Copper Cooled Quality
GIGABYTE 2x Copper PCB™ series motherboards


What is 2x Copper PCB™ Layer?


Each motherboard PCB consists of a number of layers that are tightly packed together to form a hard board. The most important two layers are the power and ground layers that essentially work the same as any electrical cable or plug to power devices. The glaring difference being that a motherboard is designed to power vast numbers of components from a single board. So with 2x copper PCBs, the power and ground layers in GIGABYTE motherboards are doubled to provide a more solid, durable and cooler system for discerning PC usersUltra Durable™ Family.


Reducing Impedance by 2x, allows greater electric current flow and reduces heat generation

Lower
is Better

Lower
PCB layer cross-section images, magnified 200x

PCB (Printed Circuit Board)
2x copper PCB™ = weight of copper layer
30.48 cm x 30.48 cm (1 square foot) PCB is 56.7 g (2 oz)

Benefits of 2x Copper PCB™
Lower
Temperature

Better
Overclocking
2x Lower
Impedance
Better Power
Effciency
Lower EMI

Better ESD
Protection

More 2x copper PCB™ information, please link the 2x copper PCB™ website.
