Lower Temperature, Longer Life,
Extreme Overclocking Stability!

Lower RDS(on)
MOSFET

Ferrite Core
Chokes

Lower ESR
Solid Capacitors


New Design
Ultra Durable 2		 Old Design

Lower RDS(on)
MOSFET

Standard
MOSFET

Ferrite Core
Choke

Iron Core
Power Inductor

Lower ESR
Solid Capacitor

Traditional
Solid Capacitor


How does the Ultra Durable 2 Power Design Work?

Power
  Store energy
and
regulate current
 Store and
discharge electric current

Lower RDS(on)
MOSFET
To stop/allow
the electric current
to flow through

  Ferrite Core
Choke		 Lower ESR
Solid Capacitor		   Processor

Coolest P35 Motherboards in the world

33°C lower CPU VRM and North Bridge average temperature for the GIGABYTE P35-DQ6 compared to current solid capacitor motherboard of the same segment.


CPU zone temperature test
  Lower Temp. = Improved Overclocking and Stability


MOSFET
Choke
Solid
Capacitor
CPU
Backside
North
Bridge

  GIGABYTE P35-DQ6 Ultra Durable 2 Motherboard.
  current solid capacitor motherboard of the same segment.
GIGABYTE P35-DQ6 Ultra Durable 2 Motherboard



Testing Environment: Run 3DMark 2006 20mins then record temperature. CPU: 840XE A0;
Thermal Solution: water cooling to avoid air flow for accurate measurement; Room temp 25 deg C
*under controlled conditions



The above photos are for reference only. Motherboard specifications may vary by model.
