x48

‧ Dynamic Energy Saver Advanced
‧ Ultra Durable 2-Advanced Power design
‧ Extreme Memory Performance with DDR3
‧ Latest Intel 45nm CPU support
‧ PCI-E 2.0 Interface
‧ 2 Gigabit LAN through Teaming
‧ Best Audio Experience
‧ Multi-layer BIOS Protection
‧ Four Sets of External SATA Ports

Designed with Top Quality Highly Efficient Components

‧ Dynamic Energy Saver Advanced
‧ Ultra Durable 2-Advanced Power design
‧ Extreme Memory Performance with DDR2
‧ Latest Intel 45nm CPU support
‧ PCI-E 2.0 Interface
‧ 2 Gigabit LAN through Teaming
‧ Best Audio Experience
‧ Multi-layer BIOS Protection
‧ Four Sets of External SATA Ports

Designed with Top Quality Highly Efficient Components

Designed with Top Quality Highly Efficient Components

Designed with Top Quality Highly Efficient Components

Model	GA-X48T-DQ6	GA-X48-DQ6	GA-X48-DS5	GA-X48-DS4
CPU Support	Intel Core™ 2 Multi-Core / Latest 45nm Processor	Intel Core™ 2 Multi-Core / Latest 45nm Processor	Intel Core™ 2 Multi-Core / Latest 45nm Processor	Intel Core™ 2 Multi-Core / Latest 45nm Processor
CPU Socket	LGA775	LGA775	LGA775	LGA775
FSB	1600/1333/1066/800 MHz	1600/1333/1066/800 MHz	1600/1333/1066/800 MHz	1600/1333/1066/800 MHz
Chipset	Intel X48 + ICH9R	Intel X48 + ICH9R	Intel X48 + ICH9R	Intel X48 + ICH9R
Onboard Graphics	-	-	-	-
Graphics Interface	2*PCI-E 2.0 x16 slot (x16, x16)	2*PCI-E 2.0 x16 slot (x16, x16)	2*PCI-E 2.0 x16 slot (x16, x16)	2*PCI-E 2.0 x16 slot (x16, x16)
Memory	Dual Channel DDR3 2000/1600/1333/1066/800	Dual Channel DDR2 1200/1066/800/667	Dual Channel DDR2 1200/1066/800/667	Dual Channel DDR2 1200/1066/800/667
Memory Socket	4*DDR3	4*DDR2	4*DDR2	4*DDR2
Max Memory	8 GB	8 GB	8 GB	8 GB
Expansion Slots	2PCI + 3PCI-Ex1	2PCI + 3PCI-Ex1	2PCI + 3PCI-Ex1	2PCI + 3PCI-Ex1
ATA connector	8SATA 3Gb/s + 1PATA	8SATA 3Gb/s + 1PATA	8SATA 3Gb/s + 1PATA	6*SATA 3Gb/s
RAID	SATA RAID 0, 1, 5, 10 (ICH9R)/ SATA RAID 0,1,JBOD (GIGABYTE SATA2)	SATA RAID 0, 1, 5, 10 (ICH9R)/ SATA RAID 0,1,JBOD (GIGABYTE SATA2)	SATA RAID 0, 1, 5, 10 (ICH9R)/ SATA RAID 0,1,JBOD (GIGABYTE SATA2)	SATA RAID 0, 1, 5, 10 (ICH9R)
Audio	HD Audio, 8-channel	HD Audio, 8-channel	HD Audio, 8-channel	HD Audio, 8-channel
IEEE 1394	3*IEEE 1394a	3*IEEE 1394a	3*IEEE 1394a	3*IEEE 1394a
USB 2.0	12*USB 2.0	12*USB 2.0	12*USB 2.0	12*USB 2.0
LAN	2*Gigabit LAN	2*Gigabit LAN	2*Gigabit LAN	2*Gigabit LAN
BIOS	Quad BIOS	Quad BIOS	DualBIOS Plus	DualBIOS Plus
Features	DES Advanced Ultra Durable 2 Blu-ray/HD DVD support CrossFireX Quad-Core Optimized Quad Triple Phase Quad eSATA2	DES Advanced Ultra Durable 2 Blu-ray/HD DVD support CrossFireX Quad-Core Optimized Quad Triple Phase Quad eSATA2	DES Advanced Ultra Durable 2 Blu-ray/HD DVD support CrossFireX Quad-Core Optimized Quad Triple Phase SILENT-PIPE Speed, Smart	DES Advanced Ultra Durable2 Blu-ray / HD DVD support CrossFireX Quad-Core Optimized Quad Triple Phase Speed, Smart
Software	Easy Tune 5 pro, Norton Internet Security	Easy Tune 5 Pro, Norton Internet Security	Easy Tune 5 Pro, Norton Internet Security	Easy Tune 5 Pro, Norton Internet Security
Form Factor (mm)	ATX (305x244)	ATX (305x244)	ATX (305x244)	ATX (305x244)

* D : Ultra Durable2 / Ultra Durable Design
* Motherboard models may vary based on local distribution.
* Please refer to GIGABYTE website for CPU support information.
* Norton Internet Security™ includes (1).Norton Anti-Virus™ (2).Norton™ Personal Friewall (3).Norton™ Privacy Control (4).Norton™ AntiSpam (5).Notron™ Parental Control
