SPECIFICATIONS

Dimensions (WxHxD, mm)
2U
438 x 87.5 x 730
Motherboard
MR92-FS0
CPU
3rd Generation Intel® Xeon® Scalable Processors
Intel® Xeon® Platinum Processor, Intel® Xeon® Gold Processor, Intel® Xeon® Silver Processor
10nm technology, CPU TDP up to 270W
NOTE: If only 1 CPU is installed, some PCIe or memory functions might be unavailable
Socket
2 x LGA 4189
Socket P+
Chipset
Intel® C621A Express Chipset
Memory
32 x DIMM slots
DDR4 memory supported only
8-channel memory architecture per processor
RDIMM modules up to 64GB supported
LRDIMM modules up to 128GB supported
3DS RDIMM/LRDIMM modules up to 256GB supported
1.2V modules: 3200/2933/2666 MHz
LAN
2 x 1Gb/s LAN ports (Intel® I350-AM2)
1 x 10/100/1000 management LAN
Video
Integrated in Aspeed® AST2600
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp, DDR4 SDRAM
Audio
N/A
Storage
24 x 2.5" Gen4 NVMe hot-swappable HDD/SSD bays
2 x 2.5" SATA/SAS hot-swappable HDD/SSD bays in rear side
SAS
N/A
RAID
Intel® Virtual RAID On CPU (VROC) RAID 0, 1, 10, 5
Note: VROC module is compatible for Intel®SSD only
Peripheral Drives
N/A
Expansion Slots
Riser Card CRS2033:
- 1 x PCIe x16 slot (Gen4 x16), Full height half-length
- 2 x PCIe x8 slots (Gen4 x8), Full height half-length

Riser Card CRS2137:
- 1 x PCIe x16 slot (Gen4 x16 o x8), Full height half-length
- 1 x PCIe x8 slots (Gen4 x0 or x8), Full height half-length
- 1 x PCIe x16 slot (Gen4 x16 or x8), shared with OCP 2.0, Full height half-length

Riser Card CRS2027:
- 2 x PCIe x8 slots (Gen4 x8), Low profile half-length

1 x OCP 3.0 mezzanine slot with PCIe Gen4 x16 bandwidth from CPU_0
Supported NCSI function

1 x OCP 2.0 mezzanine slot with PCIe Gen3 x8 bandwidth from CPU_1
Supported NCSI function
Internal I/O
2 x CPU fan headers
1 x USB 3.0 header
1 x TPM header
1 x VROC connector
1 x Front panel header
1 x HDD back plane board header
1 x IPMB connector
1 x Clear CMOS jumper
1 x BIOS recovery jumper
Front I/O
2 x USB 3.0
1 x Power button with LED
1 x ID button with LED
1 x Reset button
1 x NMI button
1 x System status LED
1 x HDD activity LED
2 x LAN activity LEDs
Rear I/O
2 x USB 3.0
1 x VGA
2 x RJ45
1 x MLAN
1 x ID button with LED
Backplane I/O
Front side_CBP20C5: 8 x SATA/SAS and 4 x SATA/SAS/NVMe ports
Rear side_CBP2022: 2 x SATA ports
Bandwidth: PCIe Gen4 x4 or SATA 6Gb/s or SAS 12Gb/s per port
TPM
1 x TPM header with SPI interface
Optional TPM2.0 kit: CTM010
Power Supply
2 x 1600W redundant PSUs
80 PLUS Platinum

AC Input:
- 100-120V~/ 12A, 50-60Hz
- 200-240V~/ 10.0A, 50-60Hz

DC Input:
240Vdc, 10A

DC Output:
- Max 1000W/ 100-120V~
+12V/ 81.5A
+12Vsb/ 2.5A
- Max 1600W at 200-240V or 240Vdc Input
+12V/ 133A
+12Vsb/ 2.5A
System Management
Aspeed® AST2600 management controller
GIGABYTE Management Console (AMI MegaRAC SP-X) web interface

  • Dashboard
  • JAVA Based Serial Over LAN
  • HTML5 KVM
  • Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
  • Sensor Reading History Data
  • FRU Information
  • SEL Log in Linear Storage / Circular Storage Policy
  • Hardware Inventory
  • Fan Profile
  • System Firewall
  • Power Consumption
  • Power Control
  • LDAP / AD / RADIUS Support
  • Backup & Restore Configuration
  • Remote BIOS/BMC/CPLD Update
  • Event Log Filter
  • User Management
  • Media Redirection Settings
  • PAM Order Settings
  • SSL Settings
  • SMTP Settings
OS Compatibility
Windows Server 2016
Windows Server 2019

Red Hat Enterprise Linux 8.2 ( x64) or later
Red Hat Enterprise Linux 8.3 ( x64) or later

SUSE Linux Enterprise Server 12 SP5 ( x64) or later
SUSE Linux Enterprise Server 15 SP2 ( x64) or later

Ubuntu 20.04 LTS (x64) or later
Ubuntu 20.04.1 LTS (x64) or later

VMware ESXi 6.7 Update3 P03
VMware ESXi 7.0 Update2
System Fans
4 x 80x80x38mm (16'300rpm)
Operating Properties
Operating temperature: 10°C to 35°C
Operating humidity: 8-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)
Packaging Dimensions
982 x 588 x 268 mm
Packaging Content
1 x R282-NO0
2 x CPU heatsinks
1 x Rail kit
1 x VROC module
Part Numbers
Barebone package: 6NR282NO0MR-00
Part Numbers:
- Motherboard: 9MR92FS0NR-00
- Rail kit: 25HB2-3A0202-K0R
- CPU heatsink: 25ST1-343102-M1R
- Back plane board_12-port: 9CBP20C5NR-00
- Back plane board_2-port: 9CBP2022NR-00
- Front panel board: 9CFP2001NR-00
- Power supply: 25EP0-216008-L0S
- RJ45 type COM cable: 25CR0-200400-Y4R (in option)
- Riser card - CRS2033: 9CRS2033NR-00
- Riser card - CRS2137: 9CRS2137NR-00
- Riser card - CRS2027: 9CRS2027NR-00
