| Modelo |
GA-MA785GT-UD3H  |
GA-MA785GPMT-UD2H  |
GA-MA785GMT-UD2H |
| Soporte de CPU |
AMD AM3 Phenom II Processors
140W support |
AMD AM3 Phenom II Processors 140W support |
AMD AM3 Phenom II Processors 140W support |
| Socket de CPU |
AMD Socket AM3 |
AMD Socket AM3 |
AMD Socket AM3 |
| FSB |
5200 MT/s
|
5200 MT/s |
5200 MT/s |
| Chipset |
AMD 785G + SB710 |
AMD 785G + SB710 |
AMD 785G + SB710 |
| Video Integrado |
ATI Radeon HD 4200 (DX10.1) |
ATI Radeon HD 4200 (DX10.1) |
ATI Radeon HD 4200 (DX10.1) |
| Interfaz Gráfica |
2*PCI-E 2.0 x16 slot (x16, x4) |
1*PCI-E 2.0 x16 slot (x16) |
1*PCI-E 2.0 x16 slot (x16) |
| Memoria |
Dual Channel DDR3
1800+/1333/1066 |
Dual Channel DDR3 1800+/1333/1066 |
Dual Channel DDR3 1800+/1333/1066 |
| Sockets de Memoria |
4*DDR3 (Max 16 GB) |
4*DDR3 (Max 16 GB) |
4*DDR3 (Max 16 GB) |
| Puertos de Expansión |
2*PCI + 3*PCI-Ex1 |
2*PCI + 1*PCI-Ex1 |
2*PCI + 1*PCI-Ex1 |
| Conector ATA |
6*SATA 3Gb/s + 1*PATA |
5*SATA 3Gb/s + 1*e-SATA 3Gb/s + 1*PATA |
5*SATA 3Gb/s + 1*e-SATA 3Gb/s
+ 1*PATA |
| RAID |
SATA RAID 0, 1, 0+1
JBOD (SB710) |
SATA RAID 0, 1, 0+1
JBOD (SB710) |
SATA RAID 0, 1, 0+1
JBOD (SB710) |
| Audio/IEEE 1394/USB 2.0 |
HD Audio,
8-channel/3*1394a/12 |
HD Audio,
8-channel/2*1394a/12 |
HD Audio,
8-channel/2*1394a/12 |
| LAN |
Gigabit LAN |
Gigabit LAN |
Gigabit LAN |
| Características y Software |
Ultra Durable 3 Classic,
Easy Energy Saver,
DualBIOS, ACC support,
DVI/HDMI Certified,
HDCP, Blu-ray Disc support,
Dolby Home Theater,
ATI Hybrid CrossFireX,
EasyTune 6,
Norton Internet Security |
Ultra Durable 3 Classic,
Easy Energy Saver,
DualBIOS, ACC support,
DDR3 SidePort Memory,
DVI/HDMI Certified, HDCP,
Blu-ray Disc support,
Dolby Home Theater,
ATI Hybrid CrossFireX
EasyTune 6,
Norton Internet Security |
Ultra Durable 3 Classic,
Easy Energy Saver,
DualBIOS, ACC support,
DVI/HDMI Certified, HDCP,
Blu-ray Disc support,
Dolby Home Theater,
ATI Hybrid CrossFireX,
EasyTune 6,
Norton Internet Security |
| Tamaño (mm) |
ATX (305x229) |
Micro ATX (244x244) |
Micro ATX (244x244) |
|
| Modelo |
GA-MA785GMT-US2H |
GA-MA785G-UD3H  |
GA-MA785GPM-UD2H |
| Soporte de CPU |
AMD AM3 Phenom II Processors
140W support |
AMD AM3 PhenomII/ Phenom/
Athlon Processors ;140W support |
AMD AM3 PhenomII/ Phenom/ Athlon Processors ;140W support |
| Socket de CPU |
AMD Socket AM3 |
AMD Socket AM2+/ AM2 |
AMD Socket AM2+/ AM2 |
| FSB |
5200 MT/s |
5200/ 2000 MT/s |
5200/ 2000 MT/s |
| Chipset |
AMD 785G + SB710 |
AMD 785G + SB710 |
AMD 785G + SB710 |
| Video Integrado |
ATI Radeon HD 4200 (DX10.1) |
ATI Radeon HD 4200 (DX10.1) |
ATI Radeon HD 4200 (DX10.1) |
| Interfaz Gráfica |
1*PCI-E 2.0 x16 slot (x16) |
2*PCI-E 2.0 x16 slot (x16, x4) |
1*PCI-E 2.0 x16 slot (x16) |
| Memoria |
Dual Channel DDR3 1800+/1333/1066 |
Dual Channel DDR2 1333+/1066/800 |
Dual Channel DDR2 1200+/1066/800 |
| Sockets de Memoria |
4*DDR3 (Max 16 GB) |
4*DDR2 (Max 16 GB) |
4*DDR2 (Max 16 GB) |
| Puertos de Expansión |
2*PCI + 1*PCI-Ex1 |
2*PCI + 3*PCI-Ex1 |
2*PCI + 1*PCI-Ex1 |
| Conector ATA |
5*SATA 3Gb/s + 1*e-SATA 3Gb/s +1*PATA |
6*SATA 3Gb/s + 1*PATA |
5*SATA 3Gb/s + 1*e-SATA 3Gb/s +1*PATA |
| RAID |
SATA RAID 0, 1, 0+1
JBOD (SB710) |
SATA RAID 0, 1, 0+1
JBOD (SB710) |
SATA RAID 0, 1, 0+1
JBOD (SB710) |
| Audio/IEEE 1394/USB 2.0 |
HD Audio,
8-channel/2*1394a/12 |
HD Audio,
8-channel/3*1394a/12 |
HD Audio,
8-channel/2*1394a/12 |
| LAN |
Gigabit LAN |
Gigabit LAN |
Gigabit LAN |
| Características y Software |
Ultra Durable 3 Classic
(Solid capacitors for CPU VRM),
Easy Energy Saver, DualBIOS,
ACC support,
DVI/HDMI Certified,
HDCP, Blu-ray Disc support,
ATI Hybrid CrossFireX,
EasyTune 6,
Norton Internet Security |
Ultra Durable 3 Classic,
Easy Energy Saver,
DualBIOS, ACC support,
DVI/HDMI Certified,
HDCP, Blu-ray Disc support,
Dolby Home Theater,
ATI Hybrid CrossFireX,
EasyTune 6,
Norton Internet Security |
Ultra Durable 3 Classic,
Easy Energy Saver,
DualBIOS, ACC support,
DDR3 SidePort Memory,
DVI/HDMI Certified, HDCP,
Blu-ray Disc support,
Dolby Home Theater,
ATI Hybrid CrossFireX,
EasyTune 6,
Norton Internet Security |
| Tamaño (mm) |
Micro ATX (244x244) |
ATX (305x229) |
Micro ATX (244x244) |
|
| Modelo |
GA-MA785GM-UD2H |
GA-MA785GM-US2H |
|
| Soporte de CPU |
AMD AM3 PhenomII/ Phenom/ Athlon Processors ;140W support |
AMD AM3 PhenomII/ Phenom/ Athlon Processors ;140W support |
|
| Socket de CPU |
AMD Socket AM2+/ AM2 |
AMD Socket AM2+/ AM2 |
|
| FSB |
5200/ 2000 MT/s |
5200/ 2000 MT/s |
|
| Chipset |
AMD 785G + SB710 |
AMD 785G + SB710 |
|
| Video Integrado |
ATI Radeon HD 4200 (DX10.1) |
ATI Radeon HD 4200 (DX10.1) |
|
| Interfaz Gráfica |
1*PCI-E 2.0 x16 slot (x16) |
1*PCI-E 2.0 x16 slot (x16) |
|
| Memoria |
Dual Channel DDR2 1200+/1066/800 |
Dual Channel DDR2 1200+/1066/800 |
|
| Sockets de Memoria |
4*DDR2 (Max 16 GB) |
4*DDR2 (Max 16 GB) |
|
| Puertos de Expansión |
2*PCI + 1*PCI-Ex1 |
2*PCI + 1*PCI-Ex1 |
|
| Conector ATA |
5*SATA 3Gb/s + 1*e-SATA 3Gb/s + 1*PATA |
5*SATA 3Gb/s + 1*e-SATA 3Gb/s + 1*PATA |
|
| RAID |
SATA RAID 0, 1, 0+1
JBOD (SB710) |
SATA RAID 0, 1, 0+1
JBOD (SB710) |
|
| Audio/IEEE 1394/USB 2.0 |
HD Audio,
8-channel/2*1394a/12 |
HD Audio,
8-channel/2*1394a/12 |
|
| LAN |
Gigabit LAN |
Gigabit LAN |
|
| Características y Software |
Ultra Durable 3 Classic,
Easy Energy Saver,
DualBIOS, ACC support,
DVI/HDMI Certified, HDCP,
Blu-ray Disc support,
Dolby Home Theater,
ATI Hybrid CrossFireX,
EasyTune 6,
Norton Internet Security |
Ultra Durable 3 Classic
(Solid capacitors for CPU VRM),
Easy Energy Saver, DualBIOS,
ACC support,
DVI/HDMI Certified,
HDCP, Blu-ray Disc support,
ATI Hybrid CrossFireX,
EasyTune 6,
Norton Internet Security |
|
| Tamaño (mm) |
Micro ATX (244x244) |
Micro ATX (244x244) |
|
|
U: Diseño con 2oz de cobre en el PCB
D: Diseño con solo Capacitores Sólidos
|
Product features may vary by model.
Motherboard models may vary based on local distribution.
For more AMD Ultra Durable™ 3 series motherboards and detail CPU & memory support information, please refer to GIGABYTE website Click Here. |
|
|
