**PCIe Gen. 3 este dependent de compatibilitatea CPU şi a cardurilor de expansiune.

Model Intel
GA-H61M-S2P-B3
GA-H61M-S2P-B3 (rev. 1.1)
Suport CPU
2nd Generation Intel Core Processors
2nd Generation Intel Core Processors
2nd Generation Intel Core Processors
Socket CPU
LGA1155
LGA1155
LGA1155
Chipset
Intel H61 chipset
Intel H61 chipset
Intel H61 chipset
Grafică onboard
Intel HD Graphics 2000/3000
Intel HD Graphics 2000/3000
Intel HD Graphics 2000/3000
Interfaţă grafică
1*PCI-E 2.0 x16 slot
1*PCI-E 2.0 x16 slot
1*PCI-E 2.0 x16 slot
RGB
RGB
RGB
Tip memorie
Dual-Channel DDR3 1333/1066/800 MHz
Dual-Channel DDR3 1333/1066/800 MHz
Dual-Channel DDR3
1333/1066/800 MHz
Sloturi memorie
2*DDR3 (Max 16GB)
2*DDR3 (Max 16GB)
2*DDR3 (Max 16GB)
Sloturi expansiune
2*PCI-Ex1 +3*PCI
2*PCI-Ex1
1*PCI-Ex1 +2*PCI
Conector SATA
4*SATA 3Gb/s
4*SATA 3Gb/s
4*SATA 3Gb/s
USB
8*USB2.0
8*USB2.0
8*USB2.0
Audio
8-channel HD
8-channel HD
8-channel HD
LAN
GbE LAN
GbE LAN
GbE LAN
Caracteristici & Software
Ultra Durable 4 classic, VRD12, All solid capacitors, DualBIOS 3TB+ HDD Support, Smart 6, ErP Ready
Ultra Durable 4 classic, VRD12, All solid capacitors, DualBIOS 3TB+ HDD Support, Smart 6, ErP Ready
Ultra Durable 4 classic, VRD12, All solid capacitors, 108dB SNR Blu-ray, DualBIOS 3TB+ HDD Support, Smart 6, ErP Ready
Form Factor (mm)
mATX (305x190)
mATX (227x174)
mATX (244x200)



Model Intel
GA-H61M-S2H (rev. 1.3)
GA-H61M-S2H (rev. 1.3)
GA-P61-S3-B3_v1.1
GA-P61-S3-B3 (rev. 1.1)
GA-P61-S3P
GA-P61-S3P (rev. 1.0)
Suport CPU
2nd Generation Intel Core Processors
2nd Generation Intel Core Processors
2nd Generation Intel Core Processors
Socket CPU
LGA1155
LGA1155
LGA1155
Chipset
Intel H61 chipset
Intel H61 chipset
Intel H61 chipset
Grafică onboard
Intel HD Graphics 2000/3000
-
-
Interfaţă grafică
1*PCI-E 2.0 x16 slot
1*PCI-E 2.0 x16 slot
1*PCI-E 2.0 x16 slot
RGB/DVI-D/HDMI
-
-
Tip memorie
Dual-Channel DDR3
1333/1066/800 MHz
Dual-Channel DDR3 1333/1066/800 MHz
Dual-Channel DDR3
1333/1066/800 MHz
Sloturi memorie
2*DDR3 (Max 16GB)
2*DDR3 (Max 16GB)
2*DDR3 (Max 16GB)
Sloturi expansiune
2*PCI-Ex1 +1*PCI
2*PCI-Ex1 +3*PCI
2*PCI-Ex1 +3*PCI
Conector SATA
4*SATA 3Gb/s
4*SATA 3Gb/s
4*SATA 3Gb/s
USB
8*USB2.0
8*USB2.0
8*USB2.0
Audio
8-channel HD
8-channel HD
8-channel HD
LAN
GbE LAN
GbE LAN
GbE LAN
Caracteristici & Software
Ultra Durable 4 classic, VRD12, All solid capacitors, 108dB SNR Blu-ray, DualBIOS 3TB+ HDD Support, Smart 6, ErP Ready
Ultra Durable 4 classic, VRD12, All solid capacitors, DualBIOS 3TB+ HDD Support, Smart 6, ErP Ready
Ultra Durable 4 classic, VRD12, All solid capacitors, DualBIOS 3TB+ HDD Support, Smart 6, ErP Ready
Form Factor (mm)
mATX (244x205)
mATX (305x190)
mATX (305x190)


D : Design cu condensatori solizi
* Caracteristicile produsului pot varia în funcţie de model.
* Modelele de plăci de bază pot varia în funcţie de distribuţia locală.
* Vizitaţi site-ul GIGABYTE pentru informaţii despre suportul CPU.
