QBiX-WP-WHLA8265H-A1

IP67 - Industrial water proof system with Intel® Core™ i5-8265U Processor

System Size : 188W x 155D x 72H (mm)
Intel® Core™ i5-8265U Processor
Dual Channel DDR4, 2 x SO-DIMMs
IP67 water proof certification
M12 and IP67 water proof connectors

sales@gigaipc.com

Request a Quote

Compare

1/4

Designed for Harsh Environment

IP-67 Rugged Embedded System for harsh conditions, such as in chemical, mining industry, food and beverage factory, outdoor digital signage and automation/robotic control where the systems are in constant threat of water splash and dust immersion. It offers IP67-rated protection with waterproof and dustproof capability in -20°C to 80°C wide range of operating temperatures and +9-36V wide range DC input with various power protection. The hermetic and rugged enclosure of extruded aluminum protects the system from corrosion and M12 connectors and specialized molded o-rings secure the cable connectivity.
8th Generation Intel® Core™ Processor

Intel's blazing fast, feature packed processor family with built-in security is ready to take your productivity, and creativity to the next level. And, by enabling new exciting Windows 10 features, the 8th generation Intel Core processors empower you to unleash your imagination and explore the possibilities.
Dual Gigabit LAN

Experience the flexibility and convenience of the integrated Dual Lan function.
M.2 Onboard Connector

Providing users PCI-Express connectivity for SSD devices. Delivering up to 10 Gbps data transfer speeds, M.2 offers users considerably faster storage performance than current mSATA and even SATA Revision 3 6Gbps storage devices.
HDMI™-The Next Generation Multimedia Interface

HDMI™ is a High-Definition Multimedia Interface which provides up to 5Gb/s video transmitting bandwidth and 8-channel high quality audio all through a single cable. Able to transmit superior, uncompressed digital video and audio, HDMI™ ensures the crispest rendering of digital content up to 1080p without the quality losses associated with analog interfaces and their digital-to-analog conversion. In addition, HDMI™ is compatible with HDCP (High-bandwidth Digital Content Protection), allowing the playback of Blu-ray/HD DVD and other protected media content.
2.5" SATA Hard Drive Support

Utilizing SATA III 6Gb/s high speed data transfer technology, the xxx supports the installation of one 2.5” SATA hard drive and one mSATA SSD module. This allows for optimized storage configurations which combine fast SSD performance with larger capacity hard drives.

* The entire materials provided herein are for reference only. GIGABYTE reserves the right to modify or revise the content at anytime without prior notice.
* Advertised performance is based on maximum theoretical interface values from respective Chipset vendors or organization who defined the interface specification. Actual performance may vary by system configuration.
* All trademarks and logos are the properties of their respective holders.
* Due to standard PC architecture, a certain amount of memory is reserved for system usage and therefore the actual memory size is less than the stated amount.

SPECIFICATIONS

CPU

Intel® Core™ i5-8265U Processor
14nm, 4 cores, 8 threads, up to 3.9 GHz
TDP 15W

Chipset

SoC

Memory

2 x DDR4 SO-DIMM sockets, Max. Capacity 64 GB
Support Dual Channel DDR4 2400 MHz memory modules
(Integrated 8GB memory)

LAN

2 x GbE LAN Ports (Intel® I219V and Intel® I211AT)

Video

Integrated Graphics Processor - Intel® UHD Graphics 620:
1 x HDMI 1.4 port, supporting a maximum resolution of 4096x2160 @30Hz

Audio

Realtek ALC269
High Definition Audio

Expansion Slots

1 x 2280 M.2 M-Key (PCIe x4, SATA 6Gb/s)
1 x 2230 M.2 E-Key (WiFi/BT)
1 x Full-size Mini PCIe with SIM slot (PCIe x1 + USB2.0) -- support 3G/4G module
(Integrated M.2 SSD 256GB)

Rear I/O

1 x (M12) COM port (RS-232/422/485 and RI/5V/12V)
2 x (M12) COM port (RS-232)
1 x (M12) GPIO (8 bits)
1 x (M12) DC Jack

OS Supported

Windows 10 / Linux

Power Supply

+9~36VDC (Full Range)

Packaging Content

Carton size: 305 x 285 x 265 (mm)
Packing Capacity: 1pc

Including:
CABLE COM, waterproof, x 3 (P/N: 25CF8-1K8400-O0S)
CABLE USB 2.0, waterproof, x 2 (P/N: 25CFA-1K8000-O0R)
CABLE RJ45, waterproof, x 2 (P/N: 25CR0-1K8401-O0S)
CABLE SIGNAL, waterproof, x 1 (P/N: 25CR5-1K8500-O0R)
CABLE HDMI, waterproof, x 1 (P/N: 25CRC-180720-O0S)
CABLE DC JACK, waterproof, x 1 (P/N: 25CRD-1K8300-O0S)
Wall mount bracket (P/N: 25HBA-826520-H5R)

Ordering Information

9BQW8265AMR-SI (Box packing)

(Built in Components: Please contact with your sales representative for more information or e-mailed to : sales@gigaipc.com)

Storage

1 x 2.5” HDD/SSD (SATA 6Gb/s)

Front I/O

2 x (M12) LAN ports
2 x (IP67) USB 2.0 connector
1 x (IP67) HDMI connector
1 x (IP67) Power switch
1 x (M8) Power button with LED
1 x (M8) HDD LED

Dimension

188W x 155D x 72H(mm)
