W771-Z00
(rev. 100)
AMD® Ryzen™ Threadripper™ PRO Tower GPU Workstation
| Application:
人工智慧平台
,
人工智慧訓練伺服器
,
人工智慧推論伺服器
,
視覺特效演算
&
高效能運算伺服器
- AMD Ryzen™ Threadripper™ PRO 5000WX and 3000WX Processors
- 8-Channel DDR4 UDIMM/RDIMM/3DS RDIMM/LRDIMM 8 x DIMMs
- Dual Intel® 10GbE and 1GbE LAN Ports
- 1x Dedicated Management Port
- 7x PCIe 4.0 Slots for Multi-GPU
- Up to 8x 3.5” SATA HDD Bays and 2x M.2 (NVMe and SATA mode)
- Default 6x system Fan, and optional external 2x GPU Fan
- 2x 2000W CRPS RPSU 80+ Platinum
Get a Quote
* 以上產品之規格、圖片及其他資訊僅供參考,如與實際產品有任何不相符之處,應以實際產品為準。技嘉科技保留在任何時間做出修改之權利。對任何因使用上述資料而引致之損失,技嘉科技概不承擔任何責任。
* 本產品所標示之各項效能表現為各晶片廠商或各制定介面官方組織所提出的最大理論值,實際效能可能因規格及設備而有所不同。
* 本文中所使用之各項商標及企業識別圖示,均為其合法所有人之財產。
* 基於PC基本架構,有部分記憶體空間須留作系統用途,故所偵測到之記憶體大小會比實際上較少。
* 本產品所標示之各項效能表現為各晶片廠商或各制定介面官方組織所提出的最大理論值,實際效能可能因規格及設備而有所不同。
* 本文中所使用之各項商標及企業識別圖示,均為其合法所有人之財產。
* 基於PC基本架構,有部分記憶體空間須留作系統用途,故所偵測到之記憶體大小會比實際上較少。
SPECIFICATIONS
Dimensions (WxHxD, mm)
Pedestal
175 x 438 x 680 mm
175 x 438 x 680 mm
Motherboard
MC62-G40
CPU
AMD® Ryzen™ Threadripper™ PRO 5000WX Processor
AMD® Ryzen™ Threadripper™ PRO 3000WX Processor
Processor up to 64-core, 128 threads
TDP up to 280W
AMD® Ryzen™ Threadripper™ PRO 3000WX Processor
Processor up to 64-core, 128 threads
TDP up to 280W
Socket
sWRX8 Socket
Chipset
AMD® WRX80
Memory
8 x DIMM slots
DDR4 memory module supported only
8 channel memory architecture
Support for 3200/2933/2666/2400/2133 MHz; ECC & non-ECC; buffered & unbuffered; UDIMM, RDIMM, 3DS R-DIMM, LRDIMM
Total up to 2TB of system memory (256GB single LRDIMM capacity)
DDR4 memory module supported only
8 channel memory architecture
Support for 3200/2933/2666/2400/2133 MHz; ECC & non-ECC; buffered & unbuffered; UDIMM, RDIMM, 3DS R-DIMM, LRDIMM
Total up to 2TB of system memory (256GB single LRDIMM capacity)
LAN
2 x 10GbE LAN (Intel® X550-AT2)
1 x GbE LAN (Intel® i210)
1 x 10/100/1000 management LAN
1 x GbE LAN (Intel® i210)
1 x 10/100/1000 management LAN
Video
Integrated in Aspeed® AST2600
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp
Audio
Realtek® ALC4080 HD audio codec
Supports 7.1 channel configurations
3 ports Audio Jack (Audio in/Audio out/Mic)
Supports 7.1 channel configurations
3 ports Audio Jack (Audio in/Audio out/Mic)
Storage
4 x 3.5" / 2.5" SATAIII hot-swappable HDD/SSD bays
Additional 4 x 3.5" / 2.5" SATAIII hot-swappable HDD/SSD bays (Option)
2 x M.2 slot for storage (M-Key; NGFF-2242/2280; PCIe Gen4 x4 or SATA III 6Gb/s)
SAS card is required for SAS devices support
Additional 4 x 3.5" / 2.5" SATAIII hot-swappable HDD/SSD bays (Option)
2 x M.2 slot for storage (M-Key; NGFF-2242/2280; PCIe Gen4 x4 or SATA III 6Gb/s)
SAS card is required for SAS devices support
RAID
RAID 0, RAID 1, RAID 5 and RAID 10
Peripheral Drives
2 x 5.25" space reserved for ODD device
Expansion Slots
Slot_7: 1 x PCIe x16 (Gen4 x16) slot
Slot_6: 1 x PCIe x16 (Gen4 x16) slot
Slot_5: 1 x PCIe x16 (Gen4 x16) slot
Slot_4: 1 x PCIe x16 (Gen4 x16) slot
Slot_3: 1 x PCIe x16 (Gen4 x16) slot
Slot_2: 1 x PCIe x16 (Gen4 x8) slot
Slot_1: 1 x PCIe x16 (Gen4 x16) slot
2 x M.2 slot for storage:
- M-key
- PCIe Gen4 x4 or 4x SATA 6Gb/s
- Supports NGFF-2242/2280 card
1 x M.2 slot for Wi-Fi:
- E-key
- Supports NGFF-2230 card
Slot_6: 1 x PCIe x16 (Gen4 x16) slot
Slot_5: 1 x PCIe x16 (Gen4 x16) slot
Slot_4: 1 x PCIe x16 (Gen4 x16) slot
Slot_3: 1 x PCIe x16 (Gen4 x16) slot
Slot_2: 1 x PCIe x16 (Gen4 x8) slot
Slot_1: 1 x PCIe x16 (Gen4 x16) slot
2 x M.2 slot for storage:
- M-key
- PCIe Gen4 x4 or 4x SATA 6Gb/s
- Supports NGFF-2242/2280 card
1 x M.2 slot for Wi-Fi:
- E-key
- Supports NGFF-2230 card
Internal I/O
1 x 24-pin ATX main power connector
2 x 8-pin ATX 12V power connectors
1 x CPU Fan header
1 x PCH Fan header
8 x System Fan headers
2 x USB 3.0 headers for 4 ports
1 x PMBus connector
4 x SATA III 6Gb/s ports
2 x M.2 slot for storage
1 x M.2 slot for Wi-Fi
3 x slimSAS connectors
1 x Front panel header
1 x Back plane board header
1 x PMBus header
1 x IPMB header
1 x TPM header
1 x COM header 6 x System fan headers
1 x USB 3.0 header
2 x COM headers
1 x TPM header
1 x Front panel header
1 x HDD back plane board header
1 x PMBus connector
1 x IPMB connector
1 x Clear CMOS jumper
1 x BIOS recovery jumper
2 x 8-pin ATX 12V power connectors
1 x CPU Fan header
1 x PCH Fan header
8 x System Fan headers
2 x USB 3.0 headers for 4 ports
1 x PMBus connector
4 x SATA III 6Gb/s ports
2 x M.2 slot for storage
1 x M.2 slot for Wi-Fi
3 x slimSAS connectors
1 x Front panel header
1 x Back plane board header
1 x PMBus header
1 x IPMB header
1 x TPM header
1 x COM header 6 x System fan headers
1 x USB 3.0 header
2 x COM headers
1 x TPM header
1 x Front panel header
1 x HDD back plane board header
1 x PMBus connector
1 x IPMB connector
1 x Clear CMOS jumper
1 x BIOS recovery jumper
Front I/O
1 x Front Panel Lock
2 x USB 3.0
1 x Power button
1 x Reset button
1 x Power LED
1 x Hard drives status LED
1 x System status LED
1 x UID LED
2 x LAN activity/link LEDs
4 x Hard drive bays
2 x USB 3.0
1 x Power button
1 x Reset button
1 x Power LED
1 x Hard drives status LED
1 x System status LED
1 x UID LED
2 x LAN activity/link LEDs
4 x Hard drive bays
Rear I/O
1 x VGA
1 x ID Button
2 x USB 3.2 gen2 (Type-A + Type-C®)
1 x RJ45 (GbE LAN)
1 x MLAN
4 x USB 3.2 gen2 Type-A
2 x RJ45 (red) (10GbE LAN)
1 x 3 in 1 Audio jacks 1 x Power switch with LED
1 x ID Button
2 x USB 3.2 gen2 (Type-A + Type-C®)
1 x RJ45 (GbE LAN)
1 x MLAN
4 x USB 3.2 gen2 Type-A
2 x RJ45 (red) (10GbE LAN)
1 x 3 in 1 Audio jacks 1 x Power switch with LED
TPM
1 x TPM header with SPI interface
Optional TPM2.0 kit: CTM010
Optional TPM2.0 kit: CTM010
Power Supply
2 x 2000W redundant PSUs
80 PLUS Platinum
AC Input:
- 100-127V~/ 13A, 50-60Hz
- 200-240V~/ 12A, 50-60Hz
DC Output:
- Max 2000W/ 240-300V
+12.2V/ 166.7A
+12Vsb/ 3A
- Max 1560w / 180-220V
+12.2V/ 130A
+12Vsb/ 3A
- Max 996W/ 90-140V
+12.2V/ 83A
+12Vsb/ 2.1A
System Management
ASPEED® AST2600 Management Controller
GIGABYTE Management Console (AMI MegaRAC SP-X) web interface
GIGABYTE Management Console (AMI MegaRAC SP-X) web interface
- Dashboard
- HTML5 KVM
- Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
- Sensor Reading History Data
- FRU Information
- SEL Log in Linear Storage / Circular Storage Policy
- Hardware Inventory
- Fan Profile
- System Firewall
- Power Consumption
- Power Control
- LDAP / AD / RADIUS Support
- Backup & Restore Configuration
- Remote BIOS/BMC/CPLD Update
- Event Log Filter
- User Management
- Media Redirection Settings
- PAM Order Settings
- SSL Settings
- SMTP Settings
OS Compatibility
Windows 10 (64bit)
Windows 11 (64bit)
Red Hat Enterprise Linux 8.2 (64bit)
Red Hat Enterprise Linux 8.3 (64bit)
Ubuntu 20.04 LTS (64bit)
Windows 11 (64bit)
Red Hat Enterprise Linux 8.2 (64bit)
Red Hat Enterprise Linux 8.3 (64bit)
Ubuntu 20.04 LTS (64bit)
Weight
Net Weight: 22 kg
Gross Weight: 24 kg
Gross Weight: 24 kg
System Fans
4 x 80x80x38mm (11,000 rpm)
2 x 80x80x38mm (8,200 rpm)
Recommend Action: purchase additional GPU Fan module (option) to reach maximum computing performance if system is installed multiple GPU cards with up to 300w power consumption.
2 x 80x80x38mm (8,200 rpm)
Recommend Action: purchase additional GPU Fan module (option) to reach maximum computing performance if system is installed multiple GPU cards with up to 300w power consumption.
Operating Properties
Operating temperature: 10°C to 35°C
Operating humidity: 8-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)
Operating humidity: 8-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)
Packaging Dimensions
1078 x 588 x 388 mm
Packaging Content
1 x W771-Z00
1 x CPU Fan-sink
1 x Quick installation guide
1 x CPU Fan-sink
1 x Quick installation guide
Part Numbers
Barebone package: 6NW771Z00MR-00-1*
- Motherboard: 9MC62G40MR-00*
- I/O shield: 12AIO-MC62G4-00R
- Power supply: 25EP0-22000G-A0S
- GPU Fan module: 25HB1-MC6200-C0R (option)
- Additional HDD cage: 25HB1-MC6201-C0R (option)
- Rail kit for W771-Z00 (option, (A)+(B))
(A) 25HB2-A66123-C0R (Slide Rail), Q'ty: 1 set
(B) 25HB4-MC6200-C0R (Handle + Rack ear + Rail screws), Q'ty: 1 set
- CPU Fan-Sink: (option, (A)+(B))
(A) 25ST2-88382C-D0R (Fan)
(B) S25ST1-243103-A0R (Sink)
- Motherboard: 9MC62G40MR-00*
- I/O shield: 12AIO-MC62G4-00R
- Power supply: 25EP0-22000G-A0S
- GPU Fan module: 25HB1-MC6200-C0R (option)
- Additional HDD cage: 25HB1-MC6201-C0R (option)
- Rail kit for W771-Z00 (option, (A)+(B))
(A) 25HB2-A66123-C0R (Slide Rail), Q'ty: 1 set
(B) 25HB4-MC6200-C0R (Handle + Rack ear + Rail screws), Q'ty: 1 set
- CPU Fan-Sink: (option, (A)+(B))
(A) 25ST2-88382C-D0R (Fan)
(B) S25ST1-243103-A0R (Sink)
