| Model |
GA-P55-UD6 |
GA-P55-UD5 |
GA-P55-UD4P |
GA-P55-UD4 |
GA-P55-UD3P
|
| CPU |
Intel Core i7/ Core i5 Processors |
Intel Core i7/ Core i5 Processors |
Intel Core i7/ Core i5 Processors |
Intel Core i7/ Core i5 Processors |
Intel Core i7/ Core i5 Processors |
| Socket CPU |
LGA1156 |
LGA1156 |
LGA1156 |
LGA1156 |
LGA1156 |
| QPI/FSB |
- |
- |
- |
- |
- |
| Chipset |
Intel P55 |
Intel P55 |
Intel P55 |
Intel P55 |
Intel P55 |
| Grafică onboard |
- |
- |
- |
- |
- |
| Interfață grafică |
3*PCI-E 2.0 x16 slot
(x16, x8, x4) |
3*PCI-E 2.0 x16 slot
(x16, x8, x4) |
2*PCI-E 2.0 x16 slot
(x16, x8) |
2*PCI-E 2.0 x16 slot
(x16, x8) |
2*PCI-E 2.0 x16 slot
(x16, x4) |
| Memorie |
Dual Channel DDR3 2200/1333/1066/800 |
Dual Channel DDR3 2200/1333/1066/800 |
Dual Channel DDR3 2200/1333/1066/800 |
Dual Channel DDR3 2200/1333/1066/800 |
Dual Channel DDR3 2200/1333/1066/800 |
| Socket memorie |
6*DDR3 (Max 16 GB) |
4*DDR3 (Max 16 GB)
|
4*DDR3 (Max 16 GB)
|
4*DDR3 (Max 16 GB)
|
4*DDR3 (Max 16 GB)
|
| Sloturi expansiune |
2*PCI + 2*PCI-Ex1 |
2*PCI + 2*PCI-Ex1 |
2*PCI + 3*PCI-Ex1
|
2*PCI + 3*PCI-Ex1
|
4*PCI +1*PCI-Ex1
|
| Conector ATA |
12*SATA 3Gb/s + 1*PATA |
12*SATA 3Gb/s + 1*PATA |
10*SATA 3Gb/s +2*e-SATA 3Gb/s + 1*PATA
|
10*SATA 3Gb/s +2*e-SATA 3Gb/s + 1*PATA
|
10*SATA 3Gb/s +2*e-SATA 3Gb/s + 1*PATA
|
RAID
|
SATA 3Gb RAID 0, 1, 5, 10 |
SATA 3Gb RAID 0, 1, 5, 10 |
SATA 3Gb RAID 0, 1, 5, 10 |
SATA 3Gb RAID 0, 1, 5, 10 |
SATA 3Gb RAID 0, 1, 5, 10 |
| Audio |
HD Audio, 8-channel |
HD Audio, 8-channel |
HD Audio, 8-channel |
HD Audio, 8-channel |
HD Audio, 8-channel |
| IEEE 1394 |
3*IEEE 1394a |
3*IEEE 1394a |
3*IEEE 1394a |
3*IEEE 1394a |
- |
| USB 2.0 |
14*USB 2.0 |
14*USB 2.0 |
14*USB 2.0 |
14*USB 2.0 |
14*USB 2.0 |
| LAN |
Dual Gigabit LAN |
Dual Gigabit LAN |
Dual Gigabit LAN |
Gigabit LAN
|
Gigabit LAN
|
| BIOS |
Smart DualBIOS |
Smart DualBIOS |
Smart DualBIOS |
Smart DualBIOS |
Smart DualBIOS |
| Caracteristici |
24 phase power, Ultra Durable 3, Dynamic Energy Saver 2,
Smart TPM, ATI CrossFireX,
SLI, Debug LED, Dolby Home Theater, Precision OV,
eSATA/ USB combo |
12 phase power, Ultra Durable 3, Dynamic Energy Saver 2,
Smart TPM, ATI CrossFireX,
SLI, Dolby Home Theater,
Precision OV,
eSATA/ USB combo
|
Ultra Durable 3,
Dynamic Energy Saver 2,
Smart TPM,
ATI CrossFireX,
SLI, Dolby Home Theater,
Precision OV |
Ultra Durable 3,
Dynamic Energy Saver 2,
ATI CrossFireX,
SLI, Precision OV |
Ultra Durable 3,
Dynamic Energy Saver 2,
Smart TPM,
ATI CrossFireX, Precision OV
|
| Software |
Smart 6, XHD, EasyTune 6 |
Smart 6, XHD, EasyTune 6 |
Smart 6, XHD, EasyTune 6 |
Smart 6, XHD, EasyTune 6 |
Smart 6, XHD, EasyTune 6 |
| Form Factor (mm) |
ATX (305x244) |
ATX (305x244) |
ATX (305x244) |
ATX (305x244) |
ATX (305x244) |
|
|
| |
|
|
| |
| Model |
GA-P55-UD3R
|
GA-P55-UD3
|
GA-P55-UD3L |
GA-P55-US3L
|
GA-P55M-UD4
|
| CPU |
Intel Core i7/ Core i5 Processors |
Intel Core i7/ Core i5 Processors |
Intel Core i7/ Core i5 Processors |
Intel Core i7/ Core i5 Processors |
Intel Core i7/ Core i5 Processors |
| Socket CPU |
LGA1156 |
LGA1156 |
LGA1156 |
LGA1156 |
LGA1156 |
| QPI/FSB |
- |
- |
- |
- |
- |
| Chipset |
Intel P55 |
Intel P55 |
Intel P55 |
Intel P55 |
Intel P55 |
| Grafică onboard |
- |
- |
- |
- |
- |
| Interfață grafică |
2*PCI-E 2.0 x16 slot
(x16, x4) |
2*PCI-E 2.0 x16 slot
(x16, x4) |
2*PCI-E 2.0 x16 slot
(x16, x4) |
2*PCI-E 2.0 x16 slot
(x16, x4) |
2*PCI-E 2.0 x16 slot
(x16, x8) |
| Memorie |
Dual Channel DDR3 2200/1333/1066/800 |
Dual Channel DDR3 2200/1333/1066/800 |
Dual Channel DDR3 2200/1333/1066/800 |
Dual Channel DDR3 2200/1333/1066/800 |
Dual Channel DDR3 2200/1333/1066/800 |
| Socket memorie |
4*DDR3 (Max 16 GB)
|
4*DDR3 (Max 16 GB)
|
4*DDR3 (Max 16 GB)
|
4*DDR3 (Max 16 GB)
|
4*DDR3 (Max 16 GB)
|
| Sloturi expansiune |
4*PCI +1*PCI-Ex1
|
3*PCI +2*PCI-Ex1
|
4*PCI + 1*PCI-Ex1
|
4*PCI + 1*PCI-Ex1
|
1*PCI + 1*PCI-Ex4
|
| Conector ATA |
10*SATA 3Gb/s +2*e-SATA 3Gb/s + 1*PATA
|
8*SATA 3Gb/s + 1*PATA
|
8*SATA 3Gb/s + 1*PATA
|
6*SATA 3Gb/s + 1*PATA
|
8*SATA 3Gb/s + 1*PATA
|
RAID
|
SATA 3Gb RAID 0, 1, 5, 10 |
SATA 3Gb RAID 0, 1, 5, 10 |
SATA 3Gb RAID 0, 1, 5, 10 |
SATA 3Gb RAID 0, 1, 5, 10 |
SATA 3Gb RAID 0, 1, 5, 10 |
| Audio |
HD Audio, 8-channel |
HD Audio, 8-channel |
HD Audio, 8-channel |
HD Audio, 8-channel |
HD Audio, 8-channel |
| IEEE 1394 |
-
|
-
|
-
|
-
|
2*IEEE 1394a
|
| USB 2.0 |
14*USB 2.0 |
14*USB 2.0 |
14*USB 2.0 |
14*USB 2.0 |
14*USB 2.0 |
| LAN |
Gigabit LAN
|
Gigabit LAN
|
Gigabit LAN
|
Gigabit LAN
|
Gigabit LAN
|
| BIOS |
Smart DualBIOS |
Smart DualBIOS |
Smart DualBIOS |
Smart DualBIOS |
Smart DualBIOS |
| Caracteristici |
Ultra Durable 3,
Dynamic Energy Saver 2,
ATI CrossFireX,
Precision OV |
Ultra Durable 3,
Dynamic Energy Saver 2,
ATI CrossFireX,
Precision OV |
Ultra Durable 3 Classic,
Dynamic Energy Saver 2,
ATI CrossFireX,
Precision OV |
Ultra Durable 3 Classic,
Solid capacitors for CPU VRM,
Dynamic Energy Saver 2,
ATI CrossFireX,
Precision OV |
12 phase power,
Ultra Durable 3,
Dynamic Energy Saver 2, ATI CrossFireX, SLI,
Dolby Home Theater,
Precision OV,
eSATA/ USB combo |
| Software |
Smart 6, XHD, EasyTune 6 |
Smart 6, XHD, EasyTune 6 |
Smart 6, XHD, EasyTune 6 |
Smart 6, XHD, EasyTune 6 |
Smart 6, XHD, EasyTune 6 |
| Form Factor (mm) |
ATX (305x244) |
ATX (305x244) |
ATX (305x244) |
ATX (305x244) |
Micro ATX (244x244)
|
|
|
| |
|
|
| |
| Model |
GA-P55M-UD2 |
|
| CPU |
Intel Core i7/ Core i5 Processors |
| Socket CPU |
LGA1156 |
| QPI/FSB |
- |
| Chipset |
Intel P55 |
| Grafică onboard |
- |
| Interfață grafică |
2*PCI-E 2.0 x16 slot
(x16, x4) |
| Memorie |
Dual Channel DDR3 2200/1333/1066/800 |
| Socket memorie |
4*DDR3 (Max 16 GB)
|
| Sloturi expansiune |
2*PCI
|
| Conector ATA |
7*SATA 3Gb/s +1*e-SATA3Gb/s + 1*PATA
|
RAID
|
SATA 3Gb RAID 0, 1, 5, 10 |
| Audio |
HD Audio, 8-channel |
| IEEE 1394 |
3*IEEE 1394a |
| USB 2.0 |
14*USB 2.0 |
| LAN |
Gigabit LAN
|
| BIOS |
Smart DualBIOS |
| Caracteristici |
Ultra Durable 3,
Dynamic Energy Saver 2,
ATI CrossFireX,
Precision OV |
| Software |
Smart 6, XHD, EasyTune 6 |
| Form Factor (mm) |
Micro ATX (244x244)
|
|
|
| |
|
|
| |
 |
Norton™ Internet Security
Fast, comprehensive, and up-to-the-minute protection against online threats. It safeguards your computer, identity, and home network without slowing you down.
It sets a new standard for speed and makes online shopping, banking, and browsing safer and more convenient than ever. |
|
|
| |
|
|
| |
U : Design PCB cu 2 oz cupru D : Design cu condensatori solizi
*Caracteristicile produselor pot varia în funcție de model. *Modelele plăcilor de bază pot varia în funcție de distribuția locală.
*Vizitați websote-ul GIGABYTE pentru mai multe informații despre suportul CPU.
Toate materialele prezentate aici sunt doar pentru referință. GIGABYTE își rezervă dreptul de a modifica sau revizui conținutul oricând fără notificare prealabilă. |
|
| |
|
|
| |
|
|
