GIGABYTE

|
|
|
Models
|

Intel – X58A Series

  GA-X58A-UD7 GA-X58A-UD5 GA-X58A-UD3R


Model
GA-X58A-UD7
GA-X58A-UD7
GA-X58A-UD7
GA-X58A-UD5
GA-X58A-UD7
GA-X58A-UD3R

CPU Support
Intel Core i7 Processors
Intel Core i7 Processors
Intel Core i7 Processors
CPU Socket
LGA1366
LGA1366
LGA1366
QPI/FSB
6.4GT/s, 4.8GT/s
6.4GT/s, 4.8GT/s
6.4GT/s, 4.8GT/s
Chipset
Intel X58 + ICH10R
Intel X58 + ICH10R
Intel X58 + ICH10R
Onboard Graphics
-
-
-
Graphics Interface
4*PCI-E 2.0 x16 slot
(2x16 or 4x8)
4*PCI-E 2.0 x16 slot
(2x16 or 4x8)
4*PCI-E 2.0 x16 slot
(2x16 or 4x8)
Memory
Dual Channel DDR3 2200/1333/1066/800
Dual Channel DDR3 2200/1333/1066/800
Dual Channel DDR3 2200/1333/1066/800
Memory Socket
6*DDR3 (Max 24 GB)
6*DDR3 (Max 24 GB)
6*DDR3 (Max 24 GB)
Expansion Slots
1*PCI + 2*PCI-Ex1
1*PCI + 2*PCI-Ex1
1*PCI + 2*PCI-Ex1
ATA connector
2*SATA 6Gb/s
10*SATA 3Gb/s + 1*PATA
2*SATA 6Gb/s
10*SATA 3Gb/s + 1*PATA
2*SATA 6Gb/s
10*SATA 3Gb/s + 1*PATA
RAID
SATA 6Gb RAID 0
SATA 3Gb RAID 0, 1, 5, 10
SATA 6Gb RAID 0
SATA 3Gb RAID 0, 1, 5, 10
SATA 6Gb RAID 0
SATA 3Gb RAID 0, 1, 5, 10
Audio
HD Audio, 8-channel
HD Audio, 8-channel
HD Audio, 8-channel
IEEE 1394
3*IEEE 1394a
3*IEEE 1394a
3*IEEE 1394a
USB
10*USB 2.0, 2*USB 3.0
10*USB 2.0, 2*USB 3.0
10*USB 2.0, 2*USB 3.0
LAN
2*Gigabit LAN
(Teaming Support)
2*Gigabit LAN
(Teaming Support)
1*Gigabit LAN
(Teaming Support)
BIOS
DualBIOS™
DualBIOS™
DualBIOS™
Features
USB 3.0, SATA 6Gb/s, 3x USB power, 24 phase power, Ultra Durable 3, Dynamic Energy Saver 2, ATI CrossFireX, SLI, Debug LED, Dolby Home Theater, Precision OV, eSATA/ USB combo, Hybrid SILENT-PIPE 2, Quick Boost
USB 3.0, USB 3x power ,
SATA 6Gb/s, 12 phase,
Smart6, Ultra Durable 3,
Dynamic Energy Saver 2,
3 Way SLI, ATI CrossFireX,
Dolby Home Theater,
Precision OV, Debug LED,
EuP Ready
USB 3.0, USB 3x power ,
SATA 6Gb/s,
Smart6,Ultra Durable 3,
Dynamic Energy Saver 2,
3 Way SLI, ATI CrossFireX,
Dolby Home Theater,
Precision OV,
EuP Ready
Software
EasyTune 6,
Norton™ Internet Security
EasyTune 6,
Norton™ Internet Security
EasyTune 6,
Norton™ Internet Security
Form Factor (mm)
ATX (305x244)
ATX (305x244)
ATX (305x244)




Norton™ Internet Security
Fast, comprehensive, and up-to-the-minute protection against online threats. It safeguards your computer, identity, and home network without slowing you down.
It sets a new standard for speed and makes online shopping, banking, and browsing safer and more convenient than ever.


  U : 2 oz copper PCB design D : All solid capacitor design
*Product features may vary by model. *Motherboard models may vary based on local distribution.
*Please refer to GIGABYTE website for CPU support information.
The entire materials provided herein are for reference only. GIGABYTE reserves the right to modify or revise the content at anytime without prior notice.
