| Model Name |
|
|
|
| CPU/APU Support |
AMD Fusion APUs (DX11)
AMD AthlonII / Sempron CPUs |
AMD Fusion APUs (DX11)
AMD AthlonII / Sempron CPUs
|
AMD Fusion APUs (DX11)
AMD AthlonII / Sempron CPUs |
| CPU Socket |
AMD Socket FM1 |
AMD Socket FM1 |
AMD Socket FM1 |
| Chipset |
AMD A75 Chipset |
AMD A75 Chipset |
AMD A75 Chipset |
| Graphics Interface |
2*PCI-E 2.0 x16
(x8, x8) |
2*PCI-E 2.0 x16
(x16, x4) |
2*PCI-E 2.0 x16
(x16, x4) |
| Memory Type |
Dual-channel DDR3 2400+/1866/1600/1333 |
Dual-channel DDR3 2400+/1866/1600/1333 |
Dual-channel DDR3 2400+/1866/1600/1333 |
| Memory DIMM |
4*DDR3 (Max 64GB) |
4*DDR3 (Max 64GB) |
4*DDR3 (Max 64GB) |
| Expansion Slots |
3*PCI-E 2.0 x1 + 2*PCI |
2*PCI-E 2.0 x1 + 3*PCI |
2*PCI-E 2.0 x1 + 3*PCI |
| ATA connector |
5*SATA 6Gb/s + 1*eSATA 6Gb/s |
5*SATA 6Gb/s + 1*eSATA 6Gb/s |
6*SATA 6Gb/s |
| SATA RAID |
0, 1, 10 (A75) |
0, 1, 10 (A75) |
0, 1, 10 (A75) |
| USB |
8*USB3.0 + 10*USB2.0 |
6*USB3.0 +10*USB2.0 |
4*USB3.0 + 10*USB2.0 |
| Audio |
8-channel HD |
8-channel HD |
8-channel HD |
| 1394 |
2*1394a |
- |
- |
| LAN |
1*GbE |
1*GbE |
1*GbE |
| Video Output |
HDMI / Dual-link DVI / Display
/ D-Sub |
HDMI / Dual-link DVI /
D-Sub |
HDMI |
| Features & Software |
USB 3.0, SATA 6Gb/s,
3x USB power,
8+2 phase, Ultra Durable,
On/Off Charge, All Japanese solid cap, TouchBIOS,
108dB SNR Blu-ray,
AMD Dual Graphics / CrossFireX,
Dolby,
ET6
|
USB 3.0, SATA 6Gb/s,
3x USB power,
4+1 phase, Ultra Durable,
On/Off Charge,
All Japanese solid cap, TouchBIOS, 108dB SNR Blu-ray,
Dolby, AMD Dual Graphics / CrossFireX,
ET6
|
USB 3.0, SATA 6Gb/s,
3x USB power,
4+1 phase, Ultra Durable,
On/Off Charge,
All solid capacitors,
Touch BIOS, ET6, AMD Dual Graphics / CrossFireX
|
| Form Factor (mm) |
ATX (305x244) |
ATX (305x225) |
ATX (305x225) |
|
| Model Name |
|
|
|
| CPU/APU Support |
AMD Fusion APUs (DX11)
AMD AthlonII / Sempron CPUs |
AMD Fusion APUs (DX11)
AMD AthlonII / Sempron CPUs
|
AMD Fusion APUs (DX11)
AMD AthlonII / Sempron CPUs |
| CPU Socket |
AMD Socket FM1 |
AMD Socket FM1 |
AMD Socket FM1 |
| Chipset |
AMD A75 Chipset |
AMD A75 Chipset |
AMD A75 Chipset |
| Graphics Interface |
2*PCI-E 2.0 x16
(x16, x4) |
2*PCI-E 2.0 x16
(x16, x4) |
2*PCI-E 2.0 x16
(x16, x4)
|
| Memory Type |
Dual-channel DDR3 2400+/1866/1600/1333 |
Dual-channel DDR3 2400+/1866/1600/1333 |
Dual-channel DDR3 2400+/1866/1600/1333 |
| Memory DIMM |
4*DDR3 (Max 64GB) |
2*DDR3 (Max 32GB) |
2*DDR3 (Max 32GB) |
| Expansion Slots |
1*PCI-E 2.0 x1 + 1*PCI |
1*PCI-E 2.0 x1 + 1*PCI |
1*PCI-E 2.0 x1 + 1*PCI |
| ATA connector |
5*SATA 6Gb/s + 1*eSATA 6Gb/s |
6*SATA 6Gb/s |
6*SATA 6Gb/s |
| SATA RAID |
0, 1, 10 (A75) |
0, 1, 10 (A75) |
0, 1, 10 (A75) |
| USB |
4*USB3.0 + 8*USB2.0 |
4*USB3.0 + 6*USB2.0 |
4*USB3.0 + 6*USB2.0 |
| Audio |
8-channel HD |
8-channel HD |
8-channel HD |
| 1394 |
2*1394a |
- |
- |
| LAN |
1*GbE |
1*GbE |
1*GbE |
| Video Output |
HDMI / Dual-link DVI / Display
/ D-Sub |
HDMI / Dual-link DVI
/ D-Sub |
DVI / D-Sub |
| Features & Software |
USB 3.0, SATA 6Gb/s,
3x USB power,
4+1 phase, Ultra Durable,
On/Off Charge, All Japanese solid cap, TouchBIOS,
108dB SNR Blu-ray,
AMD Dual Graphics,
ET6
|
USB 3.0, SATA 6Gb/s,
3x USB power,
4+1 phase, Ultra Durable,
On/Off Charge,
108dB SNR Blu-ray,
All Japanese solid cap, TouchBIOS, AMD Dual Graphics,
ET6
|
USB 3.0, SATA 6Gb/s,
3x USB power,
4+1 phase, Ultra Durable,
On/Off Charge, All solid capacitors, Touch BIOS,
108dB SNR Blu-ray,
ET6, AMD Dual Graphics
|
| Form Factor (mm) |
mATX (244x244) |
mATX (244x225) |
mATX (244x210) |
|
| Model Name |
|
|
|
| CPU/APU Support |
AMD Fusion APUs (DX11)
AMD AthlonII / Sempron CPUs
|
AMD Fusion APUs (DX11)
AMD AthlonII / Sempron CPUs |
AMD Fusion APUs (DX11)
AMD AthlonII / Sempron CPUs |
| CPU Socket |
AMD Socket FM1 |
AMD Socket FM1 |
AMD Socket FM1 |
| Chipset |
AMD A75 Chipset |
AMD A75 Chipset |
AMD A55 Chipset |
| Graphics Interface |
2*PCI-E 2.0 x16 (x16, x4) |
1*PCI-E 2.0 x16
|
2*PCI-E 2.0 x16 (x16, x4)
|
| Memory Type |
Dual-channel DDR3 2400+/1866/1600/1333 |
Dual-channel DDR3 2000+/1866/1600/1333 |
Dual-channel DDR3 2400+/1866/1600/1333 |
| Memory DIMM |
2*DDR3 (Max 32GB) |
2*DDR3 (Max 32GB) |
4*DDR3 (Max 64GB) |
| Expansion Slots |
1*PCI-E 2.0 x1 + 1*PCI |
- |
2*PCI-E 2.0 x1 + 3*PCI |
| ATA connector |
4*SATA 6Gb/s |
4*SATA 6Gb/s + 1*eSATA |
6*SATA 3Gb/s |
| SATA RAID |
0, 1, 10 (A75) |
0, 1, 10 (A75) |
0, 1, 10 (A55) |
| USB |
4*USB3.0 + 8*USB2.0 |
4*USB3.0 + 4*USB2.0 |
14*USB2.0 |
| Audio |
8-channel HD |
8-channel HD |
8-channel HD |
| 1394 |
- |
- |
- |
| LAN |
1*GbE |
1*GbE |
1*GbE |
| Video Output |
DVI / D-sub |
HDMI / DVI |
HDMI |
| Features & Software |
USB 3.0, SATA 6Gb/s,
3x USB power,
3+1 phase, Ultra Durable,
On/Off Charge,
All solid capacitors, Touch BIOS, AMD Dual Graphics,
ET6
|
USB 3.0, SATA 6Gb/s,
3x USB power,
3+1 phase, Ultra Durable, Driver Mosfet,
On/Off Charge, All Japanese solid cap, Touch BIOS,
108dB SNR Blu-ray,
Dolby, AMD Dual Graphics,
ET6
|
3x USB power,
4+1 phase, Ultra Durable, On/Off Charge, 108dB SNR Blu-ray,
All solid capacitors, Touch BIOS, AMD Dual Graphics / CrossFireX, ET6
|
| Form Factor (mm) |
mATX (225x174) |
mini-ITX (170x170) |
ATX (305x225) |
|
| Model Name |
|
|
|
| CPU/APU Support |
AMD Fusion APUs (DX11)
AMD AthlonII / Sempron CPUs
|
AMD Fusion APUs (DX11)
AMD AthlonII / Sempron CPUs
|
AMD Fusion APUs (DX11)
AMD AthlonII / Sempron CPUs |
| CPU Socket |
AMD Socket FM1 |
AMD Socket FM1 |
AMD Socket FM1 |
| Chipset |
AMD A55 Chipset |
AMD A55 Chipset |
AMD A55 Chipset |
| Graphics Interface |
|
2*PCI-E 2.0 x16 (x16, x4)
|
2*PCI-E 2.0 x16 (x16, x4)
|
| Memory Type |
Dual-channel DDR3 2400+/1866/1600/1333 |
Dual-channel DDR3 2400+/1866/1600/1333 |
Dual-channel DDR3 Dual-ch DDR3 2400+/1866/1600/1333 |
| Memory DIMM |
2*DDR3 (Max 32GB) |
4*DDR3 (Max 64GB) |
2*DDR3 (Max 32GB) |
| Expansion Slots |
2*PCI-E 2.0 x1 + 3*PCI |
1*PCI-E 2.0 x1 + 1*PCI |
1*PCI-E 2.0 x1 + 1*PCI |
| ATA connector |
6*SATA 3Gb/s |
6*SATA 3Gb/s |
6*SATA 3Gb/s |
| SATA RAID |
0, 1, 10 (A55) |
0, 1, 10 (A55) |
0, 1, 10 (A55) |
| USB |
14*USB2.0 |
12*USB2.0 |
10*USB2.0 |
| Audio |
8-channel HD |
8-channel HD |
8-channel HD |
| 1394 |
- |
- |
- |
| LAN |
1*GbE |
1*GbE |
1*GbE |
| Video Output |
HDMI |
HDMI / DVI
/
D-Sub |
HDMI / DVI /
D-Sub |
| Features & Software |
4+1 phase, Ultra Durable,
On/Off Charge, All solid capacitors,
Touch BIOS, ET6, AMD Dual Graphics / CrossFireX
|
3x USB power, 4+1 phase, Ultra Durable,
On/Off Charge, 108dB SNR Blu-ray,
All solid capacitors, Touch BIOS, AMD Dual Graphics, ET6
|
3x USB power, 4+1 phase, Ultra Durable,
On/Off Charge, 108dB SNR Blu-ray, All solid capacitors, Touch BIOS, AMD Dual Graphics, ET6
|
| Form Factor (mm) |
ATX (305x190) |
mATX (244x244) |
mATX (244x225) |
|
| Model Name |
|
|
| CPU/APU Support |
AMD Fusion APUs (DX11)
AMD AthlonII / Sempron CPUs |
AMD Fusion APUs (DX11)
AMD AthlonII / Sempron CPUs |
| CPU Socket |
AMD Socket FM1 |
AMD Socket FM1 |
| Chipset |
AMD A55 Chipset |
AMD A55 Chipset |
| Graphics Interface |
1*PCI-E 2.0 x16
|
1*PCI-E 2.0 x16
|
| Memory Type |
Dual-channel DDR3 2400+/1866+/1600/1333 |
Dual-channel DDR3
1866+/1600/1333 |
| Memory DIMM |
2*DDR3 (Max 32GB) |
2*DDR3 (Max 32GB) |
| Expansion Slots |
2*PCI-E 2.0 x1 + 1*PCI |
1*PCI-E 2.0 x1 + 1*PCI |
| ATA connector |
6*SATA 3Gb/s |
4*SATA 3Gb/s |
| SATA RAID |
0, 1, 10 (A55) |
0, 1, 10 (A55) |
| USB |
8*USB2.0 |
8*USB2.0 |
| Audio |
8-channel HD |
8-channel HD |
| 1394 |
- |
- |
| LAN |
1*GbE |
1*GbE |
| Video Output |
DVI / D-sub |
DVI / D-sub |
| Features & Software |
3+1 phase, Ultra Durable, On/Off Charge, All solid capacitors, Touch BIOS,
ET6, AMD Dual Graphics
|
3+1 phase, Ultra Durable,
On/Off Charge, All solid capacitors,
Touch BIOS, ET6, AMD Dual Graphics
|
| Form Factor (mm) |
mATX (244x210) |
mATX 226x174) |
|
|
| |
U : 2x copper PCB design D : All solid capacitor design
* Product features may vary by model.
* Motherboard models may vary based on local distribution.
* Please refer to GIGABYTE website for CPU support information.
|
|
