GIGABYTE 333 Onboard Acceleration

Modèles

Séries Intel – P55A

	GA-P55A-UD7	GA-P55A-UD6	GA-P55A-UD5	GA-P55A-UD4P	GA-P55A-UD4	GA-P55A-UD3P	GA-P55A-UD3R
	GA-P55A-UD3

Référence	GA-P55A-UD7	GA-P55A-UD6	GA-P55A-UD5	GA-P55A-UD4P
Support CPU	Intel Core i7/ Core i5	Intel Core i7/ Core i5	Intel Core i7/ Core i5	Intel Core i7/ Core i5
Socket	LGA1156	LGA1156	LGA1156	LGA1156
QPI/FSB	-	-	-	-
Chipset	Intel P55	Intel P55	Intel P55	Intel P55
VGA intégré	-	-	-	-
Interfaces	4*PCI-E 2.0 x16 slot (2x16, 4x8)	3*PCI-E 2.0 x16 slot (x16, x8, x4)	3*PCI-E 2.0 x16 slot (x16, x8, x4)	2*PCI-E 2.0 x16 slot (x16, x8)
Mémoires	Dual Channel DDR3 2600+/2200/1333/1066/800	Dual Channel DDR3 2600+/2200/1333/1066/800	Dual Channel DDR3 2600+/2200/1333/1066/800	Dual Channel DDR3 2200/1333/1066/800
Socket mémoire	4*DDR3 (Max 16 GB)	6*DDR3 (Max 16 GB)	4*DDR3 (Max 16 GB)	4*DDR3 (Max 16 GB)
Slots	2PCI + 1PCI-Ex1	2PCI + 2PCI-Ex1	2PCI + 2PCI-Ex1	2PCI + 3PCI-Ex1
ATA	8SATA 3Gb/s + 2SATA 6Gb/s + 1*PATA	2SATA 6Gb/s 10SATA 3Gb/s + 1*PATA	2SATA 6Gb/s 10SATA 3Gb/s + 1*PATA	2SATA 6Gb/s 8SATA 3Gb/s + 1*PATA
RAID	SATA 6Gb RAID 0 SATA 3Gb RAID 0, 1, 5, 10	SATA 6Gb RAID 0 SATA 3Gb RAID 0, 1, 5, 10	SATA 6Gb RAID 0 SATA 3Gb RAID 0, 1, 5, 10	SATA 6Gb RAID 0 SATA 3Gb RAID 0, 1, 5, 10
Audio	HD Audio, 8-channel	HD Audio, 8-channel	HD Audio, 8-channel	HD Audio, 8-channel
IEEE 1394	3*IEEE 1394a	3*IEEE 1394a	3*IEEE 1394a	3*IEEE 1394a
USB	12USB 2.0 2USB 3.0	12USB 2.0 2USB 3.0	12USB 2.0 2USB 3.0	12USB 2.0 2USB 3.0
LAN	Dual Gigabit LAN	Dual Gigabit LAN	Dual Gigabit LAN	Dual Gigabit LAN
BIOS	Smart DualBIOS	Smart DualBIOS	Smart DualBIOS	Smart DualBIOS
Innovations	USB 3.0, USB 3x power , SATA 6Gb/s, 24 phase, Smart6,Ultra Durable 3, Dynamic Energy Saver 2, 3 Way SLI, ATI CrossFireX, Dolby Home Theater, Precision OV, Debug LED, Hybrid Silent Pipe, EuP Ready	USB 3.0, SATA 6Gb/s, 3x USB power, 24 phase power, Ultra Durable 3, Dynamic Energy Saver 2, Smart TPM, ATI CrossFireX, SLI, Debug LED, Dolby Home Theater, Precision OV, eSATA/ USB combo	USB 3.0, SATA 6Gb/s, 3x USB power, 12 phase power, Ultra Durable 3, Dynamic Energy Saver 2, Smart TPM, ATI CrossFireX, SLI, Dolby Home Theater, Precision OV, eSATA/ USB combo	USB 3.0, SATA 6Gb/s, 3x USB power, Ultra Durable 3, Dynamic Energy Saver 2, Smart TPM, ATI CrossFireX, SLI, Dolby Home Theater, Precision OV
Logiciels	Smart 6, XHD, EasyTune 6	Smart 6, XHD, EasyTune 6	Smart 6, XHD, EasyTune 6	Smart 6, XHD, EasyTune 6
Form Factor (mm)	ATX (305x244)	ATX (305x244)	ATX (305x244)	ATX (305x244)

Référence	GA-P55A-UD4	GA-P55A-UD3P	GA-P55A-UD3R	GA-P55A-UD3
Support CPU	Intel Core i7/ Core i5	Intel Core i7/ Core i5	Intel Core i7/ Core i5	Intel Core i7/ Core i5
Socket	LGA1156	LGA1156	LGA1156	LGA1156
QPI/FSB	-	-	-	-
Chipset	Intel P55	Intel P55	Intel P55	Intel P55
VGA intégré	-	-	-	-
Interfaces	2*PCI-E 2.0 x16 slot (x16, x8)	1PCI-E 2.0 x16+ 1PCI-E x4	1PCI-E 2.0 x16+ 1PCI-E x4	1PCI-E 2.0 x16+ 1PCI-E x4
Mémoires	Dual Channel DDR3 2200/1333/1066/800	Dual Channel DDR3 2200/1333/1066/800	Dual Channel DDR3 2200/1333/1066/800	Dual Channel DDR3 2200/1333/1066/800
Socket mémoire	4*DDR3 (Max 16 GB)	4*DDR3 (Max 16 GB)	4*DDR3 (Max 16 GB)	4*DDR3 (Max 16 GB)
Slots	2PCI + 3PCI-Ex1	3PCI +2PCI-Ex1	3PCI + 2PCI-Ex1	3PCI + 2PCI-Ex1
ATA	2SATA 6Gb/s 8SATA 3Gb/s + 1*PATA	2SATA 6Gb/s 8SATA 3Gb/s + 1*PATA	2SATA 6Gb/s 8SATA 3Gb/s + 1*PATA	2SATA 6Gb/s 6SATA 3Gb/s + 1*PATA
RAID	SATA 6Gb RAID 0 SATA 3Gb RAID 0, 1, 5, 10	SATA 6Gb RAID 0 SATA 3Gb RAID 0, 1, 5, 10	SATA 6Gb RAID 0 SATA 3Gb RAID 0, 1, 5, 10	SATA 6Gb RAID 0 SATA 3Gb RAID 0, 1, 5, 10
Audio	HD Audio, 8-channel	HD Audio, 8-channel	HD Audio, 8-channel	HD Audio, 8-channel
IEEE 1394	3*IEEE 1394a	-	-	-
USB	12USB 2.0 2USB 3.0	12USB 2.0 2USB 3.0	12USB 2.0 2USB 3.0	12USB 2.0 2USB 3.0
LAN	Gigabit LAN	Gigabit LAN	Gigabit LAN	Gigabit LAN
BIOS	Smart DualBIOS	Smart DualBIOS	Smart DualBIOS	Smart DualBIOS
Innovations	USB 3.0, SATA 6Gb/s, 3x USB power, Ultra Durable 3, Dynamic Energy Saver 2, ATI CrossFireX, Dolby Home Theater, SLI, Precision OV	USB 3.0, SATA 6Gb/s, 3x USB power, Ultra Durable 3, Dynamic Energy Saver 2, Smart TPM, ATI CrossFireX, Dolby Home Theater, Precision OV	USB 3.0, SATA 6Gb/s, 3x USB power, Ultra Durable 3, Dynamic Energy Saver 2, ATI CrossFireX, Dolby Home Theater, Precision OV	USB 3.0, SATA 6Gb/s, 3x USB power, Ultra Durable 3, Dynamic Energy Saver 2, ATI CrossFireX, Precision OV
Logiciels	Smart 6, XHD, EasyTune 6	Smart 6, XHD, EasyTune 6	Smart 6, XHD, EasyTune 6	Smart 6, XHD, EasyTune 6
Form Factor (mm)	ATX (305x244)	ATX (305x244)	ATX (305x244)	ATX (305x244)

Norton™ Internet Security
Logiciel de protection en temps réel contre les attaques virales diffusées par internet

U : Design à 2 onces de cuivre D : 100% condensateurs solides
*Caractéristiques produits pouvant varier selon votre pays.
GIGABYTE se réserve le droit de modifier chacune de ces informations sans préavis.
