Intel – X58A Series
Intel – P55A Series

  GA-X58A-UD7 GA-X58A-UD5 GA-X58A-UD3R


Référence
GA-X58A-UD7
GA-X58A-UD7
GA-X58A-UD7
GA-X58A-UD5
GA-X58A-UD7
GA-X58A-UD3R

Support CPU
Intel Core i7
Intel Core i7
Intel Core i7
Socket
LGA1366
LGA1366
LGA1366
QPI/FSB
6.4GT/s, 4.8GT/s
6.4GT/s, 4.8GT/s
6.4GT/s, 4.8GT/s
Chipset
Intel X58 + ICH10R
Intel X58 + ICH10R
Intel X58 + ICH10R
VGA intégré
-
-
-
Interfaces
4*PCI-E 2.0 x16 slot
(2x16 or 4x8)
4*PCI-E 2.0 x16 slot
(2x16 or 4x8)
4*PCI-E 2.0 x16 slot
(2x16 or 4x8)
Mémoires
Dual Channel DDR3 2200/1333/1066/800
Dual Channel DDR3 2200/1333/1066/800
Dual Channel DDR3 2200/1333/1066/800
Socket mémoire
6*DDR3 (Max 24 GB)
6*DDR3 (Max 24 GB)
6*DDR3 (Max 24 GB)
Slots
1*PCI + 2*PCI-Ex1
1*PCI + 2*PCI-Ex1
1*PCI + 2*PCI-Ex1
ATA
2*SATA 6Gb/s
10*SATA 3Gb/s + 1*PATA
2*SATA 6Gb/s
10*SATA 3Gb/s + 1*PATA
2*SATA 6Gb/s
10*SATA 3Gb/s + 1*PATA
RAID
SATA 6Gb RAID 0
SATA 3Gb RAID 0, 1, 5, 10
SATA 6Gb RAID 0
SATA 3Gb RAID 0, 1, 5, 10
SATA 6Gb RAID 0
SATA 3Gb RAID 0, 1, 5, 10
Audio
HD Audio, 8-channel
HD Audio, 8-channel
HD Audio, 8-channel
IEEE 1394
3*IEEE 1394a
3*IEEE 1394a
3*IEEE 1394a
USB
10*USB 2.0, 2*USB 3.0
10*USB 2.0, 2*USB 3.0
10*USB 2.0, 2*USB 3.0
LAN
2*Gigabit LAN
(Teaming Support)
2*Gigabit LAN
(Teaming Support)
1*Gigabit LAN
(Teaming Support)
BIOS
DualBIOS™
DualBIOS™
DualBIOS™
Innovations
USB 3.0, SATA 6Gb/s, 3x USB power, 24 phase power, Ultra Durable 3, Dynamic Energy Saver 2, ATI CrossFireX, SLI, Debug LED, Dolby Home Theater, Precision OV, eSATA/ USB combo, Hybrid SILENT-PIPE 2, Quick Boost
USB 3.0, USB 3x power ,
SATA 6Gb/s, 12 phase,
Smart6, Ultra Durable 3,
Dynamic Energy Saver 2,
3 Way SLI, ATI CrossFireX,
Dolby Home Theater,
Precision OV, Debug LED,
EuP Ready
USB 3.0, USB 3x power ,
SATA 6Gb/s,
Smart6,Ultra Durable 3,
Dynamic Energy Saver 2,
3 Way SLI, ATI CrossFireX,
Dolby Home Theater,
Precision OV,
EuP Ready
Logiciels
EasyTune 6,
Norton™ Internet Security
EasyTune 6,
Norton™ Internet Security
EasyTune 6,
Norton™ Internet Security
Form Factor (mm)
ATX (305x244)
ATX (305x244)
ATX (305x244)




Norton™ Internet Security
Logiciel de protection en temps réel contre les attaques virales diffusées par internet


  U : Design à 2 onces de cuivre D : 100% condensateurs solides
*Caractéristiques produits pouvant varier selon votre pays.
GIGABYTE se réserve le droit de modifier chacune de ces informations sans préavis.
