Intel – P55A Series
AMD – 700A Series



GA-790FXTA-UD5 GA-790XTA-UD4 GA-770TA-UD3



Model
GA-790FXTA-UD5
GA-790FXTA-UD5
GA-790XTA-UD4
GA-790XTA-UD4
GA-770TA-UD3
GA-770TA-UD3
CPU Support
AMD AM3 PhenomII/ AthlonII Processors
AMD AM3 PhenomII/ AthlonII Processors
AMD AM3 PhenomII/ AthlonII Processors
CPU Socket
Socket AM3
Socket AM3
Socket AM3
QPI/FSB
HT3.0 (5200MT/s)
HT3.0 (5200MT/s)
HT3.0 (5200MT/s)
Chipset
AMD 790FX + SB750
AMD 790X + SB750
AMD 770 + SB710
Onboard Graphics
-
-
-
Graphics Interface
3*PCI-E 2.0 x16 slot
(x16, x16 or x16, x8, x8)
2*PCI-E 2.0 x16 slot
(x16 or x8, x8)
1*PCI-E 2.0 x16 slot
Memory
Dual Channel DDR3 1866+/1333/1066
Dual Channel DDR3 1866+/1333/1066
Dual Channel DDR3 1866+/1333/1066
Memory Socket
4*DDR3 (Max 16 GB)
4*DDR3 (Max 16 GB)
4*DDR3 (Max 16 GB)
Expansion Slots
3*PCI + 1*PCI-Ex1
3*PCI + 2*PCI-Ex1
4*PCI + 2*PCI-Ex1
SATA connector
2*SATA 6Gb/s
2*SATA 6Gb/s
2*SATA 6Gb/s
8*SATA 3Gb/s (2* eSATA/ USB Combo) + 1*PATA
8*SATA 3Gb/s (2* eSATA) + 1*PATA
8*SATA 3Gb/s (2* eSATA) + 1*PATA
RAID
SATA 6Gb/s RAID 0
SATA 6Gb/s RAID 0
SATA 6Gb/s RAID 0
SATA 3Gb/s RAID 0, 1, 5, 10
SATA 3Gb/s RAID 0, 1, 5, 10
SATA 3Gb/s RAID 0, 1, 10
Audio
HD Audio, 8-channel
HD Audio, 8-channel
HD Audio, 8-channel
IEEE 1394
3*IEEE 1394a
3*IEEE 1394a
3*IEEE 1394a
USB 2.0
10*USB 2.0, 2*USB 3.0
10*USB 2.0, 2*USB 3.0
10*USB 2.0, 2*USB 3.0
LAN
Dual Gigabit LAN
Gigabit LAN
Gigabit LAN
BIOS
Smart DualBIOS
Smart DualBIOS
Smart DualBIOS
Features
USB 3.0, SATA 6Gb/s, 3x USB power, 8+2 phase power, Ultra Durable 3, Easy Energy Saver, ACC support, ATI CrossFireX, Dolby Home Theater, Precision OV, eSATA/ USB combo, Smart DualLAN, Onboard Quick Switches
USB 3.0, SATA 6Gb/s, 3x USB power, 8+2 phase power, Ultra Durable 3, Easy Energy Saver, ACC support, ATI CrossFireX, Dolby Home Theater, Precision OV
USB 3.0, SATA 6Gb/s, 3x USB power, 8+2 phase power, Ultra Durable 3, Easy Energy Saver, ACC support, Precision OV
Software
EasyTune 6
EasyTune 6
EasyTune 6
Form Factor (mm)
ATX (305x244)
ATX (305x244)
ATX (305x230)




Norton™ Internet Security
Fast, comprehensive, and up-to-the-minute protection against online threats. It safeguards your computer, identity, and home network without slowing you down.
It sets a new standard for speed and makes online shopping, banking, and browsing safer and more convenient than ever.



  U : 2 oz copper PCB design D : All solid capacitor design
*Product features may vary by model. *Motherboard models may vary based on local distribution.
*Please refer to GIGABYTE website for CPU support information.
