S452-Z30
Storage Server - AMD EPYC™ 7003/7002 - 4U UP 42-Bay Gen3 NVMe/SATA/SAS
- Single AMD EPYC™ 7003/7002 Series Processors
- 8-Channel DDR4 RDIMM/LRDIMM, 16 x DIMMs
- 2 x 1Gb/s LAN ports via Intel® I350-AM2
- 36 x 3.5"/2.5" SATA/SAS hot-swap bays
- 4 x 2.5" Gen3 NVMe/SATA hot-swap bays on the rear side
- 2 x 2.5" SATA hot-swap bays on the rear side
- SAS expander with 12Gb/s transfer speed
- 2 x M.2 slots with PCIe Gen3 x4 interface
- 4 x LP PCIe Gen4 x16 and x8 slots
- 2 x LP PCIe Gen3 x16 and x8 slots
- 1+1 1200W 80 PLUS Platinum redundant power supplies (-A00)
- 1+1 1300W 80 PLUS Platinum redundant power supplies (-A01/-B0x)
- 1+1 1300W 80 PLUS Titanium redundant power supplies (-ATx)
- 產品介紹
- 產品規格
- 支援與下載
- 相關資源
產品規格
Dimensions (WxHxD, mm)
4U
482.6 x 177 x 625
482.6 x 177 x 625
Motherboard
MZ32-AR0
CPU
AMD EPYC™ 7003 Series Processors
AMD EPYC™ 7002 Series Processors
Single processor, cTDP up to 180W
AMD EPYC™ 7002 Series Processors
Single processor, cTDP up to 180W
Socket
1 x LGA 4094
Socket SP3
Socket SP3
Chipset
System on Chip
Memory
16 x DIMM slots
DDR4 memory supported
8-Channel memory per processor
RDIMM/LRDIMM: Up to 3200/2933 MT/s [1]
[1] Follow BIOS setting and memory QVL if running 3200 MT/s with 2DPC.
DDR4 memory supported
8-Channel memory per processor
RDIMM/LRDIMM: Up to 3200/2933 MT/s [1]
[1] Follow BIOS setting and memory QVL if running 3200 MT/s with 2DPC.
LAN
Rear:
2 x 1Gb/s LAN (1 x Intel® I350-AM2)
- Support NCSI function
1 x 10/100/1000 Mbps Management LAN
2 x 1Gb/s LAN (1 x Intel® I350-AM2)
- Support NCSI function
1 x 10/100/1000 Mbps Management LAN
Video
Integrated in ASPEED® AST2500
- 1 x VGA port
- 1 x VGA port
Storage
Front hot-swap:
24 x 3.5"/2.5" SATA/SAS [1]
Rear hot-swap:
12 x 3.5"/2.5" SATA/SAS [1]
4 x 2.5" Gen3 NVMe/SATA [2]
2 x 2.5" SATA [2]
Internal M.2:
2 x M.2 (2242/2260/2280), PCIe Gen3 x4
[1] Storage card is required to enable SATA and SAS drives.
- Broadcom SAS35x48 expander
- Bandwidth: SATA 6Gb/s or SAS 12Gb/s per port
[2] Rear side 2.5" bays only support Solid State Drives due to thermal consideration.
24 x 3.5"/2.5" SATA/SAS [1]
Rear hot-swap:
12 x 3.5"/2.5" SATA/SAS [1]
4 x 2.5" Gen3 NVMe/SATA [2]
2 x 2.5" SATA [2]
Internal M.2:
2 x M.2 (2242/2260/2280), PCIe Gen3 x4
[1] Storage card is required to enable SATA and SAS drives.
- Broadcom SAS35x48 expander
- Bandwidth: SATA 6Gb/s or SAS 12Gb/s per port
[2] Rear side 2.5" bays only support Solid State Drives due to thermal consideration.
SAS
Supported via storage cards
RAID
Require RAID add-in cards
PCIe Expansion Slots
Slot_6: LP PCIe x16 (Gen4 x16)
Slot_5: LP PCIe x16 (Gen4 x8)
Slot_4: LP PCIe x16 (Gen4 x16)
Slot_3: LP PCIe x16 (Gen4 x16)
Slot_2: LP PCIe x8 (Gen3 x0 or x8)
Slot_1: LP PCIe x16 (Gen3 x16 or x8), shared with Slot_2
1 x OCP 2.0 mezzanine (Gen3 x16)(Type1, P1, P2, P3, P4) [1]
- Supports NCSI function
[1] Installing an OCP 2.0 mezzanine card requires removal of the rear 4-bay drive cage.
Slot_5: LP PCIe x16 (Gen4 x8)
Slot_4: LP PCIe x16 (Gen4 x16)
Slot_3: LP PCIe x16 (Gen4 x16)
Slot_2: LP PCIe x8 (Gen3 x0 or x8)
Slot_1: LP PCIe x16 (Gen3 x16 or x8), shared with Slot_2
1 x OCP 2.0 mezzanine (Gen3 x16)(Type1, P1, P2, P3, P4) [1]
- Supports NCSI function
[1] Installing an OCP 2.0 mezzanine card requires removal of the rear 4-bay drive cage.
Front I/O
2 x USB 3.0 ports
1 x Power button with LED
1 x ID button with LED
1 x Reset button
2 x LAN activity LEDs
1 x System status LED
1 x Power button with LED
1 x ID button with LED
1 x Reset button
2 x LAN activity LEDs
1 x System status LED
Rear I/O
3 x USB 3.0 ports
1 x VGA port
1 x COM_1 port
2 x RJ45 ports
1 x MLAN port
1 x ID button with LED
1 x VGA port
1 x COM_1 port
2 x RJ45 ports
1 x MLAN port
1 x ID button with LED
Backplane Board
Speed and bandwidth:
Front - CBPD4O0: SATA 6Gb/s or SAS 12Gb/s
Rear - CBPD0C0: SATA 6Gb/s or SAS 12Gb/s
Rear - CBP2021: SATA 6Gb/s
Rear - COBPU43: PCIe Gen3 x4 or SATA 6Gb/s
Front - CBPD4O0: SATA 6Gb/s or SAS 12Gb/s
Rear - CBPD0C0: SATA 6Gb/s or SAS 12Gb/s
Rear - CBP2021: SATA 6Gb/s
Rear - COBPU43: PCIe Gen3 x4 or SATA 6Gb/s
Security Modules
1 x TPM header with SPI interface
- Optional TPM2.0 kit: CTM010
- Optional TPM2.0 kit: CTM010
Power Supply[#1]
1+1 1200W 80 PLUS Platinum redundant power supplies (-A00)
AC Input:
- 100-127V~/ 12.47A, 47-63Hz
- 200-240V~/ 7.08A, 47-63Hz
DC Input: (Only for China)
- 240Vdc/ 7A
DC Output:
- Max 1000W/ 100-127V~
+12V/ 82A
+12Vsb/ 2A
- Max 1200W/ 200-240V~ or 240Vdc Input
+12V/ 98A
+12Vsb/ 2A
1+1 1300W 80 PLUS Platinum redundant power supplies (-A01/B0x)
AC Input:
- 100-240V~/ 12-7A, 50-60Hz
- 200-240V~/ 8A, 50-60Hz
DC Input: (Only for China)
- 240Vdc/ 6.5A
DC Output:
- Max 1000W/ 100-240V~
+12V/ 80.5A
+12Vsb/ 3A
- Max 1300W/ 200-240V~ or 240Vdc Input
+12V/ 105.4A
+12Vsb/ 3A
1+1 1300W 80 PLUS Titanium redundant power supplies (-ATx)
AC Input:
- 100-127V~/ 12A, 50-60Hz
- 200-240V~/ 8A, 50-60Hz
DC Input: (Only for China)
- 240Vdc/ 7A
DC Output:
- Max 1000W/ 100-127V~
+12.2V/ 82A
+12.2Vsb/ 3A
- Max 1300W/ 200-240V~ or 240Vdc Input
+12.2V/ 106A
+12.2Vsb/ 3A
AC Input:
- 100-127V~/ 12.47A, 47-63Hz
- 200-240V~/ 7.08A, 47-63Hz
DC Input: (Only for China)
- 240Vdc/ 7A
DC Output:
- Max 1000W/ 100-127V~
+12V/ 82A
+12Vsb/ 2A
- Max 1200W/ 200-240V~ or 240Vdc Input
+12V/ 98A
+12Vsb/ 2A
1+1 1300W 80 PLUS Platinum redundant power supplies (-A01/B0x)
AC Input:
- 100-240V~/ 12-7A, 50-60Hz
- 200-240V~/ 8A, 50-60Hz
DC Input: (Only for China)
- 240Vdc/ 6.5A
DC Output:
- Max 1000W/ 100-240V~
+12V/ 80.5A
+12Vsb/ 3A
- Max 1300W/ 200-240V~ or 240Vdc Input
+12V/ 105.4A
+12Vsb/ 3A
1+1 1300W 80 PLUS Titanium redundant power supplies (-ATx)
AC Input:
- 100-127V~/ 12A, 50-60Hz
- 200-240V~/ 8A, 50-60Hz
DC Input: (Only for China)
- 240Vdc/ 7A
DC Output:
- Max 1000W/ 100-127V~
+12.2V/ 82A
+12.2Vsb/ 3A
- Max 1300W/ 200-240V~ or 240Vdc Input
+12.2V/ 106A
+12.2Vsb/ 3A
System Management
ASPEED® AST2500 Baseboard Management Controller
GIGABYTE Management Console web interface
GIGABYTE Management Console web interface
- Dashboard
- JAVA Based Serial Over LAN
- HTML5 KVM
- Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
- Sensor Reading History Data
- FRU Information
- SEL Log in Linear Storage/Circular Storage Policy
- Hardware Inventory
- Fan Profile
- System Firewall
- Power Consumption
- Power Control
- LDAP / AD / RADIUS Support
- Backup & Restore Configuration
- Remote BIOS/BMC/CPLD Update
- Event Log Filter
- User Management
- Media Redirection Settings
- PAM Order Settings
- SSL Settings
- SMTP Settings
OS Compatibility
Citrix Hypervisor 8.2.0 or later
Red Hat Enterprise Linux 8.3 or later
Red Hat Enterprise Linux 9.0 or later
SUSE Linux Enterprise Server 12 SP5 or later
SUSE Linux Enterprise Server 15 SP2 or later
Ubuntu 18.04.5 LTS or later
Ubuntu 20.04 LTS or later
Ubuntu 22.04 LTS or later
VMware ESXi 6.7 Update3 P03 or later
VMware ESXi 7.0 Update1 or later
VMware ESXi 8.0 or later
Windows Server 2016 (X2APIC/256T not supported)
Windows Server 2019
Windows Server 2022
Red Hat Enterprise Linux 8.3 or later
Red Hat Enterprise Linux 9.0 or later
SUSE Linux Enterprise Server 12 SP5 or later
SUSE Linux Enterprise Server 15 SP2 or later
Ubuntu 18.04.5 LTS or later
Ubuntu 20.04 LTS or later
Ubuntu 22.04 LTS or later
VMware ESXi 6.7 Update3 P03 or later
VMware ESXi 7.0 Update1 or later
VMware ESXi 8.0 or later
Windows Server 2016 (X2APIC/256T not supported)
Windows Server 2019
Windows Server 2022
System Fans
8 x 80x80x38mm
Operating Properties
Operating temperature: 10°C to 35°C
Operating humidity: 8% to 80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20% to 95% (non-condensing)
Operating humidity: 8% to 80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20% to 95% (non-condensing)
Weight
Net Weight: 30 kg
Gross Weight: 48.4 kg
Gross Weight: 48.4 kg
Packaging Dimensions
843 x 610 x 290 mm
Packaging Content
1 x S452-Z30
1 x CPU heatsink
1 x 3-Section Rail kit
1 x CPU heatsink
1 x 3-Section Rail kit
Part Numbers
- Barebone package: 6NS452Z30MR-00-A*/B*
- Motherboard: 9MZ32AR0NR-00*
- 3-Section Rail kit: 25HB2-3A6104-I0R
- CPU heatsink: 25ST1-44320G-A0R
- Backplane board - CBPD0C0: 9CBPD0C0NR-00*
- Backplane board - CBPD4O0: 9CBPD4O0NR-00*
- Backplane board - CBP2021: 9CBP2021NR-00*
- Backplane board - COBPU43: 9COBPU43NR-00*
- Fan module: 25ST2-883829-D0R
- Power supply (-A00): 25EP0-212003-D0S
- Power supply (-A01/-B0x): 25EP0-21300B-F3S
- Power supply (-ATx): 25EP0-21300C-G1S
Optional parts:
- RMA packaging: 6NS452Z30SR-RMA-A100
- Motherboard: 9MZ32AR0NR-00*
- 3-Section Rail kit: 25HB2-3A6104-I0R
- CPU heatsink: 25ST1-44320G-A0R
- Backplane board - CBPD0C0: 9CBPD0C0NR-00*
- Backplane board - CBPD4O0: 9CBPD4O0NR-00*
- Backplane board - CBP2021: 9CBP2021NR-00*
- Backplane board - COBPU43: 9COBPU43NR-00*
- Fan module: 25ST2-883829-D0R
- Power supply (-A00): 25EP0-212003-D0S
- Power supply (-A01/-B0x): 25EP0-21300B-F3S
- Power supply (-ATx): 25EP0-21300C-G1S
Optional parts:
- RMA packaging: 6NS452Z30SR-RMA-A100
[#1] 伺服器產品未附帶電源線。客戶需自行選擇適當的電源線 (可選配件)，或聯繫業務協助客製化。
[#2] 本網站所提供之產品規格、圖片及其他資訊僅供參考，如有差異應以實際產品為準。技嘉科技保留隨時修改內容的權利，並不對因使用上述資料而導致的任何損失承擔責任。
[#3] 本產品所標示之效能數據為晶片廠商或相關介面標準制定組織所公佈的最大理論值，實際效能可能因系統配置及使用環境而有所不同。
[#4] 本文所使用的所有商標及企業識別標誌均為其合法所有者的財產。
