‧ Dynamic Energy Saver
‧ Ultra Durable 2-Advanced Power design
‧ Extreme Memory Performance with DDR3
‧ Latest Intel 45nm CPU support
‧ PCI-E 2.0 Interface
‧ 2 Gigabit LAN through Teaming
‧ Best Audio Experience
‧ Multi-layer BIOS Protection
‧ Four Sets of External SATA Ports

Designed with Top Quality Highly Efficient Components




‧ Dynamic Energy Saver
‧ Ultra Durable 2-Advanced Power design
‧ Extreme Memory Performance with DDR2
‧ Latest Intel 45nm CPU support
‧ PCI-E 2.0 Interface
‧ 2 Gigabit LAN through Teaming
‧ Best Audio Experience
‧ Multi-layer BIOS Protection
‧ Four Sets of External SATA Ports


Designed with Top Quality Highly Efficient Components



‧ Dynamic Energy Saver
‧ Ultra Durable 2-Advanced Power design
‧ Extreme Memory Performance with DDR2
‧ Latest Intel 45nm CPU support
‧ PCI-E 2.0 Interface
‧ 2 Gigabit LAN through Teaming
‧ Best Audio Experience
‧ Multi-layer BIOS Protection
‧ Two Sets of External SATA Ports


Designed with Top Quality Highly Efficient Components


Model
GA-X48T-DQ6
GA-X48-DS5
CPU Support
Intel Core™ 2 Multi-Core /
Latest 45nm Processor
Intel Core™ 2 Multi-Core /
Latest 45nm Processor
Intel Core™ 2 Multi-Core /
Latest 45nm Processor
CPU Socket
LGA775
LGA775
LGA775
FSB
1600/1333/1066/800 MHz
1600/1333/1066/800 MHz
1600/1333/1066/800 MHz
Chipset
Intel X48 + ICH9R
Intel X48 + ICH9R
Intel X48 + ICH9R
Onboard Graphics
-
-
-
Graphics Interface
2*PCI-E 2.0 x16 slot (x16, x16)
2*PCI-E 2.0 x16 slot (x16, x16)
2*PCI-E 2.0 x16 slot (x16, x16)
Memory
Dual Channel DDR3
1900/1600/1333/1066/800
Dual Channel DDR2
1200/1066/800/667
Dual Channel DDR2
1200/1066/800/667
Memory Socket
4*DDR3
4*DDR2
4*DDR2
Max Memory
8 GB
8 GB
8 GB
Expansion Slots
2*PCI + 3*PCI-Ex1
2*PCI + 3*PCI-Ex1
2*PCI + 3*PCI-Ex1
ATA connector
8*SATA 3Gb/s + 1*PATA
8*SATA 3Gb/s + 1*PATA
8*SATA 3Gb/s + 1*PATA
RAID
SATA RAID 0, 1, 5, 10 (ICH9R)/
SATA RAID 0,1,JBOD
(GIGABYTE SATA2)
SATA RAID 0, 1, 5, 10 (ICH9R)/
SATA RAID 0,1,JBOD
(GIGABYTE SATA2)
SATA RAID 0, 1, 5, 10 (ICH9R)/
SATA RAID 0,1,JBOD
(GIGABYTE SATA2)
Audio
HD Audio, 8-channel
HD Audio, 8-channel
HD Audio, 8-channel
IEEE 1394
3*IEEE 1394a
3*IEEE 1394a
3*IEEE 1394a
USB 2.0
12*USB 2.0
12*USB 2.0
12*USB 2.0
LAN
2*Gigabit LAN
2*Gigabit LAN
2*Gigabit LAN
BIOS
Quad BIOS
Quad BIOS
DualBIOS Plus
Features
Dynamic Energy Saver
Ultra Durable 2
Blu-ray/HD DVD support
CrossFireX
Quad-Core Optimized
Quad Triple Phase
Quad eSATA2
Dynamic Energy Saver
Ultra Durable 2
Blu-ray/HD DVD support
CrossFireX
Quad-Core Optimized
Quad Triple Phase
Quad eSATA2
Dynamic Energy Saver
Ultra Durable 2
Blu-ray/HD DVD support
CrossFireX
Quad-Core Optimized
Quad Triple Phase
SILENT-PIPE
Speed, Smart
Software
Easy Tune 5 pro,
Norton Internet Security
Easy Tune 5 Pro,
Norton Internet Security
Easy Tune 5 Pro,
Norton Internet Security
Form Factor (mm)
ATX (305x244)
ATX (305x244)
ATX (305x244)

* D : Thiết kế Ultra Durable2 / Ultra Durable
* Model bo mạch chủ có thể khác nhau tùy theo nhà phân phối.
* Vui lòng tham khảo website GIGABYTE để biết thêm thông tin CPU hỗ trợ.
* Norton Internet Security™ includes (1).Norton Anti-VirusTM (2).Norton™ Personal Friewall (3).Norton™ Privacy Control (4).Norton™ AntiSpam (5).Notron™ Parental Control
