S260-NF1 (rev. 100)
2U NVMe Over Fabric Storage
| Application:
儲存伺服器
Application:
- Western Digital Onyx NVMe Over Fabric storage controller
- Fully supported iWARP, RoCE v1 and v2
- Dual controllers architecture
- 1 x 100Gb or 2 x 50Gb Ethernet port(s) via QSFP28 interface
- 1 x AST2520 management port per node
- 24 x 2.5" NVMe hot-swappable SSD bays
- 3 x PCIe Gen3 expansion slots per node
- Dual 800W 80 PLUS Platinum redundant power supply
Request a Quote
1/5
* 以上產品之規格、圖片及其他資訊僅供參考，如與實際產品有任何不相符之處，應以實際產品為準。技嘉科技保留在任何時間做出修改之權利。對任何因使用上述資料而引致之損失，技嘉科技概不承擔任何責任。
* 本產品所標示之各項效能表現為各晶片廠商或各制定介面官方組織所提出的最大理論值，實際效能可能因規格及設備而有所不同。
* 本文中所使用之各項商標及企業識別圖示，均為其合法所有人之財產。
* 基於PC基本架構，有部分記憶體空間須留作系統用途，故所偵測到之記憶體大小會比實際上較少。
* 本產品所標示之各項效能表現為各晶片廠商或各制定介面官方組織所提出的最大理論值，實際效能可能因規格及設備而有所不同。
* 本文中所使用之各項商標及企業識別圖示，均為其合法所有人之財產。
* 基於PC基本架構，有部分記憶體空間須留作系統用途，故所偵測到之記憶體大小會比實際上較少。
SPECIFICATIONS
Dimensions (WxHxD, mm)
2U
440 x 87 x 695
440 x 87 x 695
Motherboard
2 x CPBD530
Embedded Microsemi PM8536B-FEI PICe switch with 96 Lanes
Pre-installed 1 x Western Digital Onyx NVMe Host Bus Adapter* in each CPBD530
Each CPBD530 board controls 24 x NVMe SSD devices with PCIe x2 bandwidth per port
*NOTE: Up to 3 x Western Digital Onyx NVMe Host Bus Adapters in each CPBD530 board
Embedded Microsemi PM8536B-FEI PICe switch with 96 Lanes
Pre-installed 1 x Western Digital Onyx NVMe Host Bus Adapter* in each CPBD530
Each CPBD530 board controls 24 x NVMe SSD devices with PCIe x2 bandwidth per port
*NOTE: Up to 3 x Western Digital Onyx NVMe Host Bus Adapters in each CPBD530 board
CPU
Western Digital Onyx NVMeOF Bridge ASIC
Socket
Embedded
Chipset
-
Memory
-
LAN
1 x 100Gb or 2 x 50Gb Ethernet port(s) via QSFP28 interface
1 x 10/100/1000 management LAN
1 x 10/100/1000 management LAN
Video
Integrated in Aspeed® AST2520
Audio
-
Storage
24 x 2.5" NVMe hot-swappable SSD bays
SATA
-
SAS
-
RAID
-
Peripheral Drives
-
Expansion Slots
Per node:
Total 3 x PCIe x16 slots (Gen3 x16) for Western Digital Onyx NVMeOF HBAs per node
- 2 x PCIe x16 (Gen3 x16 bus) Full height slots
- 1 x PCIe x16 (Gen3 x16 bus) Low profile slot
Total 3 x PCIe x16 slots (Gen3 x16) for Western Digital Onyx NVMeOF HBAs per node
- 2 x PCIe x16 (Gen3 x16 bus) Full height slots
- 1 x PCIe x16 (Gen3 x16 bus) Low profile slot
Internal I/O
-
Front I/O
1 x Power button with LED
1 x ID button with LED
1 x Reset button
1 x System status LED
1 x ID button with LED
1 x Reset button
1 x System status LED
Rear I/O
1 x QSFP28
1 x MLAN
1 x Serial port
1 x Power button with LED
1 x ID button with LED
1 x BMC Reset button
1 x System Reset button
1 x System status LED
1 x MLAN
1 x Serial port
1 x Power button with LED
1 x ID button with LED
1 x BMC Reset button
1 x System Reset button
1 x System status LED
Backplane I/O
Bandwidth: PCIe Gen3 x2 per port
TPM
-
Power Supply
2 x 800W redundant PSUs
80 PLUS Platinum
AC Input:
- 100-240V~/ 10-4A, 50-60Hz
DC Input:
- 240Vdc/ 4.5A
DC Output:
- 800W
+12V/ 66A
+12Vsb/ 2.5A
80 PLUS Platinum
AC Input:
- 100-240V~/ 10-4A, 50-60Hz
DC Input:
- 240Vdc/ 4.5A
DC Output:
- 800W
+12V/ 66A
+12Vsb/ 2.5A
System Management
Aspeed® AST2520 management controller
OS Compatibility
-
Weight
Net Weight: 17 kg
Gross Weight: 28.8 kg
Gross Weight: 28.8 kg
System Fans
4 x 80x80x38mm (16,300rpm)
Operating Properties
Operating temperature: 10°C to 35°C
Operating humidity: 8-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)
Operating humidity: 8-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)
Packaging Dimensions
1038 x 697 x 311 mm
Packaging Content
1 x S260-NF1
1 x Rail kit
1 x Rail kit
Part Numbers
Barebone package: 6NS260NF1MR-00
Part Numbers:
- Controller board: 9CPBD530NR-00
- NVMeOF bridge controller: 25FCZ-ONYX20-M9R
- Rail kit: 25HB2-AN6103-K0R
- Back plane board: 9CBPD0O1NR-00
- Front panel board: 9CFPH004NR-00
- Power supply: 25EP0-208004-L0S
- Riser card - CRSD020: 9CRSD020NR-00
- NVMeOF bridge controller: 25FCZ-ONYX20-M9R
- Rail kit: 25HB2-AN6103-K0R
- Back plane board: 9CBPD0O1NR-00
- Front panel board: 9CFPH004NR-00
- Power supply: 25EP0-208004-L0S
- Riser card - CRSD020: 9CRSD020NR-00
