Version Version 1.0 or 2.0
Form Factor 3 Nodes/ 2OU
Motherboard MZ61-HD2
CPU AMD EPYC™ 7000 series processor families
Socket 2 x LGA 4094
Chipset SoC
Memory 16 x DIMM slots
DDR4 memory supported only
8-Channel memory architecture
RDIMM modules up to 64GB supported
LRDIMM modules up to 128GB supported
Memory speed: 2666(1DPC)/2400/2133 MHz
LAN 2 x 10GbE LAN ports (Intel® I350-AM2)
1 x 10/100/1000 management LAN
Video Integrated in Aspeed® AST2500
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp, DDR4 SDRAM
Storage 4 x 2.5" hybrid NVMe/SATA/SAS hot-swap bays
4 x 2.5" NVMe fixed bays
Backplane 6Gb/s, 12Gb/s, NVMe
SATA Drives 4
SAS Drives Add-on card available
NVMe Drives 8
RAID Optional
Expansion Slots 2 x PCIe x16 (Gen3 x16) slots, Low profile, half length
1 x OCP mezzanine slot (Gen3 x16), occupied by CNVO124, 4 x U.2 HBA
Front IO
2 x USB 3.0
1 x VGA
2 x RJ45
1 x MLAN
1 x Power button with LED
1 x ID button with LED
1 x System status LED
TPM 1 x TPM header
Server Management Aspeed® AST2500 management controller
Avocent® MergePoint IPMI 2.0 web interface:
Network settings
Network security settings
Hardware information
Users control
Services settings
IPMI settings
Sessions control
LDAP settings
Power control
Fan profiles
Voltages, fans and temperatures monitoring
System event log
Events management (platform events, trap settings, email settings)
Serial Over LAN
vKVM & vMedia (HTML5)
Operating Properties Operating temperature: 10°C to 35°C
Operating humidity: 8-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)
Fan Module 2 x 80x80x38mm 14900rpm fan modules per nodes
Chassis Dimension 690x180x90 (mm)
Weight Net Weight: 7.32 kg
Gross Weight: 12.18 kg
Part Numbers 6NTO22Z62MR-00
