QBiX-Exp-TGLA1135G7H-A1

Intel® Core™ i5-1135G7 Processor

Industrial system with Intel® Core™ i5-1135G7 Processor / Fanless Design / Dual Channel DDR4 up to 64 GB/ 2 x HDMI

System size : 210.36W x 165D x 67H (mm)

Intel® Core™ i5-1135G7 Processor

Dual Channel DDR4, 2 x SO-DIMMs

2 x HDMI for Dual display

4 x GbE LAN Ports with PoE 15W/Port

2 x GbE LAN Ports

(For more product information, please contact us at sales@gigaipc.com)

Get a Quote

加入比較表

11th Generation Intel® Core™ Processors

Intel's blazing fast, feature packed processor family with built-in security is ready to take your productivity, and creativity to the next level. And, by enabling new exciting Windows 10 features, the 11th generation Intel Core processors empower you to unleash your imagination and explore the possibilities.
HDMI™-The Next Generation Multimedia Interface

HDMI™ is a High-Definition Multimedia Interface which provides up to 5Gb/s video transmitting bandwidth and 8-channel high quality audio all through a single cable. Able to transmit superior, uncompressed digital video and audio, HDMI™ ensures the crispest rendering of digital content up to 1080p without the quality losses associated with analog interfaces and their digital-to-analog conversion. In addition, HDMI™ is compatible with HDCP (High-bandwidth Digital Content Protection), allowing the playback of Blu-ray/HD DVD and other protected media content.
M.2 Onboard Connector

Providing users PCI-Express connectivity for SSD devices. Delivering up to 10 Gbps data transfer speeds, M.2 offers users considerably faster storage performance than current mSATA and even SATA Revision 3 6Gbps storage devices.
2.5" SATA Hard Drive Support

Utilizing SATA III 6Gb/s high speed data transfer technology, the xxx supports the installation of one 2.5” SATA hard drive and one mSATA SSD module. This allows for optimized storage configurations which combine fast SSD performance with larger capacity hard drives.

* 以上產品之規格、圖片及其他資訊僅供參考，如與實際產品有任何不相符之處，應以實際產品為準。技嘉科技保留在任何時間做出修改之權利。對任何因使用上述資料而引致之損失，技嘉科技概不承擔任何責任。
* 本產品所標示之各項效能表現為各晶片廠商或各制定介面官方組織所提出的最大理論值，實際效能可能因規格及設備而有所不同。
* 本文中所使用之各項商標及企業識別圖示，均為其合法所有人之財產。
* 基於PC基本架構，有部分記憶體空間須留作系統用途，故所偵測到之記憶體大小會比實際上較少。

SPECIFICATIONS

Processor Supported

Intel® Core™ i5-1135G7 Processor
10nm SuperFin, 4 cores, 8 threads, up to 4.2 GHz

Chipset Description

SoC

Memory Type

2 x DDR4 SO-DIMM sockets, Max. Capacity 64 GB
Support Dual Channel DDR4 3200 MHz memory modules

Integrated Network

2 x GbE LAN Ports (Intel® I219V and Intel® I211AT)
4 x PoE GbE LAN Ports (Intel® I211AT)

Integrated Video Controller

Integrated Graphics Processor - Intel® Iris® Xᵉ Graphics:
2 x HDMI 2.0 ports, supporting a maximum resolution of 4096x2160 @60Hz

(2 independent display outputs)

Integrated Audio Controller

Realtek® Audio Codec

Expansion Slot

1 x 2280 M.2 M-Key (PCIe x2, SATA 6Gb/s)
1 x 2230 M.2 E-Key
1 x Full-size MiniPCIe with SIM Slot

Rear I/O Connectors

2 x HDMI
2 x RJ45 LAN Ports
4 x USB 3.2 Gen 2x1
1 x COM Port (RS-232/422/485 & RI/5V/12V)
1 x COM Port (RS-232/422/485)
1 x GPIO (8 bits)
1 x Headphone Jack
1 x 4-pin Terminal Block

Packaging Bundle

Carton size: 572 x 321 x 372 (mm)
Packing Capacity: 4pcs

Including:
Terminal Blocks Male Plug x 1 (P/N: 25IO0-2ESDV0-D2R)
Screw For 2.5" HDD M3x4L x 8 (P/N: 25984G-1C014-S00)
Thermal Pad for Memory x 1 (P/N: 25ST3-200086-T5R)

Ordering Information

6BQE1135AMR-SI (Box packing)

Storage

1 x Swappable 2.5" HDD/SSD (SATA 6Gb/s)

Front I/O

4 x RJ45 LAN Ports with PoE
2 x USB 2.0
1 x Power button with LED
1 x HDD LED
2 x COM Ports (RS-232/422/485)
2 x External Antenna Holes (Optional)

Dimension

210.36W x 165D x 67H (mm)
