MC12-LE0
(rev. 1.x)
AMD Ryzen™ 5000 Server Board
- AMD Ryzen™ 5000 Series / Ryzen™ 4000 Series / Ryzen™ 3000 Series Processors
- Dual Channel ECC / Non-ECC Unbuffered DDR4, 4 DIMMs
- 2 x 1Gb/s LAN ports (Intel® I210-AT)
- 1 x Dedicated management port
- 6 x SATA 6Gb/s ports
- Ultra-Fast M.2 with PCIe Gen3 x1 interface
- 2 x PCIe Gen4 expansion slots
Request a Quote
1/4
* Les informations ici proposées le sont pour référence uniquement. GIGABYTE se réserve le droit de modifier ce contenu à tout moment et sans préavis.
* Marques et logos appartiennent aux détenteurs respectifs de leurs droits.
* L'architecture de grand nombre de PC affectera directement la capacité mémoire, en effet, une certaine quantité de RAM sera affectée au système, la quantité totale affichée pourra alors varier de celle insérée sur votre carte mère
* Marques et logos appartiennent aux détenteurs respectifs de leurs droits.
* L'architecture de grand nombre de PC affectera directement la capacité mémoire, en effet, une certaine quantité de RAM sera affectée au système, la quantité totale affichée pourra alors varier de celle insérée sur votre carte mère
SPECIFICATIONS
Form Factor
microATX
244W x 244D (mm)
244W x 244D (mm)
CPU
AMD Ryzen™ 5000 Series / Ryzen™ 4000 Series / Ryzen™ 3000 Series Processors
Socket
AM4
Chipset
AMD B550
Memory
4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory
Dual channel memory architecture
Supported ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules*
Supported non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Memory speed: Up to 3200/2933/2667/2400/2133 MHz
*NOTE: ECC support is only with AMD Ryzen™ with PRO technology
Dual channel memory architecture
Supported ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules*
Supported non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Memory speed: Up to 3200/2933/2667/2400/2133 MHz
*NOTE: ECC support is only with AMD Ryzen™ with PRO technology
LAN
2 x 1GbE LAN ports (Intel® I210-AT)
1 x 10/100/1000 management LAN
1 x 10/100/1000 management LAN
Video
Integrated in Aspeed® AST2500
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp
Audio
N/A
SAS
N/A
SATA
6 x SATA 6Gb/s ports
RAID
RAID 0/1/10
Expansion Slots
Slot_6 (PCIEX16): 1 x PCIe x16 (Gen4 x16 bus) slot from CPU
Slot_4 (PCIEX4): 1 x PCIe x4 (Gen4 x4 bus) slot from CPU
1 x M.2 slot:
- M-key
- PCIe Gen3 x1
- Supports NGFF-2242/2280 cards
Slot_4 (PCIEX4): 1 x PCIe x4 (Gen4 x4 bus) slot from CPU
1 x M.2 slot:
- M-key
- PCIe Gen3 x1
- Supports NGFF-2242/2280 cards
Internal I/O
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
6 x SATA ports
1 x M.2 slot
1 x HDD back plane board header
1 x CPU fan header
5 x System fan headers
1 x USB 3.1 Gen1 header with 2-port
1 x USB 3.1 Gen1 type-A connector
1 x USB 2.0 header with 2-port
1 x TPM header
1 x Front panel header
1 x IPMB connector
1 x PMBUS connector
1 x Clear CMOS jumper
1 x 8-pin ATX 12V power connector
6 x SATA ports
1 x M.2 slot
1 x HDD back plane board header
1 x CPU fan header
5 x System fan headers
1 x USB 3.1 Gen1 header with 2-port
1 x USB 3.1 Gen1 type-A connector
1 x USB 2.0 header with 2-port
1 x TPM header
1 x Front panel header
1 x IPMB connector
1 x PMBUS connector
1 x Clear CMOS jumper
Rear I/O
2 x USB 3.1 Gen1
1 x VGA
1 x COM
2 x RJ45
1 x MLAN
1 x ID button with LED
1 x VGA
1 x COM
2 x RJ45
1 x MLAN
1 x ID button with LED
TPM
1 x TPM header with SPI interface
Optional TPM2.0 kit: CTM010
Optional TPM2.0 kit: CTM010
OS Supported
Windows 10 64-bit
Board Management
Aspeed® AST2500 management controller
GIGABYTE Management Console (AMI MegaRAC SP-X) web interface
GIGABYTE Management Console (AMI MegaRAC SP-X) web interface
- Dashboard
- HTML5 KVM
- Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
- Sensor Reading History Data
- FRU Information
- SEL Log in Linear Storage / Circular Storage Policy
- Hardware Inventory
- Fan Profile
- System Firewall
- Power Consumption
- Power Control
- LDAP / AD / RADIUS Support
- Backup & Restore Configuration
- Remote BIOS/BMC/CPLD Update
- Event Log Filter
- User Management
- Media Redirection Settings
- PAM Order Settings
- SSL Settings
- SMTP Settings
PSU Connectors
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x 8-pin ATX 12V power connector
Operating Properties
Operating temperature: 10°C to 40°C
Operating humidity: 8-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)
Operating humidity: 8-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)
Retail Packaging Content
1 x MC12-LE0
1 x I/O shield
1 x Quick start guide
4 x SATA cables
Single Box dimensions: 321 x 308.5 x 78.5 mm
Carton dimension: 630 x 420 x 345 mm
Quantity: 10 x single box with one carton
1 x I/O shield
1 x Quick start guide
4 x SATA cables
Single Box dimensions: 321 x 308.5 x 78.5 mm
Carton dimension: 630 x 420 x 345 mm
Quantity: 10 x single box with one carton
Bulk Packaging Content
10 x MC12-LE0
10 x I/O shields
Carton dimensions: 609 x 581 x 362 mm
MOQ: 10 PCS MC12-LE0
10 x I/O shields
Carton dimensions: 609 x 581 x 362 mm
MOQ: 10 PCS MC12-LE0
Reference Numbers
Retail: 9MC12LE0MR-00
Bulk: 9MC12LE0NR-00
Part Numbers: - I/O shield: 12AIO-MC12C0-10R
- SATA 6Gb/s cable: 12CF1-2SAT1B-01R (1 set 2 cables)
Bulk: 9MC12LE0NR-00
Part Numbers: - I/O shield: 12AIO-MC12C0-10R
- SATA 6Gb/s cable: 12CF1-2SAT1B-01R (1 set 2 cables)
* Les informations ici proposées le sont pour référence uniquement. GIGABYTE se réserve le droit de modifier ce contenu à tout moment et sans préavis.
*Les performances affichées sont basées sur les informations proposées par les constructeurs de chipsets ou sociétés définissant les caractéristiques des interfaces. Performances pouvant varier selon configuration.
* Marques et logos appartiennent aux détenteurs respectifs de leurs droits.
* L'architecture de grand nombre de PC affectera directement la capacité mémoire, en effet, une certaine quantité de RAM sera affectée au système, la quantité totale affichée pourra alors varier de celle insérée sur votre carte mère
*Les performances affichées sont basées sur les informations proposées par les constructeurs de chipsets ou sociétés définissant les caractéristiques des interfaces. Performances pouvant varier selon configuration.
* Marques et logos appartiennent aux détenteurs respectifs de leurs droits.
* L'architecture de grand nombre de PC affectera directement la capacité mémoire, en effet, une certaine quantité de RAM sera affectée au système, la quantité totale affichée pourra alors varier de celle insérée sur votre carte mère
SUPPORT
- All
- All
- Windows 11 64bit
- Windows 10 64bit
Chipset
LAN
LAN
Version
Taille
Date
Intel® LAN Driver and Utility
Version : 26.4
686.68 MB
Apr 21, 2022
OS: Windows 10 64bit,Windows 11 64bit
VGA
VGA
Version
Taille
Date
ASPEED Graphic Driver
Version : 1.12
3.45 MB
Mar 31, 2022
OS: Windows 10 64bit,Windows 11 64bit
BIOS
Description
Version
Taille
Date
1. Fixed first flash BIOS and clear CMOS not show warring message
2. Fixed Renoir CPU AC loss can't sync with BMC
3. Fine tune POST SATA information
4. Fine tune Onboard LAN control item
2. Fixed Renoir CPU AC loss can't sync with BMC
3. Fine tune POST SATA information
4. Fine tune Onboard LAN control item
Version : F11
32.03 MB
Oct 07, 2022
Windows and UEFI mode flash BIOS SOP
Please download BIOS update tool from AMI Website
Please download BIOS update tool from AMI Website
-
0.31 MB
Jan 29, 2021
Warning:
Because BIOS flashing is potentially risky, if you do not encounter problems using the current version of BIOS, it is recommended that you not flash the BIOS. To flash the BIOS, do it with caution. Inadequate BIOS flashing may result in system malfunction.
What is a BETA?
BETA describes a new version that is reliable yet may not include all the features of the final product. During this phase we are previewing new features and gathering customer input to insure our product provides the best experience possible.
Update CPU ID/Micro codes in new BIOS means?
[1] To support new series of CPUs, or [2] To support the same CPU but with new stepping. CPU support of motherboard is consist of BIOS and hardware design, detail CPU support information please see CPU support list.
Because BIOS flashing is potentially risky, if you do not encounter problems using the current version of BIOS, it is recommended that you not flash the BIOS. To flash the BIOS, do it with caution. Inadequate BIOS flashing may result in system malfunction.
What is a BETA?
BETA describes a new version that is reliable yet may not include all the features of the final product. During this phase we are previewing new features and gathering customer input to insure our product provides the best experience possible.
Update CPU ID/Micro codes in new BIOS means?
[1] To support new series of CPUs, or [2] To support the same CPU but with new stepping. CPU support of motherboard is consist of BIOS and hardware design, detail CPU support information please see CPU support list.
Firmware
Description
Version
Taille
Date
BMC Firmware with embedded GIGABYTE Management Console
(AST2500 AMI)
(AST2500 AMI)
Version : 12.61.17
105.27 MB
Nov 15, 2023
