產品規格
Dimensions (WxHxD, mm)
2U
438 x 87.5 x 820
CPU
AMD EPYC™ 7002 Series Processors
AMD EPYC™ 7001 Series Processors
Single processor, 7nm technology
Up to 64 cores, 128 threads
TDP up to 240W, cTDP up to 280W
Socket
1 x LGA 4094
Socket SP3
Memory
8 x DIMM slots
DDR4 memory supported only
8-Channel memory architecture
RDIMM up to 128GB supported
LRDIMM up to 128GB supported
Memory speed: Up to 3200 MT/s
LAN
Rear side:
1 x 10/100/1000 Mbps Management LAN
Video
Integrated in Aspeed® AST2500
- 1 x VGA port
Storage
Front side:
4 x 3.5"/2.5" SATA hot-swappable bays
SATA devices supported only
Rear side:
2 x 2.5" Gen4 NVMe/SATA/SAS hot-swappable bays
SAS card is required for SAS devices support
SAS
Depends on SAS add-in cards
Expansion Slots
4 x PCIe x16 (Gen4 x16) FHFL slots, for GPUs
Riser Card CRSG120:
- 1 x PCIe x16 (Gen4 x16 or x8) FHHL slot
- 1 x PCIe x8 (Gen4 x0 or x8) FHHL slot
1 x OCP 3.0 slot with PCIe Gen4 x16 bandwidth
Supports NCSI function
- System is validated for population with a uniform GPU model.
- Support is not provided for mixed GPU populations.
Internal I/O
1 x TPM header
Front I/O
1 x USB 3.0
1 x Power button with LED
1 x ID button with LED
1 x NMI button
1 x Reset button
1 x Storage activity LED
1 x System status LED
Rear I/O
2 x USB 3.0
1 x VGA
1 x MLAN
1 x ID LED
Backplane Board
Speed and bandwidth:
Front side - CBPG041: SATA 6Gb/s
Rear side - CBP2021: PCIe Gen4 x4 or SATA 6Gb/s or SAS 12Gb/s
TPM
1 x TPM header with SPI interface
-
Optional TPM2.0 kit:
CTM010Power Supply[#1]
Dual 1600W 80 PLUS Platinum redundant power supply
AC Input:
- 100-120V~/ 12A, 50/60Hz
- 200-240V~/ 10A, 50/60Hz
DC Input: (Only for China)
- 240Vdc/ 10A
DC Output:
- Max 1000W/ 100-120V~
+12V/ 81.5A
+12Vsb/ 2.5A
- Max 1600W/ 200-240V~ or 240Vdc Input
+12V/ 133A
+12Vsb/ 2.5A
System Management
Aspeed
® AST2500 Baseboard Management Controller
GIGABYTE Management Console web interface
- Dashboard
- HTML5 KVM
- Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
- Sensor Reading History Data
- FRU Information
- SEL Log in Linear Storage/Circular Storage Policy
- Hardware Inventory
- Fan Profile
- System Firewall
- Power Consumption
- Power Control
- LDAP / AD / RADIUS Support
- Backup & Restore Configuration
- Remote BIOS/BMC/CPLD Update
- Event Log Filter
- User Management
- Media Redirection Settings
- PAM Order Settings
- SSL Settings
- SMTP Settings
OS Compatibility
Citrix Hypervisor 8.1.0 or later
Red Hat Enterprise Linux 7.6 or later
Red Hat Enterprise Linux 8.0 or later
Red Hat Enterprise Linux 9.0 or later
SUSE Linux Enterprise Server 12 SP4 or later
SUSE Linux Enterprise Server 15 SP1 or later
Ubuntu 16.04.6 LTS or later
Ubuntu 18.04.3 LTS or later
Ubuntu 20.04 LTS or later
VMware ESXi 6.5 EP15 or later
VMware ESXi 6.7 Update3 or later
VMware ESXi 7.0 or later
VMware ESXi 8.0 or later
Windows Server 2016 (X2APIC/256T not supported)
Windows Server 2019System Fans
5 x 80x80x38mm (16,300rpm)
Operating Properties
Operating temperature: 10°C to 35°C
Operating humidity: 8%-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)
Weight
Net Weight: 18.1 kg
Gross Weight: 27 kg
Gross Weight (AICs included): 56.2 kg
Packaging Dimensions
1077 x 679 x 300 mm
Packaging Content
1 x G242-Z11
1 x CPU heatsink
3 x GPU power cables (PCIe 8pin*2, 360mm)
1 x GPU power cable (PCIe 8pin*2, 480mm)
1 x 2-Section Rail kit
Part Numbers
- Barebone package: 6NG242Z11MR-00-1*
- Motherboard: 9MZ12HD3NR-00
- 2-Section Rail kit: 25HB2-3A0202-K0R
- CPU heatsink: 25ST1-15320E-J1R
- Front panel board - CFP1000: 9CFP1000NR-00
- Backplane board - CBPG041: 9CBPG041NR-00
- Backplane board - CBP2021: 9CBP2021NR-00
- Fan module: 25ST2-88382A-D0R
- Riser card - CRSG120: 9CRSG120NR-00
- GPU power cable (PCIe 8pin*2, 360mm): 25CRI-360300-Y4R
- GPU power cable (PCIe 8pin*2, 480mm): 25CRI-480300-Y4R
- Power supply: 25EP0-216007-L0S
Optional parts:
- RMA packaging: 6NG242Z11SR-RMA-A100
[#1] 伺服器產品未附帶電源線。客戶需自行選擇適當的電源線 (可選配件),或聯繫業務協助客製化。
[#2] 本網站所提供之產品規格、圖片及其他資訊僅供參考,如有差異應以實際產品為準。技嘉科技保留隨時修改內容的權利,並不對因使用上述資料而導致的任何損失承擔責任。
[#3] 本產品所標示之效能數據為晶片廠商或相關介面標準制定組織所公佈的最大理論值,實際效能可能因系統配置及使用環境而有所不同。
[#4] 本文所使用的所有商標及企業識別標誌均為其合法所有者的財產。
