Soporte de CPU

Socket del CPU

LGA1155

Chipset

Intel Z68 chipset

Intel HD Graphics 2000/3000

Interfaz Gráfica

2*PCI-E 2.0 x16 slot
(x16, x8)/ HDMI

Tipo de Memoria

Dual Channel 2133/1333/1066

DIMM de Memoria

4*DDR3 (Max 32 GB)

Puertos de Expansión

2*PCI-Ex1+ 2*PCI

SATA RAID

Conector SATA

4* SATA 6Gb/s+3* SATA
3Gb/s+1*eSATA 3Gb/s

USB

4*USB 3.0 +14*USB 2.0

Audio

Creative HW audio 20K2

Front audio headphone amplifier

Nichicon MUSE capacitor

LAN

Bigfoot Killer 2100

TPM

Onboard LPC pin header for
Infineon TPM module

Características&Software

Touch BIOS,EZ Smart Response, Intel Smart Response, Lucid Virtu,8 power phase,Ultra Durable 3, On/off Charge, Smart 6, 2 way CrossFireX/SLI,Driver MOSFET,X-Fi,EAX

Tamaño (mm)

ATX (305x264)

Soporte del CPU

Intel^® Core™ i7 Processors

Intel^® Core™ i7 Processors

Socket del CPU

LGA1366

LGA1366

LGA1366

QPI/FSB

4.8GT/s, 6.4GT/s

4.8GT/s, 6.4GT/s

4.8GT/s, 6.4GT/s

Chipset

X58+ICH10R

X58+ICH10R

X58+ICH10R

Interfaz Gráfica

4*PCI-E 2.0 x16 slot  (2x16, 2x8)

3*PCI-E 2.0 x16 slot  (2x16, 1x8)

3*PCI-E 2.0 x16 slot  (2x16, 1x8)

Tipo de Memoria

3 Channel DDR3 2200/1600/1333MHz

3 Channel DDR3 2200/1600/1333MHz

3 Channel DDR3 2200/1600/1333MHz

DIMM de Memoria

6*DDR3 (Max 24 GB)

6*DDR3 (Max 24 GB)

6*DDR3 (Max 24 GB)

Puertos de Expansión

2*PCI-Ex1+ 1*PCI

2*PCI-Ex1+ 1*PCI

2*PCI-Ex1+ 1*PCI

Conector SATA

2* SATA 6Gb/s+6* SATA 3Gb/s+ 1*Power eSATA (front bezel)

2* SATA 6Gb/s+6* SATA 3Gb/s+2*eSATA 3Gb/s

2* SATA 6Gb/s+6* SATA 3Gb/s+2*eSATA 3Gb/s

SATA RAID

RAID 0,1,5,10, JBOD

RAID 0,1,5,10, JBOD

RAID 0,1,5,10, JBOD

USB 3.0

8 (4 front, 4 rear)

4 (2 front, 2 rear)

4 (2 front, 2 rear)

USB 2.0

8 (4 front, 4 rear)

12 (6 front, 6 rear)

12 (6 front, 6 rear)

Audio

Creative HW audio 20K2

Creative HW audio 20K2

Realtek ALC 889

Front audio headphone amplifier

Front audio headphone amplifier

Front audio headphone amplifier

Nichicon MUSE capacitor

Nichicon MUSE capacitor

Nichicon MUSE capacitor

LAN

Bigfoot Killer™ 2100

Bigfoot Killer™ 2100

Bigfoot Killer™ 2100

Botón de ON en HW

Yes (front bezel)

Yes (rear panel)

Yes (rear panel)

Características &
Software

16 power phase, Dual Power, 3 way SLI™, 4 way CrossFire™ X, Driver MOSFET, X-Fi, EAX, Dolby, DTS, 3TB+ HDD,On/Off charge, USB 3.0,USB 3x power, Smart6, UD3,DES2

8 power phase, Dual Power, 3 way SLI™,
3 way CrossFire™ X,Driver MOSFET, X-Fi, EAX, Dolby, DTS,3TB+ HDD, On/Off charge,
USB 3.0, USB 3x power, Smart6, UD3,DES2

8 power phase, Dual Power, 3 way SLI™,
3 way CrossFire™ X,Driver MOSFET, X-Fi,
3TB+ HDD, On/Off charge,USB 3.0,
USB 3x power,Smart6, UD3,DES2

Tamaño (mm)

XL-ATX (345x262)

ATX (305x264)

ATX (305x263)

*Las características pueden variar entre modelos. *Las especificaciones e imágenes pueden cambiar sin previo aviso
*Los modelos de motherboards pueden variar por la distribución local.
*Visita el sitio Web de GIGABYTE para información del soporte de CPUs.
