XL44-SX2-AAS1
NVIDIA RTX PRO™ Server - 4U DP 8 x NVIDIA RTX PRO™ 6000 Blackwell Server Edition GPUs
- NVIDIA RTX PRO™ server with ConnectX®-8 SuperNIC™ switch
- Configured with 8 x NVIDIA RTX PRO™ 6000 Blackwell Server Edition GPUs
- Configured with 1 x NVIDIA® BlueField®-3 DPU
- Onboard 400Gb/s InfiniBand/Ethernet QSFP ports with PCIe Gen6 switching for peak GPU-to-GPU performance
- Dual Intel® Xeon® 6700/6500-Series Processors
- 8-Channel DDR5 RDIMM/MRDIMM, 32 x DIMMs
- 2 x 10Gb/s LAN ports via Intel® X710-AT2
- 8 x 2.5" Gen5 NVMe hot-swap bays
- 2 x M.2 slots with PCIe Gen4 x2 interface
- 3+1 3200W 80 PLUS Titanium redundant power supplies
Ordering Numbers: 6NXL44SX2DR000AAS1*
產品規格
Dimensions (WxHxD, mm)
4U
438 x 176.6 x 802.5
438 x 176.6 x 802.5
Motherboard
MSX4-MG1
CPU
Intel® Xeon® 6 Processors
- Intel® Xeon® 6700-Series Processors
- Intel® Xeon® 6500-Series Processors
Dual processor, TDP up to 350W
[Note] If only 1 CPU is installed, some PCIe or memory functions might be unavailable.
- Intel® Xeon® 6700-Series Processors
- Intel® Xeon® 6500-Series Processors
Dual processor, TDP up to 350W
[Note] If only 1 CPU is installed, some PCIe or memory functions might be unavailable.
Socket
2 x LGA 4710
Socket E2
Socket E2
Chipset
System on Chip
Memory
32 x DIMM slots
Support DDR5 RDIMM/MRDIMM [1]
8-Channel memory per processor
RDIMM: Up to 6400 MT/s (1DPC), 5200 MT/s (2DPC)
MRDIMM: Up to 8000 MT/s
[1] MRDIMMs are supported only on select Intel® Xeon® 6 processors with P-cores and only in a 1DPC configuration.
Support DDR5 RDIMM/MRDIMM [1]
8-Channel memory per processor
RDIMM: Up to 6400 MT/s (1DPC), 5200 MT/s (2DPC)
MRDIMM: Up to 8000 MT/s
[1] MRDIMMs are supported only on select Intel® Xeon® 6 processors with P-cores and only in a 1DPC configuration.
LAN
Front (I/O board):
2 x 10Gb/s LAN (1 x Intel® X710-AT2)
- Support NCSI function
1 x 10/100/1000 Mbps Management LAN
Rear (ConnectX®-8 SuperNIC™ switch board):
8 x QSFP ports (400Gb/s InfiniBand/Ethernet, for GPU networking)
2 x 10Gb/s LAN (1 x Intel® X710-AT2)
- Support NCSI function
1 x 10/100/1000 Mbps Management LAN
Rear (ConnectX®-8 SuperNIC™ switch board):
8 x QSFP ports (400Gb/s InfiniBand/Ethernet, for GPU networking)
Video
Integrated in ASPEED® AST2600
- 1 x Mini-DP
- 1 x Mini-DP
Storage
Front hot-swap:
8 x 2.5" Gen5 NVMe
- (2 x NVMe from CPU_0, 6 x NVMe from CPU_1)
Internal M.2 (I/O board):
2 x M.2 (2280/22110), PCIe Gen4 x2, from CPU_0
8 x 2.5" Gen5 NVMe
- (2 x NVMe from CPU_0, 6 x NVMe from CPU_1)
Internal M.2 (I/O board):
2 x M.2 (2280/22110), PCIe Gen4 x2, from CPU_0
PCIe Expansion Slots
8 x NVIDIA RTX PRO™ 6000 Blackwell Server Edition GPUs, via ConnectX®-8
1 x NVIDIA® BlueField®-3 DPU, from CPU_0
1 x NVIDIA® BlueField®-3 DPU, from CPU_0
Front I/O
I/O board:
2 x USB 3.2 Gen1 ports (Type-A)
1 x Mini-DP
2 x RJ45 ports
1 x MLAN port
1 x Power button with LED
1 x ID button with LED
1 x NMI button
1 x Reset button
1 x Storage activity LED
1 x System status LED
2 x USB 3.2 Gen1 ports (Type-A)
1 x Mini-DP
2 x RJ45 ports
1 x MLAN port
1 x Power button with LED
1 x ID button with LED
1 x NMI button
1 x Reset button
1 x Storage activity LED
1 x System status LED
Rear I/O
8 x QSFP ports
Security Modules
1 x TPM header with SPI interface
- Optional TPM2.0 kit: CTM012
1 x PRoT connector (only enabled on RoT SKU)
- Optional TPM2.0 kit: CTM012
1 x PRoT connector (only enabled on RoT SKU)
Power Supply[#1]
3+1 3200W 80 PLUS Titanium redundant power supply [1]
AC Input:
- 100-127V~/ 16A, 50-60Hz
- 200-220V~/ 16A, 50-60Hz
- 220-240V~/ 16A, 50-60Hz
DC Input: (Only for China)
- 240Vdc/ 16A
DC Output:
- Max 1300W/ 100-127V~
+12.2V/ 106.6A
+12.2Vsb/ 3A
- Max 3000W/ 200-220V~
+12.2V/ 246A
+12.2Vsb/ 3A
- Max 3200W/ 220-240V~ or 240Vdc Input
+12.2V/ 262.3A
+12.2Vsb/ 3A
[1] The system power supply requires C19 power cord.
AC Input:
- 100-127V~/ 16A, 50-60Hz
- 200-220V~/ 16A, 50-60Hz
- 220-240V~/ 16A, 50-60Hz
DC Input: (Only for China)
- 240Vdc/ 16A
DC Output:
- Max 1300W/ 100-127V~
+12.2V/ 106.6A
+12.2Vsb/ 3A
- Max 3000W/ 200-220V~
+12.2V/ 246A
+12.2Vsb/ 3A
- Max 3200W/ 220-240V~ or 240Vdc Input
+12.2V/ 262.3A
+12.2Vsb/ 3A
[1] The system power supply requires C19 power cord.
OS Certifications
System Fans
10 x 80x80x80mm
Operating Properties
Operating temperature: 10°C to 30°C
Operating humidity: 8% to 80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20% to 95% (non-condensing)
Operating humidity: 8% to 80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20% to 95% (non-condensing)
Packaging Dimensions
1200 x 800 x 444 mm
Packaging Content
1 x XL44-SX2-AAS1
2 x CPU heatsinks
4 x Carriers
1 x L-shape Rail kit
2 x CPU heatsinks
4 x Carriers
1 x L-shape Rail kit
Part Numbers
- Barebone package: 6NXL44SX2DR000AAS1*
- Motherboard: 9MSX4MG1UR-000*
- Motherboard: 9MSX4MG1UR-000*
[#1] 伺服器產品未附帶電源線。客戶需自行選擇適當的電源線 (可選配件)，或聯繫業務協助客製化。
[#2] 本網站所提供之產品規格、圖片及其他資訊僅供參考，如有差異應以實際產品為準。技嘉科技保留隨時修改內容的權利，並不對因使用上述資料而導致的任何損失承擔責任。
[#3] 本產品所標示之效能數據為晶片廠商或相關介面標準制定組織所公佈的最大理論值，實際效能可能因系統配置及使用環境而有所不同。
[#4] 本文所使用的所有商標及企業識別標誌均為其合法所有者的財產。
