اسم الموديل |
GA-B75-D3V |
GA-B75M-D3H |
GA-B75M-D3V |
المعالج |
Intel 3rd and 2nd gen Core CPUs |
Intel 3rd and 2nd gen Core CPUs
|
Intel 3rd and 2nd gen Core CPUs |
مقبس المعالج |
LGA 1155 |
LGA 1155 |
LGA 1155 |
FSB/BCLK |
100 |
100 |
100 |
الشريحة الرئيسية |
Intel B75 Express chipset |
Intel B75 Express chipset |
Intel B75 Express chipset |
واجهة الجرافيك |
1*PCIe 3.0x16 + 1*PCIe 2.0x4 |
1*PCIe 3.0x16 + 1*PCIe 2.0x4 |
1*PCIe 3.0x16 |
نوع الذاكرة |
Dual-Channel DDR3
1600/1333 MHz |
Dual-Channel DDR3
1600/1333 MHz |
Dual-Channel DDR3
1600/1333 MHz |
واجهات تركيب وحدات الذاكرة |
4*DDR3 (Max 32 GB) |
4*DDR3 (Max 32 GB) |
2*DDR3 (Max 32 GB) |
واجهات تركيب الكروت |
3*PCIe x1+2*PCI |
2*PCI |
2*PCIe x1+1*PCI |
موصلات SATA |
1*SATA 6Gb/s+ 4*SATA 3Gb/s |
1*SATA 6Gb/s+ 5*SATA 3Gb/s |
1*SATA 6Gb/s+ 5*SATA 3Gb/s |
USB |
4 USB 3.0 ports, 8 USB 2.0 ports |
4 USB 3.0 ports, 8 USB 2.0 ports |
4 USB 3.0 ports, 8 USB 2.0 ports |
شريحة الصوت/الشبكة |
ALC887-VD2/
Qualcomm Atheros 8151 |
ALC887/Realtek 8111F-VL |
ALC887/Qualcomm Atheros 8151 |
مخرج الفيديو |
RGB/DVI |
RGB/DVI/HDMI |
RGB/DVI |
خصائص و برامج |
Dual UEFI BIOS, Gen.3 support,
Ultra Durable 4 Classic,USB3.0,
SATA 3, 3X USB Power,mSATA, CrossFireX, On/Off charege,
All Japanese solid capacitors,
LAN Optimizer
|
Dual UEFI BIOS, Gen.3 support,
Ultra Durable 4 Classic,USB3.0,
SATA 3, 3X USB Power, CrossFireX, On/Off charege,
All Japanese solid capacitors,
LAN Optimizer |
Dual UEFI BIOS, Gen.3 support,
Ultra Durable 4 Classic,
USB3.0, SATA 3,
3X USB
Power(For USB3.0 only),
CrossFireX, On/Off charege,
All Japanese solid capacitors,
LAN Optimizer |
أبعاد المنتج (مم) |
ATX 305x215 |
mATX 244x220 |
mATX 244x174 |
|
اسم الموديل |
GA-P75-D3 * |
GA-P75-D3P * |
GA-B75M-D3P |
المعالج |
Intel 3rd and 2nd gen Core CPUs |
Intel 3rd and 2nd gen Core CPUs |
Intel 3rd and 2nd gen Core CPUs
|
مقبس المعالج |
LGA 1155 |
LGA 1155 |
LGA 1155 |
FSB/BCLK |
100 |
100 |
100 |
الشريحة الرئيسية |
Intel B75 Express chipset |
Intel B75 Express chipset |
Intel B75 Express chipset |
واجهة الجرافيك |
1*PCIe 3.0x16 + 1*PCIe 2.0x4 |
1*PCIe 3.0x16 + 1*PCIe 2.0x4 |
1*PCIe 3.0x16 + 1*PCIe 2.0x4 |
نوع الذاكرة |
Dual-Channel DDR3
1600/1333 MHz |
Dual-Channel DDR3
1600/1333 MHz |
Dual-Channel DDR3
1600/1333 MHz |
واجهات تركيب وحدات الذاكرة |
4*DDR3 (Max 32 GB) |
4*DDR3 (Max 32 GB) |
4*DDR3 (Max 32 GB) |
واجهات تركيب الكروت |
1*PCIe x1+4*PCI |
1*PCIe x1+4*PCI |
1*PCIe x1+1*PCI |
موصلات SATA |
1*SATA 6Gb/s+ 4*SATA 3Gb/s |
1*SATA 6Gb/s+ 4*SATA 3Gb/s |
3*SATA 6Gb/s+ 5*SATA 3Gb/s |
USB |
4 USB 3.0 ports, 8 USB 2.0 ports |
4 USB 3.0 ports, 8 USB 2.0 ports |
4 USB 3.0 ports, 8 USB 2.0 ports |
شريحة الصوت/الشبكة |
ALC887-VD2/Realtek 8111F-VL |
ALC887/Realtek 8111F-VL |
ALC887/Realtek 8111DP-VL |
مخرج الفيديو |
N/A |
N/A |
RGB/DVI/HDMI/DisplayPort |
خصائص و برامج |
Dual UEFI BIOS, Gen.3 support,
Ultra Durable 4 Classic,USB3.0,
SATA 3, 3X USB Power,mSATA, CrossFireX, On/Off charege,
All Japanese solid capacitors,
LAN Optimizer |
Dual UEFI BIOS, Gen.3 support,
Ultra Durable 4 Classic,USB3.0,
SATA 3, 3X USB Power,mSATA, CrossFireX, On/Off charege,
All Japanese solid capacitors,
LAN Optimizer |
Dual UEFI BIOS, Gen.3 support,
Ultra Durable 4 Classic,
USB3.0, SATA 3,
3X USB
Power(For USB3.0 only), CrossFireX, On/Off charege,
All Japanese solid capacitors,
LAN Optimizer |
أبعاد المنتج (مم) |
ATX 305x215 |
ATX 305x217 |
mATX 244x244 |
اسم الموديل |
GA-B75M-HD3 |
GA-B75M-D2V |
|
|
Intel 3rd and 2nd gen Core CPUs |
Intel 3rd and 2nd gen Core CPUs |
|
|
LGA 1155 |
LGA 1155 |
|
FSB/BCLK |
100 |
100 |
|
|
Intel B75 Express chipset |
Intel B75 Express chipset |
|
|
|
|
|
|
Dual-Channel DDR3
1600/1333 MHz |
Dual-Channel DDR3
1600/1333 MHz |
|
واجهات تركيب وحدات الذاكرة
|
|
|
|
|
|
|
|
|
1*SATA 6Gb/s+5*SATA 3Gb/s
|
1*SATA 6Gb/s+5*SATA 3Gb/s
|
|
USB |
|
|
|
|
Realtek ALC887/Realtek 8111F |
Realtek ALC887/Realtek 8111F |
|
|
|
|
|
|
USB 3.0, SATA 3,
Ultra durable 4 Classic,
All Solid capacitors,
On/Off Charge,Dual UEFI BIOS, Win8
|
USB 3.0, SATA 3,
Ultra durable 4 Classic,
All Solid capacitors,
On/Off Charge, UEFI BIOS, Win8
|
|
|
|
|
|
|
|
*هذه اللوحة الرئيسية المدعومة بشريحة إنتل B75 لا تدعم Intel HD Graphics أو Intel Wireless Display (حتى فى وجود شريحة WiFi مناسبة من إنتل).
يلزم تركيب كارت جرافيك مستقل لعروض الفيديو
|
*يتوقف دعم الجيل الثالث من واجهات تركيب الكروت PCIE على توافق كل من المعالج و الكارت المستخدم. |
|
