* Product features may vary by model. |
| Model Name |
|
|
|
GA-Z77X-UD5H WiFi
GA-Z77X-UD5H |
|
|
|
GA-Z77X-UD3H WiFi
GA-Z77X-UD3H |
|
| CPU Support |
Intel 22nm and 2nd Gen Core CPUs |
Intel 22nm and 2nd Gen Core CPUs |
Intel 22nm and 2nd Gen Core CPUs |
| CPU Socket |
LGA1155 |
LGA1155 |
LGA1155 |
| Chipset |
Intel Z77 chipset |
Intel Z77 chipset |
Intel Z77 chipset |
| Graphics Interface |
2*PCIE 3.0 X16+ 2*PCIE 3.0 X8 |
1*PCIE 3.0 X16+ 1*PCIE 3.0 X8 |
1*PCIE 3.0 X16+ 1*PCIE 3.0 X8 |
| Memory Type |
Dual-Channel DDR3 1600/1333 MHz |
Dual-Channel DDR3 1600/1333 MHz |
Dual-Channel DDR3 1600/1333 MHz |
| Memory DIMM |
4*DDR3 (Max 32 GB) |
4*DDR3 (Max 32 GB) |
4*DDR3 (Max 32 GB) |
| Expansion Slots |
2*PCIEx1+ 1*PCI |
1*PCIEx4+3*PCIEx1+ 1*PCI |
1*PCIEx4+3*PCIEx1+ 1*PCI |
| SATA connector |
6*SATA 6Gb/s+4*SATA 3Gb/s |
6*SATA 6Gb/s+4*SATA 3Gb/s |
4*SATA 6Gb/s+4*SATA 3Gb/s |
| SATA RAID |
RAID 0,1,5,10 |
RAID 0,1,5,10 |
RAID 0,1,5,10 |
| USB |
10* USB3.0+4*USB2.0 |
10* USB3.0+6*USB2.0 |
8* USB3.0+6*USB2.0 |
| Video Output |
HDMI,DVI,RGB,Display port |
HDMI,DVI,RGB,Display port |
HDMI,DVI,RGB,Display port |
| Audio |
8-channel HD |
8-channel HD |
8-channel HD |
| 1394 |
2*1394 |
2*1394 |
- |
| LAN |
Smart Dual LAN |
Smart Dual LAN |
GbE LAN |
| Features & Software |
3D Power, 3D BIOS,
Gen. 3 support, Ultra Durable 4,
EZ Smart Response,
Onboard OC buttons,
Creative Sound Core 3D, mSATA, CrossFireX, SLI, On/off charge,
All Japanese Solid capacitors,
Lucid MVP, WiFi+Bluetooth 4.0 |
3D Power, 3D BIOS,
Gen. 3 support, Ultra Durable 4,
EZ Smart Response,
Creative X-Fi MBII SW,
mSATA, CrossFireX, SLI,
On/off charge,
All Japanese Solid capacitors,
Lucid MVP, WiFi+Bluetooth 4.0 |
3D Power, 3D BIOS,
Gen. 3 support, Ultra Durable 4,
EZ Smart Response,
mSATA, CrossFireX, SLI,
On/off charge,
All Japanese Solid capacitors,
Lucid MVP,
WiFi+Bluetooth 4.0 |
| Form Factor (mm) |
ATX (305x264) |
ATX (305x244) |
ATX (305x244) |
|
| Model Name |
|
|
|
| CPU Support |
Intel 22nm and 2nd Gen Core CPUs |
Intel 22nm and 2nd Gen Core CPUs |
Intel 22nm and 2nd Gen Core CPUs |
| CPU Socket |
LGA1155 |
LGA1155 |
LGA1155 |
| Chipset |
Intel Z77 chipset |
Intel Z77 chipset |
Intel Z77 chipset |
| Graphics Interface |
1*PCIE 3.0 X16+ 1*PCIE 3.0 X8 |
1*PCIE 3.0 X16+ 1*PCIE 2.0 X4 |
1*PCIE 3.0 X16+ 1*PCIE 2.0 X4 |
| Memory Type |
Dual-Channel DDR3 1600/1333 MHz |
Dual-Channel DDR3 1600/1333 MHz |
Dual-Channel DDR3 1600/1333 MHz |
| Memory DIMM |
4*DDR3 (Max 32 GB) |
4*DDR3 (Max 32 GB) |
4*DDR3 (Max 32 GB) |
| Expansion Slots |
1*PCIEx4+3*PCIEx1+ 1*PCI |
3*PCIEx1+ 2*PCI |
2*PCIEx1+ 2*PCI |
| SATA connector |
4*SATA 6Gb/s+4*SATA 3Gb/s |
2*SATA 6Gb/s+4*SATA 3Gb/s |
2*SATA 6Gb/s+3*SATA 3Gb/s |
| SATA RAID |
RAID 0,1,5,10 |
RAID 0,1,5,10 |
RAID 0,1,5,10 |
| USB |
8* USB3.0+6*USB2.0 |
6* USB3.0+10*USB2.0 |
4* USB3.0+8*USB2.0 |
| Video Output |
HDMI,DVI,RGB |
HDMI,DVI,RGB |
HDMI,DVI,RGB |
| Audio |
8-channel HD |
8-channel HD |
8-channel HD |
| 1394 |
- |
- |
- |
| LAN |
GbE LAN |
GbE LAN |
GbE LAN |
| Features & Software |
3D Power, 3D BIOS,
Gen. 3 support,
Ultra Durable 4 Classic, EZ Smart Response, mSATA,
CrossFireX, SLI, On/off charge,
All Japanese Solid capacitors,
Lucid MVP |
3D Power, 3D BIOS,
Gen. 3 support,
Ultra Durable 4 Classic
EZ Smart Response, mSATA,
CrossFireX, On/off charge,
All Japanese Solid capacitors,
Lucid MVP |
3D BIOS, Gen. 3 support,
Ultra Durable 4 Classic,
EZ Smart Response,
mSATA, CrossFireX,
On/off charge, Solid capacitors |
| Form Factor (mm) |
ATX (305x225) |
ATX (305x244) |
ATX (305x215) |
|
| Model Name |
|
|
~coming soon~ |
G1.Sniper M3 |
|
|
| CPU Support |
Intel 22nm and 2nd Gen Core CPUs |
Intel 22nm and 2nd Gen Core CPUs |
Intel 22nm and 2nd Gen Core CPUs |
| CPU Socket |
LGA1155 |
LGA1155 |
LGA1155 |
| Chipset |
Intel Z77 chipset |
Intel Z77 chipset |
Intel Z77 chipset |
| Graphics Interface |
1*PCIE 3.0 X16+ 1*PCIE 2.0 X4 |
1*PCIE 3.0 X16+ 1*PCIE 3.0 X8 |
1*PCIE 3.0 X16+ 1*PCIE 3.0 X8 |
| Memory Type |
Dual-Channel DDR3 1600/1333 MHz |
Dual-Channel DDR3 1600/1333 MHz |
Dual-Channel DDR3 1600/1333 MHz |
| Memory DIMM |
4*DDR3 (Max 32 GB) |
4*DDR3 (Max 32 GB) |
4*DDR3 (Max 32 GB) |
| Expansion Slots |
2*PCIEx1+ 2*PCI |
1*PCIEx4+ 1*PCIEx1 |
1*PCIEx4+ 1*PCIEx1 |
| SATA connector |
2*SATA 6Gb/s+3*SATA 3Gb/s |
2*SATA 6Gb/s+4*SATA 3Gb/s |
2*SATA 6Gb/s+4*SATA 3Gb/s |
| SATA RAID |
RAID 0,1,5,10 |
RAID 0,1,5,10 |
RAID 0,1,5,10 |
| USB |
4* USB3.0+8*USB2.0 |
4* USB3.0+8*USB2.0 |
4* USB3.0+10*USB2.0 |
| Video Output |
HDMI |
HDMI,DVI,RGB,Display port |
HDMI,DVI,RGB |
| Audio |
8-channel HD |
8-channel HD |
8-channel HD |
| 1394 |
- |
- |
- |
| LAN |
GbE LAN |
Intel GbE LAN |
GbE LAN |
| Features & Software |
3D BIOS, Gen. 3 support,
Ultra Durable 4 Classic,
EZ Smart Response,
mSATA, CrossFireX,
On/off charge, Solid capacitors |
3D Power, 3D BIOS,
Gen. 3 support, Ultra Durable 4,
Creative Sound Core 3D,
EZ Smart Response, USB 3.0, SATA3, CrossFireX,
SLI, On/off charge,
All Japanese Solid capacitors,
Lucid MVP |
3D Power, 3D BIOS,
Gen. 3 support,
Ultra Durable 4 Classic,
EZ Smart Response, CrossFireX,
SLI, On/off charge,
All Japanese Solid capacitors,
Lucid MVP |
| Form Factor (mm) |
ATX (305x215) |
mATX (244x244) |
mATX (244x244) |
|
| Model Name |
|
|
|
| CPU Support |
Intel 22nm and 2nd Gen Core CPUs |
Intel 22nm and 2nd Gen Core CPUs |
Intel 22nm and 2nd Gen Core CPUs |
| CPU Socket |
LGA1155 |
LGA1155 |
LGA1155 |
| Chipset |
Intel Z77 chipset |
Intel H77 chipset |
Intel H77 chipset |
| Graphics Interface |
1*PCIE 3.0 X16+ 1*PCIE 2.0 X4 |
1*PCIE 3.0 x16 +1*PCIE 2.0 x4 |
1*PCIE 3.0 x16+1*PCIE 2.0 x4 |
| Memory Type |
Dual-Channel DDR3 1600/1333 MHz |
Dual-Channel DDR3 1600/1333 MHz |
Dual-Channel DDR3 1600/1333 MHz |
| Memory DIMM |
4*DDR3 (Max 32 GB) |
4*DDR3 (Max 32 GB) |
4*DDR3 (Max 32 GB) |
| Expansion Slots |
1*PCIEx1+ 1*PCI |
3*PCIEx1+ 2*PCI |
1*PCIEx1+ 1*PCI |
| SATA connector |
2*SATA 6Gb/s+4*SATA 3Gb/s |
2*SATA 6Gb/s+4*SATA 3Gb/s |
2*SATA 6Gb/s+4*SATA 3Gb/s |
| SATA RAID |
RAID 0,1,5,10 |
RAID 0,1,5,10 |
RAID 0,1,5,10 |
| USB |
4* USB3.0+10*USB2.0 |
6* USB3.0+10*USB2.0 |
4* USB3.0+10*USB2.0 |
| Video Output |
HDMI,DVI,RGB |
HDMI,DVI,RGB |
HDMI,DVI,RGB |
| Audio |
8-channel HD |
8-channel HD |
8-channel HD |
| 1394 |
- |
- |
- |
| LAN |
GbE LAN |
GbE LAN |
GbE LAN |
| Features & Software |
3D BIOS,
Gen. 3 support,
Ultra Durable 4 Classic,
EZ Smart Response,
CrossFireX, On/off charge,
All Japanese Solid capacitors |
3D Power, 3D BIOS,
Gen. 3 support,
Ultra Durable 4 Classic,
EZ Smart Response,USB 3.0,
SATA3, 3X power, mSATA,
CrossFireX, On/off charge,
All Japanese Solid capacitors |
3D BIOS, Gen. 3 support,
Ultra Durable 4 Classic,
EZ Smart Response, USB 3.0,
SATA3, 3X power, CrossFireX,
On/off charge,
All Japanese Solid capacitors |
| Form Factor (mm) |
mATX (244x244) |
ATX (305x244) |
mATX(244x220) |
|
U : 2 x copper PCB design D : All solid capacitor design
* PCIe Gen. 3 is dependent on CPU and expansion card compatibility.
* Product features may vary by model.
* Motherboard models may vary based on local distribution.
Please refer to GIGABYTE website for CPU support information. |
|
