Próximamente |
|
* Product features may vary by model. |
| Nombre de Modelo |
|
|
| Soporte de CPU |
3rd and 2nd Gen Intel Core CPUs
|
3rd and 2nd Gen Intel Core CPUs
|
| Socket del CPU |
LGA1155 |
LGA1155 |
| Chipset |
Intel Z77 chipset |
Intel Z77 chipset |
| Interfaz Gráfica |
1*PCIE 3.0X16+1*PCIE 3.0X8
|
1*PCIE 3.0X16+1*PCIE 3.0X8
|
| Tipo de Memoria |
Dual-Channel DDR3
2800/2600 (OC*)/1600 MHz
|
Dual-Channel DDR3
2800/2600 (OC*)/1600 MHz
|
| DIMM de Memoria |
4*DDR3(Max 32 GB)
|
4*DDR3 (Max 32 GB) |
| Purtos de Expansión |
1*PCIEx4+3*PCIEx1+1*PCI
|
1*PCIEx4+3*PCIEx1+1*PCI
|
| SAS/SATA |
4*SATA 6Gb/s+4*SATA 3Gb/s
|
2*SATA 6Gb/s+4*SATA 3Gb/s
|
| SATA RAID |
RAID 0,1,5,10 |
RAID 0,1,5,10
|
| USB |
10*USB3.0+6*USB2.0
|
8*USB3.0+6*USB2.0
|
| Audio |
8-channel HD |
8-channel HD
|
| 1394 |
1*1394a
|
- |
| LAN |
GbE LAN
|
GbE LAN
|
| Salida de Video |
HDMI/DVI/RGB/2xThunderblot port
|
HDMI/DVI/RGB/2xThunderblot port
|
| Características & Software |
Ultra Durable 5,
Thunderbolt support,
3D Power, 3D BIOS, WiFi+BlueTooth 4.0, Lucid MVP, mSATA, EZ Smart Response, SLI, CrossFireX, CFOS, On/off charge,
All Japanese Solid capacitors |
Ultra Durable 5,
Thunderbolt support,
3D Power, 3D BIOS,
Lucid MVP, mSATA,
EZ Smart Response, SLI, CrossFireX, On/off charge,
All Japanese Solid capacitors |
| Tamaño (mm) |
ATX(305x244)
|
ATX(305x244)
|
|
| Nombre de Modelo |
|
|
| Soporte de CPU |
2nd Generation Intel Core Processors
|
2nd Generation Intel Core Processors
|
| Socket del CPU |
LGA 2011
|
LGA 2011
|
| Chipset |
Intel C606 chipset
|
Intel X79 chipset
|
| Interfaz Gráfica |
2*PCIE 3.0X16+1*PCIE 3.0X8
|
2*PCIE 3.0X16+2*PCIE 3.0X8
|
| Tipo de Memoria |
4 Channel DDR3
2400/1866 (OC*)/1600 MHz
|
4 Channel DDR3
2400/1866 (OC*)/1600 MHz
|
| DIMM de Memoria |
8*DDR3(Max 64 GB)
|
8*DDR3(Max 64 GB)
|
| Purtos de Expansión |
1*PCIEx4+1*PCIEx1+1*PCI
|
2*PCIEx1+1*PCI
|
| SAS/SATA |
8*SAS+2*SATA 6Gb/s+6*SATA 3Gb/s
|
6*SATA 6Gb/s+6*SATA 3Gb/s
|
| SATA RAID |
RAID 0,1,5,10
|
RAID 0,1,5,10 |
| USB |
6*USB3.0+12*USB2.0
|
4*USB3.0+14*USB2.0
|
| Audio |
8-channel HD |
8-channel HD |
| 1394 |
2*1394a
|
- |
| LAN |
Dual LAN
|
GbE LAN
|
| Salida de Video |
-
|
-
|
| Características & Software |
Ultra Durable 5,
3D Power, 3D BIOS,
3-Way SLI, 3-Way CrossFireX, On/Off Charge,
WIFI+BlueTooth 4.0, OC DualBIOS, eSATA, All Japanese Solid Capacitors, 110dB |
Ultra Durable 5,
3D Power, 3D BIOS,
4-Way SLI, 4-Way CrossFireX,
On/Off Charge, All Japanese Solid Capacitors, 108dB |
| Tamaño (mm) |
E-ATX(305x262) |
ATX(305x244)
|
|
U : 2X en Cobre para el PCB P : Fase de Poder + solo Capacitores Sólidos
* El soporte de memoria es dependiente de la compatibilidad de los módulos de memoria y el SO.
* Los modelos de las motherboards pueden variar dependiendo de la distribución local.
* Vista el sitio web oficial de GIGABYTE para mayor información del soporte de CPUs. |
|
