Intel – X58A Series
Intel – P55A Series

  GA-X58A-UD7 GA-X58A-UD5 GA-X58A-UD3R


Model
GA-X58A-UD7
GA-X58A-UD7
GA-X58A-UD7
GA-X58A-UD5
GA-X58A-UD7
GA-X58A-UD3R

CPU Support
Intel Core i7 Processors
Intel Core i7 Processors
Intel Core i7 Processors
CPU Socket
LGA1366
LGA1366
LGA1366
QPI/FSB
6.4GT/s, 4.8GT/s
6.4GT/s, 4.8GT/s
6.4GT/s, 4.8GT/s
Chipset
Intel X58 + ICH10R
Intel X58 + ICH10R
Intel X58 + ICH10R
Onboard Graphics
-
-
-
Graphics Interface
4*PCI-E 2.0 x16 slot
(2x16 or 4x8)
4*PCI-E 2.0 x16 slot
(2x16 or 4x8)
4*PCI-E 2.0 x16 slot
(2x16 or 4x8)
Memory
Dual Channel DDR3 2200/1333/1066/800
Dual Channel DDR3 2200/1333/1066/800
Dual Channel DDR3 2200/1333/1066/800
Memory Socket
6*DDR3 (Max 24 GB)
6*DDR3 (Max 24 GB)
6*DDR3 (Max 24 GB)
Expansion Slots
1*PCI + 2*PCI-Ex1
1*PCI + 2*PCI-Ex1
1*PCI + 2*PCI-Ex1
ATA connector
2*SATA 6Gb/s
10*SATA 3Gb/s + 1*PATA
2*SATA 6Gb/s
10*SATA 3Gb/s + 1*PATA
2*SATA 6Gb/s
10*SATA 3Gb/s + 1*PATA
RAID
SATA 6Gb RAID 0
SATA 3Gb RAID 0, 1, 5, 10
SATA 6Gb RAID 0
SATA 3Gb RAID 0, 1, 5, 10
SATA 6Gb RAID 0
SATA 3Gb RAID 0, 1, 5, 10
Audio
HD Audio, 8-channel
HD Audio, 8-channel
HD Audio, 8-channel
IEEE 1394
3*IEEE 1394a
3*IEEE 1394a
3*IEEE 1394a
USB
10*USB 2.0, 2*USB 3.0
10*USB 2.0, 2*USB 3.0
10*USB 2.0, 2*USB 3.0
LAN
2*Gigabit LAN
(Teaming Support)
2*Gigabit LAN
(Teaming Support)
1*Gigabit LAN
(Teaming Support)
BIOS
DualBIOS™
DualBIOS™
DualBIOS™
Features
USB 3.0, SATA 6Gb/s, 3x USB power, 24 phase power, Ultra Durable 3, Dynamic Energy Saver 2, ATI CrossFireX, SLI, Debug LED, Dolby Home Theater, Precision OV, eSATA/ USB combo, Hybrid SILENT-PIPE 2, Quick Boost
USB 3.0, USB 3x power ,
SATA 6Gb/s, 12 phase,
Smart6, Ultra Durable 3,
Dynamic Energy Saver 2,
3 Way SLI, ATI CrossFireX,
Dolby Home Theater,
Precision OV, Debug LED,
EuP Ready
USB 3.0, USB 3x power ,
SATA 6Gb/s,
Smart6,Ultra Durable 3,
Dynamic Energy Saver 2,
3 Way SLI, ATI CrossFireX,
Dolby Home Theater,
Precision OV,
EuP Ready
Software
EasyTune 6,
Norton™ Internet Security
EasyTune 6,
Norton™ Internet Security
EasyTune 6,
Norton™ Internet Security
Form Factor (mm)
ATX (305x244)
ATX (305x244)
ATX (305x244)




Norton™ Internet Security
Fast, comprehensive, and up-to-the-minute protection against online threats. It safeguards your computer, identity, and home network without slowing you down.
It sets a new standard for speed and makes online shopping, banking, and browsing safer and more convenient than ever.


  U : 2 oz copper PCB design D : All solid capacitor design
*Product features may vary by model. *Motherboard models may vary based on local distribution.
*Please refer to GIGABYTE website for CPU support information.
