W331-Z00

(rev. 100)

Mini-Tower
198 x 370 x 375 mm

MC12-NB0

AMD Ryzen™ 5000 Series Processors
AMD Ryzen™ 4000 Series Processors
AMD Ryzen™ 3000 Series Processors

Note:
- Recommend to install CPU TDP under 65W with entry CPU fansink (low-noise) for general PC purpose.
- Recommend to install CPU TDP between 65-105W with advanced CPU fansink (high-noise) for gaming/design PC purpose.

1 x AM4

AMD B550

4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory
Dual channel memory architecture
Support ECC Unbuffered DIMM 1Rx8/2Rx8 memory modules
Support Non-ECC Unbuffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Memory speed: Up to 3200/2933/2667/2400/2133 MT/s

2 x 1Gb/s LAN ports (Realtek^® RTL8111EPV and RTL8118)

1 x DP port: Maximum resolution of 4096x2160@60Hz; Supports DP 1.2.
1 x HDMI port: Maximum resolution of 4096x2160@60Hz; Supports HDMI 2.1, HDCP 2.3, HDR.

Realtek^® ALC897 audio codec
High Definition audio; 2/4/5.1/7.1-channel
3 ports Audio Jack (Line in/Line out/Mic)

2 x 3.5"/2.5" SATA fixed bays

N/A

Optional ODD devices

1 x PCIe x16 (Gen4 x16) slot, from CPU
1 x PCIe x16 (Gen3 x4) slot, from FCH
1 x PCIe x1 (Gen3 x1) slot, from FCH

1 x M.2 slot:
- M-key
- PCIe Gen4 x4, from CPU
- Supports 2242/2280 cards

1 x M.2 slot:
- M-key
- PCIe Gen3 x2 / SATA III, from FCH
- Supports 2242/2280 cards

1 x M.2 slot for Wi-Fi:
- E-key
- PCIe Gen3 x1, from FCH
- Supports 2230 cards

1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
4 x SATA 6Gb/s ports
1 x CPU fan header
3 x System fan headers
1 x USB 2.0 header
1 x Serial header (COM)
1 x Front panel header
1 x Front Audio header
1 x Front USB3.2 header

2 x USB3.0 ports
1 x Line out port
1 x Mic in port
1 x Power Button
1 x Storage activity LED
1 x Reset Button

1 x Display port
1 x HDMI port
2 x Antenna ports
2 x USB 3.0 type A
2 x 1Gb/s RJ45 LAN ports
4 x USB 2.0 type A
3 x Audio Jacks (Line in / Line out / Mic in)

Onboard with SPI interface

Single 500W 80 PLUS Bronze power supply

AC Input:
- 100-240V~/ 7-3A, 50-60Hz

DC Output:
- Max 500W/ 100-240V~
+12V/ 41.66A
+5V/ 20A
+3.3V/ 20A
+5Vsb/ 2.5A

Realtek^® DASH Remote Management

- Power state settings (on, off, restart, hibernate, or sleep)
- View hardware, firmware or BIOS versions
- Retrieve system health status
- USB device redirection
- Boot device selection
- View event logs
- Apply updates and security patches
- Text Console Redirection
- Software KVM

Windows 10 (64bit)
Windows 11 (64bit)

2 x 92x92x25mm (4,500rpm)

Operating temperature: 0°C to 35°C
Operating humidity: 8%-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)

512 x 324 x 503 mm

1 x W331-Z00
1 x Quick Start Guide

Note: The CPU fansink is not included by default. Fansinks included in the AMD CPU package are recommended. Other verified fansinks are listed in the QVL.

- Barebone package: 6BW331Z00MR-00-1*
- Chassis kit: 25EC2-W33100-C1R
- Motherboard: 5MC12NB0MR-00-10B
- I/O Shield: 12AIO-W331Z0-00R
- System Fan: 25Y00-92250-A20R
- SATA cable: 25CF4-350500-S9R
- Power supply: 25EP0-20500C-F3S
