GA-6OXET (Rev. 1.x)

EspecificaciónSoporte y DescargasNoticias / PremiosWhere to Buy

Especificación

  • Procesador
    1. Universal socket 370 supports Intel® FC-PGA/FC-PGA2 Pentium® III (CopperMine/Tualatin)or other compatible processors
    2. Supports hardware Auto/66/100/133 MHz FSB (Front Side Bus) setting by DIP switch
    3. Supports software FSB, Multiplier, V-Core setting by BIOS
  • Chipset
    1. Intel® 815EP AGPset
    2. ITE I8712F Super I/O and health chip
    3. Creative CT5880 H/W sound
  • Memoria
    1. Supports up to 512 MB SDRAM memory
    2. 4 DIMMs 168-pin sockets
    3. Supports 32/64/128/256/512 MB SDRAM modules
    4. Supports RAM_OV voltage setting
  • Puertos de Expansión
    1. 1 x AGP slot supports 2X/4X mode & AGP 2.0 compliant
    2. 6 x PCI slots support 33MHz & PCI 2.2 compliant
    3. 1 x CNR (Communications and Network Riser) slot
    4. Supports AGP_OV voltage setting
  • Controlador de E/S
    1. 2 x UDMA ATA 66/100 IDE ports on board
    2. 1 x FDD, 2 x COM, 1 x LPT, PS/2 Keyboard, PS/2 Mouse on board
    3. 1 x Gameport, 1 x Line-in, 1 x Line-out, 1 x MIC on board
    4. 2 x USB ports on board, 2 x USB ports by cable (cable optional)
    5. 1 x SCR (Smart Card Reader) connector
    6. IrDA TX / RX header
  • Monitorización H/W
    1. Auto speed down and alarm when CPU overheat or fan failure (OS independent & driverless)
    2. 3 fan power & speed detection connectors
    3. System health status detect & report by BIOS
    4. H/W detect & report Power-in voltage, CPU voltage and CMOS battery status
  • BIOS
    1. Supports DualBIOS™ technology
    2. FWH(Firm Ware Hub) BIOS, enhanced ACPI feature for PC98/Win98/Win2000 compliance, Green, PnP, DMI, INT13 (>8.4GB) & Anti-Virus functions
    3. IDE#1~#4, SCSI, LS120, ZIP & CD-ROM bootable
    4. Auto-detect & report system health status
  • Diseño
    1. ATX form factor, 4 layers PCB (30.50 x 21.50 cm)
  • Controlador
    1. Gigabyte Windows Manager utility
    2. GIGABYTE @BIOS™ utility
    3. Hardware monitor utility
    4. Creative PCI sound drivers
  • Otras Características
    1. Supports Wake-On-LAN (WOL)
    2. Supports Internal / External Modem Ring On
    3. Includes 3 fan power connectors
    4. Poly fuse for keyboard over-current protection
    5. Supports @ BIOS™
  • Energía
    1. ATX power connector
    2. Power-on by LAN, RTC, Modem & Switch
    3. Power-off by Windows 95/98/Me/2000/NT shut down & switch
  • Procesador
    1. Universal socket 370 supports Intel® FC-PGA/FC-PGA2 Pentium® III (CopperMine/Tualatin)or other compatible processors
    2. Supports hardware Auto/66/100/133 MHz FSB (Front Side Bus) setting by DIP switch
    3. Supports software FSB, Multiplier, V-Core setting by BIOS
  • Chipset
    1. Intel® 815EP AGPset
    2. ITE I8712F Super I/O and health chip
    3. Creative CT5880 H/W sound
  • Memoria
    1. Supports up to 512 MB SDRAM memory
    2. 4 DIMMs 168-pin sockets
    3. Supports 32/64/128/256/512 MB SDRAM modules
    4. Supports RAM_OV voltage setting
  • Puertos de Expansión
    1. 1 x AGP slot supports 2X/4X mode & AGP 2.0 compliant
    2. 6 x PCI slots support 33MHz & PCI 2.2 compliant
    3. 1 x CNR (Communications and Network Riser) slot
    4. Supports AGP_OV voltage setting
  • Controlador de E/S
    1. 2 x UDMA ATA 66/100 IDE ports on board
    2. 1 x FDD, 2 x COM, 1 x LPT, PS/2 Keyboard, PS/2 Mouse on board
    3. 1 x Gameport, 1 x Line-in, 1 x Line-out, 1 x MIC on board
    4. 2 x USB ports on board, 2 x USB ports by cable (cable optional)
    5. 1 x SCR (Smart Card Reader) connector
    6. IrDA TX / RX header
  • Monitorización H/W
    1. Auto speed down and alarm when CPU overheat or fan failure (OS independent & driverless)
    2. 3 fan power & speed detection connectors
    3. System health status detect & report by BIOS
    4. H/W detect & report Power-in voltage, CPU voltage and CMOS battery status
  • BIOS
    1. Supports DualBIOS™ technology
    2. FWH(Firm Ware Hub) BIOS, enhanced ACPI feature for PC98/Win98/Win2000 compliance, Green, PnP, DMI, INT13 (>8.4GB) & Anti-Virus functions
    3. IDE#1~#4, SCSI, LS120, ZIP & CD-ROM bootable
    4. Auto-detect & report system health status
  • Diseño
    1. ATX form factor, 4 layers PCB (30.50 x 21.50 cm)
  • Controlador
    1. Gigabyte Windows Manager utility
    2. GIGABYTE @BIOS™ utility
    3. Hardware monitor utility
    4. Creative PCI sound drivers
  • Otras Características
    1. Supports Wake-On-LAN (WOL)
    2. Supports Internal / External Modem Ring On
    3. Includes 3 fan power connectors
    4. Poly fuse for keyboard over-current protection
    5. Supports @ BIOS™
  • Energía
    1. ATX power connector
    2. Power-on by LAN, RTC, Modem & Switch
    3. Power-off by Windows 95/98/Me/2000/NT shut down & switch

* Los términos HDMI, HDMI High-Definition Multimedia Interface (Interfaz multimedia de alta definición), HDMI Trade Dress (diseño e imagen comercial HDMI) y los logotipos HDMI son marcas comerciales o marcas registradas de HDMI Licensing Administrator, Inc.
* Todos los materiales aquí provistos son solo para referencia. GIGABYTE se reserva el derecho de modificar o revisar el contenido a cualquier hora sin aviso alguno.
* Todas las marcas y logos son propiedad de sus propios dueños.
* Debido a la arquitectura estándar de la PC, cierta cantidad de memoria es reservada para uso del sistema y actualmente la memoria disponible es menor a la mencionada.
