  Lower
Temperature
Better
Overclocking
Better Power
Efficiency
2X Lower
Impedance
Lower EMI Better ESD
Protection

2X Lower Impedance


2X Lower
Impedance

In addition, doubling the amount of copper lowers the PCB impedance by 50%. Impedance is a measure of how much the circuit impedes the flow of current. The less the flow of current is impeded, the less amount of energy is wasted. For GIGABYTE Ultra Durable 3 motherboards, this means total PCB electrical waste is reduced by 50%, which also means less heat is generated. 2 ounces of copper also provides improved signal quality, providing better system stability and allowing greater margins for overclocking.


Impedance Ω
  Lower is better
  Lower


2 oz Copper PCB


1 oz Copper PCB


  Electron
  Electron


TOP
