Intel Models |
 |
* Product features may vary by model. |
Model Name |
|
|
|
CPU Support |
3rd and 2nd Gen Intel Core CPUs
|
3rd and 2nd Gen Intel Core CPUs
|
3rd and 2nd Gen Intel Core CPUs
|
CPU Socket |
LGA1155 |
LGA1155 |
LGA1155 |
Chipset |
Intel Z77 chipset |
Intel Z77 chipset |
Intel Z77 chipset |
Graphics Interface |
3*PCIE 3.0X16+2*PCIE 3.0X8
|
1*PCIE 3.0X16+1*PCIE 3.0X8
|
1*PCIE 3.0X16+1*PCIE 3.0X8
|
Memory Type |
Dual-Channel DDR3
2800/2600 (OC*)/1600 MHz
|
Dual-Channel DDR3
2800/2600 (OC*)/1600 MHz
|
Dual-Channel DDR3
2800/2600 (OC*)/1600 MHz
|
Memory DIMM |
4*DDR3(Max 32 GB)
|
4*DDR3(Max 32 GB)
|
4*DDR3 (Max 32 GB) |
Expansion Slots |
2*PCIEx1
|
1*PCIEx4+3*PCIEx1+1*PCI
|
1*PCIEx4+3*PCIEx1+1*PCI
|
SAS/SATA connector |
6*SATA 6Gb/s+4*SATA 3Gb/s
|
4*SATA 6Gb/s+4*SATA 3Gb/s
|
2*SATA 6Gb/s+4*SATA 3Gb/s
|
SATA RAID |
RAID 0,1,5,10 |
RAID 0,1,5,10 |
RAID 0,1,5,10
|
USB |
10*USB3.0+4*USB2.0
|
10*USB3.0+6*USB2.0
|
8*USB3.0+6*USB2.0
|
Audio |
8-channel HD |
8-channel HD |
8-channel HD
|
1394 |
- |
1*1394a
|
- |
LAN |
Dual LAN
|
GbE LAN
|
GbE LAN
|
Video Output |
HDMI/DVI/RGB/Display Port
|
HDMI/DVI/RGB/2xThunderbolt port
|
HDMI/DVI/RGB/2xThunderbolt port
|
Features & Software |
Ultra Durable 5,
32 CPU VRM phase,
3D Power, 3D BIOS,
WiFi+BlueTooth 4.0, Lucid MVP, mSATA, EZ Smart Response,
4-Way SLI, 4-Way CrossFireX,
On/off charge,
All Japanese Solid capacitors |
Ultra Durable 5,
Thunderbolt support,
3D Power, 3D BIOS, WiFi+BlueTooth 4.0, Lucid MVP, mSATA, EZ Smart Response, SLI, CrossFireX, CFOS, On/off charge,
All Japanese Solid capacitors |
Ultra Durable 5,
Thunderbolt support,
3D Power, 3D BIOS,
Lucid MVP, mSATA,
EZ Smart Response, SLI, CrossFireX, On/off charge,
All Japanese Solid capacitors |
Form Factor (mm) |
E-ATX(305x264)
|
ATX(305x244)
|
ATX(305x244)
|
|
Model Name |
|
|
CPU Support |
2nd Generation Intel Core Processors
|
2nd Generation Intel Core Processors
|
CPU Socket |
LGA 2011
|
LGA 2011
|
Chipset |
Intel C606 chipset
|
Intel X79 chipset
|
Graphics Interface |
2*PCIE 3.0X16+1*PCIE 3.0X8
|
2*PCIE 3.0X16+2*PCIE 3.0X8
|
Memory Type |
4 Channel DDR3
2400/1866 (OC*)/1600 MHz
|
4 Channel DDR3
2400/1866 (OC*)/1600 MHz
|
Memory DIMM |
8*DDR3(Max 64 GB)
|
8*DDR3(Max 64 GB)
|
Expansion Slots |
1*PCIEx4+1*PCIEx1+1*PCI
|
2*PCIEx1+1*PCI
|
SAS/SATA connector |
8*SAS+2*SATA 6Gb/s+4*SATA 3Gb/s
+2*eSATA 6Gb/s
|
6*SATA 6Gb/s+4*SATA 3Gb/s
+2*eSATA 6Gb/s
|
SATA RAID |
RAID 0,1,5,10
|
RAID 0,1,5,10 |
USB |
6*USB3.0+12*USB2.0
|
4*USB3.0+14*USB2.0
|
Audio |
8-channel HD |
8-channel HD |
1394 |
2*1394a
|
- |
LAN |
Dual LAN
|
GbE LAN
|
Video Output |
-
|
-
|
Features & Software |
Ultra Durable 5,
3D Power, 3D BIOS,
3-Way SLI, 3-Way CrossFireX, On/Off Charge,
WIFI+BlueTooth 4.0, OC DualBIOS, eSATA, All Japanese Solid Capacitors, 110dB |
Ultra Durable 5,
3D Power, 3D BIOS,
4-Way SLI, 4-Way CrossFireX,
On/Off Charge, All Japanese Solid Capacitors |
Form Factor (mm) |
E-ATX(305x262) |
ATX(305x244)
|
|
AMD Model |
 |
| Model |
|
| CPU/APU Support |
AMD A-series APUs (DX11) /
Athlon CPUs |
| CPU Socket |
AMD Socket FM2 |
| Chipset |
AMD A85X Chipset |
| Graphics Interface |
3*PCI-E 2.0 x16 (x16, x8, x4) |
| Memory Type |
Dual-ch DDR3 1866+/1600/1333 |
| Memory DIMM |
4*DDR3 (Max 64GB) |
| Expansion Slots |
3*PCI-E 2.0 x1 + 1*PCI |
| SATA connector |
7*SATA 6Gb/s + 1*eSATA 6Gb/s |
| SATA RAID |
0, 1, 5, 10 (A85X) |
| USB |
6* USB3.0 + 10*USB2.0 |
| Audio |
8-channel HD |
| LAN |
1*GbE |
| Video Output |
Display Port / HDMI/
Dual-link DVI/ D-sub |
| Features & Software |
USB 3.0, SATA 6Gb/s, 3x USB power,
6+2 phase, Ultra Durable 5,
Triple-monitor support, Win8,
AMD CrossFire/ Dual Graphics/ Eyefinity support,
Lucid Virtu MVP support,
On/Off Charge,
Dual UEFI BIOS |
| Form Factor (mm) |
ATX (305mmx244mm) |
|
|
U : 2X Copper PCB P : Power stage + All solid capacitor design
* Memory support is dependent on memory module compatibility and system OS.
* Motherboard models may vary based on local distribution.
* Please refer to GIGABYTE website for CPU support information. |
|
