SPECIFICATIONS

Dimensions (WxHxD, mm)
1U
440 x 43.5 x 900 mm
Motherboard
MG30-NV0
CPU
Intel® Xeon® E5-2600 v4 processors supported
Intel® Xeon® E5-2600 v3 processors supported
NOTE: If only 1 CPU is installed, some PCIe or memory functions might be unavailable
Socket
2 x LGA 2011-3
Mounting pitch: square ILM (80x80mm)
Chipset
Intel® C612
Memory
16 x DIMM slots
DDR4 memory supported only
Quad channel memory architecture
RDIMM modules up to 32GB supported
LRDIMM modules up to 64GB supported
3DS LRDIMM modules up to 128GB supported
1.2V modules: 2133/2400 MHz
LAN
2 x GbE LAN ports (Intel® I350-AM2)
1 x 10/100/1000 management LAN
Video
Integrated in Aspeed® AST2400
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp
Audio
-
Storage
4 x 2.5" hot-swappable HDD/SSD bays
SAS card is required for SAS devices support
SATA
-
SAS
Supported via add-on SAS Card
RAID
Intel® SATA RAID 0/1/5/10
Peripheral Drives
-
Expansion Slots
4 x NVIDIA Tesla® V100 SXM2 modules
Up to 300GB/s GPU interconnection by NVIDIA® NVLINK technology

2 x PCIe x16 slots (Gen3 x16), Low profile half-length
Internal I/O
2 x power supply connectors
1 x Back plane power connector
1 x Mini-SAS HD SFF8643 connector
1 x USB 3.0 header
1 x COM
1 x TPM header
1 x PMBUS header
1 x IPMB connector
1 x Clear CMOS jumper
Front I/O
2 x USB 3.0
3 x RJ45
1 x VGA
1 x Power Button with LED
1 x ID Button with LED
1 x Reset Button
1 x NMI Button
Rear I/O
-
Backplane I/O
4 x SAS / SATA ports
TPM
1 x TPM header with LPC interface
Optional TPM2.0 kit: CTM000
Power Supply
2 x 2000W redundant PSU
80 PLUS Titanium

AC input:
- 1000W: 100-127V/ 12-9.5A, 50-60Hz
- 1800W: 200-220V/ 10-9.5A, 50-60Hz
- 1980W: 220-230V/ 10-9.8A, 50-60Hz
- 2000W: 230-240V/ 10-9.8A, 50-60Hz

DC output:
Max 1000W@100-127V:
+12V/ 83.3A
+12Vsb/ 2.1A
1800W@200-220V
+12V/ 150.0A
+12Vsb/ 2.1A
1980W@220-230V
+12V/ 165.0A
+12Vsb/ 2.1A
2000W@200-240V
+12V/ 166.7A
+12Vsb/ 2.1A

NOTE: Redundant function could not be supported if SXM2 modules are fully populated
System Management
Aspeed® AST2400 management controller
Avocent® MergePoint IPMI 2.0 web interface:
  • Network settings
  • Network security settings
  • Users control
  • Services settings
  • IPMI settings
  • Sessions control
  • LDAP settings
  • Power control
  • Voltages, fans and temperatures monitoring
  • System event log
  • Events management (platform events, trap settings, email settings)
  • Serial Over LAN
  • vKVM & vMedia (launch, configuration)
OS Compatibility
Windows Server 2008 R2 (x64)
Windows Server 2012 R2 (x64)
Windows Server 2016

Red Hat Enterprise Linux 6.7 (x86/x64)
Red Hat Enterprise Linux 7.2 (x64)

SUSE Linux Enterprise Server 11.4 (x86/x64)
SUSE Linux Enterprise Server 12 (x64)

Ubuntu 12.04 LTS (x86/x64)
Ubuntu 14.04 LTS (x86/x64)

VMware ESXi 5.1 U2
VMware ESXi 5.5 U2
VMware ESXi 6.0 U1
VMware ESXi 6.5
Weight
Gross Weight: 32Kg
System Fans
10 x 40x56mm Dual Rotor Fan
4 x 40x56mm Single Rotor Fan
Operating Properties
Operating temperature: 10°C to 35°C
Operating humidity: 8%-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)
Packaging Dimensions
1185 x 739 x 245 mm
Packaging Content
1 x G190-G30
2 x CPU heatsinks
4 x GPU heatsinks
1 x Rail kit
Part Numbers
Barebone package: 6NG190G30MR-00
Part Numbers:
- Motherboard: 9MG30NV0NR-00
- Rail kit: 25HB2-NJ2101-N1R
- CPU heatsink: 25ST1-423300-C1R
- GPU heatsink: 25ST1-253103-F2R
- NVLINK motherboard: 5CPBG300NR-00
- Back plane board: 9CBPG040NR-00
- Power supply: 25EP0-220003-C2S
- Front panel board: 9CFPG011NR-00
- PCIe x16 cable 660mm: 25CRF-660000-30R
- PCIe x16 cable 480mm: 25CRF-480000-30R
- PCIe x16 cable 210mm: 25CRF-210000-30R
* The entire materials provided herein are for reference only. GIGABYTE reserves the right to modify or revise the content at anytime without prior notice.
* Advertised performance is based on maximum theoretical interface values from respective Chipset vendors or organization who defined the interface specification. Actual performance may vary by system configuration.
* All trademarks and logos are the properties of their respective holders.
* Due to standard PC architecture, a certain amount of memory is reserved for system usage and therefore the actual memory size is less than the stated amount.

SUPPORT

  • Choose your OS
  • Choose your OS
  • Windows Server 2016 64bit
  • Windows Server 2012 R2 64bit
  • Windows Server 2012 64bit
  • Windows Server 2008 R2 64bit
  • Ubuntu 14.04 LTS x86
  • Ubuntu 14.04 LTS x64
  • Ubuntu 12.04 LTS x86
  • Ubuntu 12.04 LTS x64
  • SLES 12 x64
  • SLES 11.4 x86
  • SLES 11.4 x64
  • RHEL 7.2 x64
  • RHEL 6.7 x86
  • RHEL 6.7 x64
SAS
SAS
Version
Size
Date
GIGABYTE GC-MSLZ1 optional Card
LSI® SAS2208 Hardware RAID SAS Card
Version : 6.701.04.00
242.81 MB
2014/07/02
OS: Windows Server 2012 64bit,Windows Server 2008 R2 64bit,Windows Server 2012 R2 64bit
SATA RAID/AHCI
SATA RAID/AHCI
Version
Size
Date
Intel® SATA Preinstall driver
(For AHCI / RAID Mode)
Note: Windows setup to read from USB devices
Version : 4.5.0.1333
3.59 MB
2016/03/31
OS: Windows Server 2012 64bit,Windows Server 2008 R2 64bit,Windows Server 2012 R2 64bit
Intel® Rapid Storage Technology enterprise (Intel® RSTe)
Version : 4.5.0.1333
18.62 MB
2016/03/31
OS: Windows Server 2012 64bit,Windows Server 2008 R2 64bit,Windows Server 2012 R2 64bit
BIOS
Description
Version
Size
Date
Security update for 2019.2 Intel Platform Update (IPU)
[1] Update Microcode:Hasswell-EP M6F306F2_00000043,Broadwell-EP MEF406F1_0B000038
[2] Update ACM :SINIT 3.1.3
[3] Update Update SPS 03.01.03.72.0
Version : R05
13.21 MB
2019/12/06
