E152-ZE1

1U
438 x 43.5 x 400

MZE2-G10

AMD EPYC™ 7003 Series Processors
AMD EPYC™ 7002 Series Processors

Single processor, cTDP up to 240W

1 x LGA 4094
Socket SP3

System on Chip

8 x DIMM slots
DDR4 memory supported
8-Channel memory per processor
RDIMM/LRDIMM: Up to 3200/2933 MT/s

Front:
2 x 1Gb/s LAN (1 x Intel^® I350-AM2)
- Support NCSI function

1 x 10/100/1000 Mbps Management LAN

Integrated in ASPEED^® AST2600
- 1 x Mini-DP

Front hot-swap:
2 x 2.5" Gen4 NVMe/SATA ^[1]

Internal M.2 (CMTP182):
2 x M.2 (2280/22110), PCIe Gen4 x4

^[1] Supports 7mm drives only.

N/A

Require RAID add-in cards

1 x FHFL x16 (Gen4 x16), for GPUs
1 x FHFL x16 (Gen4 x16), for GPUs ^[1]
1 x LP x16 (Gen4 x16)

1 x OCP NIC 3.0 (Gen4 x16)
- Supports NCSI function

^[1] Blocked when a Dual slot GPU is installed.

2 x USB 3.0 ports (Type-A)
1 x Mini-DP
2 x RJ45 ports
1 x MLAN port
1 x Power button with LED
1 x ID button with LED
1 x System status LED

N/A

Speed and bandwidth:
PCIe Gen4 x4 or SATA 6Gb/s

1 x TPM header with SPI interface
- Optional TPM2.0 kit: CTM010

1+1 1000W 80 PLUS Platinum redundant power supplies

AC Input:
- 100-127V~/ 15A, 50-60Hz
- 200-240V~/ 8A, 50-60Hz

DC Output:
- Max 1000W
+12V/ 83.3A
+12Vsb/ 3A

ASPEED^® AST2600 Baseboard Management Controller
GIGABYTE Management Console web interface

• Dashboard
• HTML5 KVM
• Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
• Sensor Reading History Data
• FRU Information
• SEL Log in Linear Storage/Circular Storage Policy
• Hardware Inventory
• Fan Profile
• System Firewall
• Power Consumption
• Power Control
• Advanced power capping
• LDAP/AD/RADIUS Support
• Backup & Restore Configuration
• Remote BIOS/BMC/CPLD Update
• Event Log Filter
• User Management
• Media Redirection Settings
• PAM Order Settings
• SSL Settings
• SMTP Settings

Citrix Hypervisor 8.2.0 or later

Red Hat Enterprise Linux 8.3 or later
Red Hat Enterprise Linux 9.0 or later

SUSE Linux Enterprise Server 12 SP5 or later
SUSE Linux Enterprise Server 15 SP2 or later

Ubuntu 18.04.5 LTS or later
Ubuntu 20.04 LTS or later
Ubuntu 22.04 LTS or later

VMware ESXi 6.7 Update3 P03 or later
VMware ESXi 7.0 Update1 or later
VMware ESXi 8.0 or later

Windows Server 2016 (X2APIC/256T not supported)
Windows Server 2019
Windows Server 2022

1 x 40x40x28mm (25,000rpm)
5 x 40x40x56mm (25,000rpm)

Operating temperature: 10°C to 35°C
Operating humidity: 8-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)

Net Weight: 7.7 kg
Gross Weight: 11.72 kg

628 x 549 x 200 mm

1 x E152-ZE1
1 x CPU heatsink

^[Note] Rail kit not included. Please refer to optional parts for compatible rail kit.

- Barebone package: 6NE152ZE1MR-00-A*
- Motherboard: 9MZE2G10NR-00*
- CPU heatsink: 25ST1-453211-A3R
- Backplane board - CBPH022: 9CBPH022NR-00*
- Fan module 40x40x28mm: 25ST2-442827-D0R
- Fan module 40x40x56mm: 25ST2-44562M-D0R
- Fan module 40x40x56mm: 25ST2-44562N-D0R
- M.2 riser card - CMTP182: 9CMTP182NR-00*
- Riser card - CRSE020: 9CRSE020NR-00*
- Riser card - CRSH01H: 9CRSH01HNR-00*
- NVMe card - CNV3152: 9CNV3152NR-00*
- Power supply: 25EP0-210000-D0S

Optional parts:

- 2-Section Rail kit (385-480mm): 25HB2-3A0204-K0R (MOQ: 500)
- 2-Section Rail kit (660-840mm): 25HB2-3A0203-K0R
