Insist on an Ultra Durable Motherboard for your new PC








Model Name
CPU/APU Support
AMD Fusion APUs (DX11)
AMD AthlonII / Sempron CPUs
AMD Fusion APUs (DX11)
AMD AthlonII / Sempron CPUs
AMD Fusion APUs (DX11)
AMD AthlonII / Sempron CPUs
CPU Socket
AMD Socket FM1
AMD Socket FM1
AMD Socket FM1
Chipset
AMD A75 Chipset
AMD A75 Chipset
AMD A75 Chipset
Graphics Interface
2*PCI-E 2.0 x16 (x8, x8)
2*PCI-E 2.0 x16 (x16, x4)
2*PCI-E 2.0 x16 (x16, x4)
Memory Type
Dual-channel DDR3 2400+/1866/1600/1333
Dual-channel DDR3 2400+/1866/1600/1333
Dual-channel DDR3 2400+/1866/1600/1333
Memory DIMM
4*DDR3 (Max 64GB)
4*DDR3 (Max 64GB)
4*DDR3 (Max 64GB)
Expansion Slots
3*PCI-E 2.0 x1 + 2*PCI
2*PCI-E 2.0 x1 + 3*PCI
2*PCI-E 2.0 x1 + 3*PCI
ATA connector
5*SATA 6Gb/s + 1*eSATA 6Gb/s
5*SATA 6Gb/s + 1*eSATA 6Gb/s
6*SATA 6Gb/s
SATA RAID
0, 1, 10 (A75)
0, 1, 10 (A75)
0, 1, 10 (A75)
USB
8*USB3.0 + 10*USB2.0
6*USB3.0 +10*USB2.0
4*USB3.0 + 10*USB2.0
Audio
8-channel HD
8-channel HD
8-channel HD
1394
2*1394a
-
-
LAN
1*GbE
1*GbE
1*GbE
Video Output
HDMI / Dual-link DVI / Display
/ D-Sub
HDMI / Dual-link DVI / D-Sub
HDMI
Features & Software

USB 3.0, SATA 6Gb/s,
3x USB power, 8+2 phase, Ultra Durable, On/Off Charge, All Japanese solid cap, TouchBIOS, 108dB SNR Blu-ray, AMD Dual Graphics / CrossFireX, Dolby, ET6

USB 3.0, SATA 6Gb/s,
3x USB power, 4+1 phase, Ultra Durable, On/Off Charge, All Japanese solid cap, TouchBIOS, 108dB SNR Blu-ray, Dolby, AMD Dual Graphics / CrossFireX, ET6

USB 3.0, SATA 6Gb/s,
3x USB power, 4+1 phase, Ultra Durable, On/Off Charge, All solid capacitors, Touch BIOS, ET6, AMD Dual Graphics / CrossFireX

Form Factor (mm)
ATX (305x244)
ATX (305x225)
ATX (305x225)



Model Name
CPU/APU Support
AMD Fusion APUs (DX11)
AMD AthlonII / Sempron CPUs
AMD Fusion APUs (DX11)
AMD AthlonII / Sempron CPUs
AMD Fusion APUs (DX11)
AMD AthlonII / Sempron CPUs
CPU Socket
AMD Socket FM1
AMD Socket FM1
AMD Socket FM1
Chipset
AMD A75 Chipset
AMD A75 Chipset
AMD A75 Chipset
Graphics Interface
2*PCI-E 2.0 x16 (x16, x4)
2*PCI-E 2.0 x16 (x16, x4)
2*PCI-E 2.0 x16 (x16, x4)
Memory Type
Dual-channel DDR3 2400+/1866/1600/1333
Dual-channel DDR3 2400+/1866/1600/1333
Dual-channel DDR3 2400+/1866/1600/1333
Memory DIMM
4*DDR3 (Max 64GB)
2*DDR3 (Max 32GB)
2*DDR3 (Max 32GB)
Expansion Slots
1*PCI-E 2.0 x1 + 1*PCI
1*PCI-E 2.0 x1 + 1*PCI
1*PCI-E 2.0 x1 + 1*PCI
ATA connector
5*SATA 6Gb/s + 1*eSATA 6Gb/s
6*SATA 6Gb/s
6*SATA 6Gb/s
SATA RAID
0, 1, 10 (A75)
0, 1, 10 (A75)
0, 1, 10 (A75)
USB
4*USB3.0 + 8*USB2.0
4*USB3.0 + 6*USB2.0
4*USB3.0 + 6*USB2.0
Audio
8-channel HD
8-channel HD
8-channel HD
1394
2*1394a
-
-
LAN
1*GbE
1*GbE
1*GbE
Video Output
HDMI / Dual-link DVI / Display
/ D-Sub
HDMI / Dual-link DVI / D-Sub
DVI / D-Sub
Features & Software

USB 3.0, SATA 6Gb/s,
3x USB power, 4+1 phase, Ultra Durable, On/Off Charge, All Japanese solid cap, TouchBIOS, 108dB SNR Blu-ray, AMD Dual Graphics, ET6

USB 3.0, SATA 6Gb/s,
3x USB power, 4+1 phase, Ultra Durable, On/Off Charge, 108dB SNR Blu-ray, All Japanese solid cap, TouchBIOS, AMD Dual Graphics, ET6

USB 3.0, SATA 6Gb/s,
3x USB power, 4+1 phase, Ultra Durable, On/Off Charge, All solid capacitors, Touch BIOS,
108dB SNR Blu-ray,
ET6, AMD Dual Graphics

Form Factor (mm)
mATX (244x244)
mATX (244x225)
mATX (244x210)



Model Name
CPU/APU Support
AMD Fusion APUs (DX11)
AMD AthlonII / Sempron CPUs
AMD Fusion APUs (DX11)
AMD AthlonII / Sempron CPUs
AMD Fusion APUs (DX11)
AMD AthlonII / Sempron CPUs
CPU Socket
AMD Socket FM1
AMD Socket FM1
AMD Socket FM1
Chipset
AMD A75 Chipset
AMD A75 Chipset
AMD A55 Chipset
Graphics Interface
2*PCI-E 2.0 x16 (x16, x4)
1*PCI-E 2.0 x16
2*PCI-E 2.0 x16 (x16, x4)
Memory Type
Dual-channel DDR3 2400+/1866/1600/1333
Dual-channel DDR3 2000+/1866/1600/1333
Dual-channel DDR3 2400+/1866/1600/1333
Memory DIMM
2*DDR3 (Max 32GB)
2*DDR3 (Max 32GB)
4*DDR3 (Max 64GB)
Expansion Slots
1*PCI-E 2.0 x1 + 1*PCI
-
2*PCI-E 2.0 x1 + 3*PCI
ATA connector
4*SATA 6Gb/s
4*SATA 6Gb/s + 1*eSATA
6*SATA 3Gb/s
SATA RAID
0, 1, 10 (A75)
0, 1, 10 (A75)
0, 1, 10 (A55)
USB
4*USB3.0 + 8*USB2.0
4*USB3.0 + 4*USB2.0
14*USB2.0
Audio
8-channel HD
8-channel HD
8-channel HD
1394
-
-
-
LAN
1*GbE
1*GbE
1*GbE
Video Output
DVI / D-sub
HDMI / DVI
HDMI
Features & Software

USB 3.0, SATA 6Gb/s,
3x USB power, 3+1 phase, Ultra Durable, On/Off Charge,
All solid capacitors, Touch BIOS, AMD Dual Graphics, ET6

USB 3.0, SATA 6Gb/s,
3x USB power, 3+1 phase, Ultra Durable, Driver Mosfet, On/Off Charge, All Japanese solid cap, Touch BIOS, 108dB SNR Blu-ray,
Dolby, AMD Dual Graphics, ET6

3x USB power, 4+1 phase, Ultra Durable, On/Off Charge, 108dB SNR Blu-ray, All solid capacitors, Touch BIOS, AMD Dual Graphics / CrossFireX, ET6

Form Factor (mm)
mATX (225x174)
mini-ITX (170x170)
ATX (305x225)



Model Name
CPU/APU Support
AMD Fusion APUs (DX11)
AMD AthlonII / Sempron CPUs
AMD Fusion APUs (DX11)
AMD AthlonII / Sempron CPUs
AMD Fusion APUs (DX11)
AMD AthlonII / Sempron CPUs
CPU Socket
AMD Socket FM1
AMD Socket FM1
AMD Socket FM1
Chipset
AMD A55 Chipset
AMD A55 Chipset
AMD A55 Chipset
Graphics Interface
2*PCI-E 2.0 x16 (x8, x8)
2*PCI-E 2.0 x16 (x16, x4)
2*PCI-E 2.0 x16 (x16, x4)
Memory Type
Dual-channel DDR3 2400+/1866/1600/1333
Dual-channel DDR3 2400+/1866/1600/1333
Dual-channel DDR3 Dual-ch DDR3 2400+/1866/1600/1333
Memory DIMM
2*DDR3 (Max 32GB)
4*DDR3 (Max 64GB)
2*DDR3 (Max 32GB)
Expansion Slots
2*PCI-E 2.0 x1 + 3*PCI
1*PCI-E 2.0 x1 + 1*PCI
1*PCI-E 2.0 x1 + 1*PCI
ATA connector
6*SATA 3Gb/s
6*SATA 3Gb/s
6*SATA 3Gb/s
SATA RAID
0, 1, 10 (A55)
0, 1, 10 (A55)
0, 1, 10 (A55)
USB
14*USB2.0
12*USB2.0
10*USB2.0
Audio
8-channel HD
8-channel HD
8-channel HD
1394
-
-
-
LAN
1*GbE
1*GbE
1*GbE
Video Output
HDMI
HDMI / DVI / D-Sub
HDMI / DVI / D-Sub
Features & Software

4+1 phase, Ultra Durable,
On/Off Charge, All solid capacitors,
Touch BIOS, ET6, AMD Dual Graphics / CrossFireX

3x USB power, 4+1 phase, Ultra Durable, On/Off Charge, 108dB SNR Blu-ray, All solid capacitors, Touch BIOS, AMD Dual Graphics, ET6

3x USB power, 4+1 phase, Ultra Durable, On/Off Charge, 108dB SNR Blu-ray, All solid capacitors, Touch BIOS, AMD Dual Graphics, ET6

Form Factor (mm)
ATX (305x190)
mATX (244x244)
mATX (244x225)



Model Name
CPU/APU Support
AMD Fusion APUs (DX11)
AMD AthlonII / Sempron CPUs
AMD Fusion APUs (DX11)
AMD AthlonII / Sempron CPUs
CPU Socket
AMD Socket FM1
AMD Socket FM1
Chipset
AMD A55 Chipset
AMD A55 Chipset
Graphics Interface
1*PCI-E 2.0 x16
1*PCI-E 2.0 x16
Memory Type
Dual-channel DDR3 2400+/1866+/1600/1333
Dual-channel DDR3
1866+/1600/1333
Memory DIMM
2*DDR3 (Max 32GB)
2*DDR3 (Max 32GB)
Expansion Slots
2*PCI-E 2.0 x1 + 1*PCI
1*PCI-E 2.0 x1 + 1*PCI
ATA connector
6*SATA 3Gb/s
4*SATA 3Gb/s
SATA RAID
0, 1, 10 (A55)
0, 1, 10 (A55)
USB
8*USB2.0
8*USB2.0
Audio
8-channel HD
8-channel HD
1394
-
-
LAN
1*GbE
1*GbE
Video Output
DVI / D-sub
DVI / D-sub
Features & Software

3+1 phase, Ultra Durable, On/Off Charge, All solid capacitors, Touch BIOS, ET6, AMD Dual Graphics

3+1 phase, Ultra Durable,
On/Off Charge, All solid capacitors,
Touch BIOS, ET6, AMD Dual Graphics

Form Factor (mm)
mATX (244x210)
mATX 226x174)


U : 2x copper PCB design       D : All solid capacitor design
* Product features may vary by model.
* Motherboard models may vary based on local distribution.
* Please refer to GIGABYTE website for CPU support information.
