Insist on an Ultra Durable™ Motherboard for your new PC
2X Copper PCB
Quality Inside and Out
Even though several of the high quality components used in GIGABYTE Ultra Durable™ motherboards are not visible from the outside, rest assured that they are working hard to provide better efficiency, greater power savings, lower system temperatures, better overclocking performance and extended system longevity. That’s the GIGABYTE Ultra Durable™ guarantee.
PCB (Printed Circuit Board)
2x copper PCB = 2 oz copper PCB = weight of copper layer
30.48 cm x 30.48 cm (1 square foot) PCB is 56.7 g (2 oz)
Copper Layer Thickness
2x copper 0.070mm(70 µm)
1x copper 0.035mm(35 µm)
High Capacity
Ferrite Core
Solid Capacitor
Power Stage
2x Copper
Inner Layer
Signal Layer
Power Layer
New Glass Fabric
Ground Layer
Signal Layer
* Actual component specifications may vary by model
The Benefits of 2 oz Copper PCB design
Better Power
2x Lower
Lower EMI Better ESD
GIGABYTE’s exclusive 2X Copper PCBs design provides sufficient power trace paths between components to handle greater than normal power loads and to remove heat from the critical CPU power delivery area. This is essential to ensure the motherboard is able to handle the increased power loading that is necessary when overclocking.
