G492-HA0
(rev. 100)
HPC/AI Server - 3rd Gen Intel® Xeon® Scalable - 4U DP 10 x PCIe Gen4 GPUs (Dual Root)
- NVIDIA-Certified System - Data Center Server
- Supports up to 10 x Dual slot Gen4 GPUs
- 3rd Gen Intel® Xeon® Scalable Processors
- Dual processor, 10nm technology
- 8-Channel RDIMM/LRDIMM DDR4 per processor, 32 x DIMMs
- Supports Intel® Optane™ Persistent Memory 200 series
- Dual ROM Architecture
- Intel® C621A Chipset
- 2 x 10Gb/s BASE-T LAN ports via Intel® X550-AT2
- 1 x Dedicated management port
- 8 x 3.5"/2.5" Gen4 NVMe/SATA/SAS hot-swappable bays
- 4 x 3.5"/2.5" SATA/SAS hot-swappable bays
- 2 x SATA DOM supported
- 10 x FHFL PCIe Gen4 x16 slots for GPUs
- 3 x LP PCIe Gen4 x16 slots
- 1 x OCP 3.0 Gen4 x16 slot
- Triple 2200W 80 PLUS Platinum redundant power supply (-100)
- Triple 2200W 80 PLUS Titanium redundant power supply (-1T0)
Get a Quote
* Les informations ici proposées le sont pour référence uniquement. GIGABYTE se réserve le droit de modifier ce contenu à tout moment et sans préavis.
* Marques et logos appartiennent aux détenteurs respectifs de leurs droits.
* L'architecture de grand nombre de PC affectera directement la capacité mémoire, en effet, une certaine quantité de RAM sera affectée au système, la quantité totale affichée pourra alors varier de celle insérée sur votre carte mère
* Marques et logos appartiennent aux détenteurs respectifs de leurs droits.
* L'architecture de grand nombre de PC affectera directement la capacité mémoire, en effet, une certaine quantité de RAM sera affectée au système, la quantité totale affichée pourra alors varier de celle insérée sur votre carte mère
SPECIFICATIONS
Dimensions (WxHxD, mm)
4U
447 x 175.2 x 880
447 x 175.2 x 880
Motherboard
MG62-G41
CPU
3rd Generation Intel® Xeon® Scalable Processors
Dual processor, 10nm technology
TDP up to 270W
Note: If only 1 CPU is installed, some PCIe or memory functions might be unavailable.
Dual processor, 10nm technology
TDP up to 270W
Note: If only 1 CPU is installed, some PCIe or memory functions might be unavailable.
Socket
2 x LGA 4189
Socket P+
Socket P+
Chipset
Intel® C621A
Memory
32 x DIMM slots
DDR4 memory supported only
8-channel memory architecture
RDIMM modules up to 256GB supported
LRDIMM modules up to 256GB supported
3DS RDIMM/LRDIMM modules up to 256GB supported
1.2V modules: 3200/2933/2666 MT/s
DDR4 memory supported only
8-channel memory architecture
RDIMM modules up to 256GB supported
LRDIMM modules up to 256GB supported
3DS RDIMM/LRDIMM modules up to 256GB supported
1.2V modules: 3200/2933/2666 MT/s
LAN
Front side:
2 x 10Gb/s BASE-T LAN ports (Intel® X550-AT2)
NCSI function supported
1 x 10/100/1000 Mbps Management LAN
2 x 10Gb/s BASE-T LAN ports (Intel® X550-AT2)
NCSI function supported
1 x 10/100/1000 Mbps Management LAN
Video
Integrated in Aspeed® AST2600
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp
Storage
Front side:
8 x 3.5"/2.5" Gen4 NVMe/SATA/SAS hot-swappable bays
4 x 3.5"/2.5" SATA/SAS hot-swappable bays
SAS card is required for SAS devices support
Onboard 2 x SATA DOM supported
8 x 3.5"/2.5" Gen4 NVMe/SATA/SAS hot-swappable bays
4 x 3.5"/2.5" SATA/SAS hot-swappable bays
SAS card is required for SAS devices support
Onboard 2 x SATA DOM supported
SAS
Depends on SAS add-in cards
RAID
Intel® SATA RAID 0/1/10/5
Expansion Slots
10 x PCIe x16 (Gen4 x16) FHFL slots, from PEX88096, for GPUs
1 x PCIe x16 (Gen4 x16) low-profile slot on the rear side, from CPU_0
1 x PCIe x16 (Gen4 x16) low-profile slot on the front side, from CPU_0
1 x PCIe x16 (Gen4 x16) low-profile slot on the front side, from CPU_1
1 x OCP 3.0 slot with PCIe Gen4 x16 bandwidth on the rear side, from CPU_1
Supports NCSI function
- System is validated for population with a uniform GPU model.
- Support is not provided for mixed GPU populations.
1 x PCIe x16 (Gen4 x16) low-profile slot on the rear side, from CPU_0
1 x PCIe x16 (Gen4 x16) low-profile slot on the front side, from CPU_0
1 x PCIe x16 (Gen4 x16) low-profile slot on the front side, from CPU_1
1 x OCP 3.0 slot with PCIe Gen4 x16 bandwidth on the rear side, from CPU_1
Supports NCSI function
- System is validated for population with a uniform GPU model.
- Support is not provided for mixed GPU populations.
Internal I/O
1 x TPM header
1 x VROC connector
2 x SATA DOM connectors
1 x Front VGA header
1 x Serial header
1 x VROC connector
2 x SATA DOM connectors
1 x Front VGA header
1 x Serial header
Front I/O
2 x USB 3.0
1 x VGA
2 x RJ45
1 x MLAN
1 x Power button with LED
1 x ID button with LED
1 x Reset button
1 x NMI button
1 x System status LED
1 x Storage activity LED
1 x VGA
2 x RJ45
1 x MLAN
1 x Power button with LED
1 x ID button with LED
1 x Reset button
1 x NMI button
1 x System status LED
1 x Storage activity LED
Rear I/O
N/A
Backplane Board
Speed and bandwidth:
PCIe Gen4 x4 or SATA 6Gb/s or SAS 12Gb/s
PCIe Gen4 x4 or SATA 6Gb/s or SAS 12Gb/s
TPM
1 x TPM header with SPI interface
Optional TPM2.0 kit: CTM010
Optional TPM2.0 kit: CTM010
Power Supply
Triple 2200W 80 PLUS Platinum redundant power supply (-100)
AC Input:
- 100-127V~/ 14A, 47-63Hz
- 200-240V~/ 12.6A, 47-63Hz
DC Input: (Only for China)
- 240Vdc/ 12.6A
DC Output:
- Max 1200W/ 100-127V~
+12.12V/ 95.6A
+12Vsb/ 3.5A
- Max 2200W/ 200-240V~ or 240Vdc Input
+12.12V/ 178.1A
+12Vsb/ 3.5A
Triple 2200W 80 PLUS Platinum redundant power supply (-1T0)
AC Input:
- 100-127V~/ 15.5A, 50-60Hz
- 200-240V~/ 15.5A, 50-60Hz
DC Input: (Only for China)
- 240Vdc/ 15.5A
DC Output:
- Max 1000W/ 100-127V~
+12.2V/ 81A
+12Vsb/ 3A
- Max 2200W/ 200-240V~ or 240Vdc Input
+12.2V/ 180A
+12Vsb/ 3A
Note: The system power supply requires C19 power cord.
AC Input:
- 100-127V~/ 14A, 47-63Hz
- 200-240V~/ 12.6A, 47-63Hz
DC Input: (Only for China)
- 240Vdc/ 12.6A
DC Output:
- Max 1200W/ 100-127V~
+12.12V/ 95.6A
+12Vsb/ 3.5A
- Max 2200W/ 200-240V~ or 240Vdc Input
+12.12V/ 178.1A
+12Vsb/ 3.5A
Triple 2200W 80 PLUS Platinum redundant power supply (-1T0)
AC Input:
- 100-127V~/ 15.5A, 50-60Hz
- 200-240V~/ 15.5A, 50-60Hz
DC Input: (Only for China)
- 240Vdc/ 15.5A
DC Output:
- Max 1000W/ 100-127V~
+12.2V/ 81A
+12Vsb/ 3A
- Max 2200W/ 200-240V~ or 240Vdc Input
+12.2V/ 180A
+12Vsb/ 3A
Note: The system power supply requires C19 power cord.
System Management
Aspeed® AST2600 management controller
GIGABYTE Management Console (AMI MegaRAC SP-X) web interface
GIGABYTE Management Console (AMI MegaRAC SP-X) web interface
- Dashboard
- HTML5 KVM
- Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
- Sensor Reading History Data
- FRU Information
- SEL Log in Linear Storage / Circular Storage Policy
- Hardware Inventory
- Fan Profile
- System Firewall
- Power Consumption
- Power Control
- Advanced power capping
- LDAP / AD / RADIUS Support
- Backup & Restore Configuration
- Remote BIOS/BMC/CPLD Update
- Event Log Filter
- User Management
- Media Redirection Settings
- PAM Order Settings
- SSL Settings
- SMTP Settings
OS Compatibility
Windows Server 2016
Windows Server 2019
Windows Server 2022
Red Hat Enterprise Linux 7.9 or later
Red Hat Enterprise Linux 8.2 or later
Red Hat Enterprise Linux 9.0 or later
SUSE Linux Enterprise Server 12 SP5 or later
SUSE Linux Enterprise Server 15 SP2 or later
Ubuntu 20.04 LTS or later
Ubuntu 22.04 LTS or later
VMware ESXi 6.7 Update3 P03 or later
VMware ESXi 7.0 Update2 or later
VMware ESXi 8.0 or later
Citrix Hypervisor 8.2.0 or later
Windows Server 2019
Windows Server 2022
Red Hat Enterprise Linux 7.9 or later
Red Hat Enterprise Linux 8.2 or later
Red Hat Enterprise Linux 9.0 or later
SUSE Linux Enterprise Server 12 SP5 or later
SUSE Linux Enterprise Server 15 SP2 or later
Ubuntu 20.04 LTS or later
Ubuntu 22.04 LTS or later
VMware ESXi 6.7 Update3 P03 or later
VMware ESXi 7.0 Update2 or later
VMware ESXi 8.0 or later
Citrix Hypervisor 8.2.0 or later
System Fans
4 x 40x40x28mm (25,000rpm)
6 x 60x60x76mm (21,700rpm)
1 x 55x55x7.5mm (6,000rpm)
6 x 60x60x76mm (21,700rpm)
1 x 55x55x7.5mm (6,000rpm)
Operating Properties
Operating temperature: 10°C to 35°C
Operating humidity: 8%-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)
Operating humidity: 8%-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)
Weight
Net Weight: 34.2 kg
Packaging Dimensions
1109 x 609 x 606 mm
Packaging Content
1 x G492-HA0
2 x CPU fansinks
8 x GPU power cables (CPU 8pin to CPU 8pin, 100mm)
1 x L-shape Rail kit
2 x CPU fansinks
8 x GPU power cables (CPU 8pin to CPU 8pin, 100mm)
1 x L-shape Rail kit
Part Numbers
- Barebone package: 6NG492HA0MR-00-1*
- Motherboard: 9MG62G41NR-00
- L-shape Rail kit: 25HB2-A96100-K0R
- CPU fansink: 25ST4-353203-M1R
- Front panel board - CFPG015: 9CFPG015NR-00
- Backplane board - CBP20C5: 9CBP20C5NR-00
- PCIe bridge board - CPBG780: 9CPBG780NR-00
- Fan module: 6NG481HAASR-00-100
- GPU power cable (CPU 8pin, 100mm): 25CRI-100303-B0R
- Power supply (-100): 25EP0-222008-D0S
- Power supply (-1T0): 25EP0-22200A-G1S
Optional parts:
- VROC module: 25FD0-R181N0-10R (Supported for Intel SSD only)
- C19 power cord 125V/15A (US): 25CP1-018000-Q0R
- C19 power cord 250V/16A (EU): 25CP3-01830H-Q0R
- C19 power cord 125V/15A (JP): 25CPA-01830B-Q0R
- RMA packaging: 6NG492HA0SR-RMA-A100
- Motherboard: 9MG62G41NR-00
- L-shape Rail kit: 25HB2-A96100-K0R
- CPU fansink: 25ST4-353203-M1R
- Front panel board - CFPG015: 9CFPG015NR-00
- Backplane board - CBP20C5: 9CBP20C5NR-00
- PCIe bridge board - CPBG780: 9CPBG780NR-00
- Fan module: 6NG481HAASR-00-100
- GPU power cable (CPU 8pin, 100mm): 25CRI-100303-B0R
- Power supply (-100): 25EP0-222008-D0S
- Power supply (-1T0): 25EP0-22200A-G1S
Optional parts:
- VROC module: 25FD0-R181N0-10R (Supported for Intel SSD only)
- C19 power cord 125V/15A (US): 25CP1-018000-Q0R
- C19 power cord 250V/16A (EU): 25CP3-01830H-Q0R
- C19 power cord 125V/15A (JP): 25CPA-01830B-Q0R
- RMA packaging: 6NG492HA0SR-RMA-A100
* Les informations ici proposées le sont pour référence uniquement. GIGABYTE se réserve le droit de modifier ce contenu à tout moment et sans préavis.
*Les performances affichées sont basées sur les informations proposées par les constructeurs de chipsets ou sociétés définissant les caractéristiques des interfaces. Performances pouvant varier selon configuration.
* Marques et logos appartiennent aux détenteurs respectifs de leurs droits.
* L'architecture de grand nombre de PC affectera directement la capacité mémoire, en effet, une certaine quantité de RAM sera affectée au système, la quantité totale affichée pourra alors varier de celle insérée sur votre carte mère
*Les performances affichées sont basées sur les informations proposées par les constructeurs de chipsets ou sociétés définissant les caractéristiques des interfaces. Performances pouvant varier selon configuration.
* Marques et logos appartiennent aux détenteurs respectifs de leurs droits.
* L'architecture de grand nombre de PC affectera directement la capacité mémoire, en effet, une certaine quantité de RAM sera affectée au système, la quantité totale affichée pourra alors varier de celle insérée sur votre carte mère
SUPPORT
Driver
BIOS
Utilitaire
Firmware
QVL
- All
- All
- Windows Server 2022
- Windows Server 2019
- Windows Server 2016 64bit
- Linux
Chipset
Chipset
Version
Taille
Date
Intel® Chipset Driver
Version : 10.1.18612.8252
3.08 MB
Jun 10, 2021
OS: Windows Server 2016 64bit,Windows Server 2019
Broadcom PCIe Switch Driver
Version : F18
3.56 MB
Dec 15, 2021
OS: Windows Server 2016 64bit,Windows Server 2019
Intel® Chipset Driver
Version : 10.1.18807.8279
3.29 MB
Apr 25, 2022
OS: Windows Server 2022
LAN
LAN
Version
Taille
Date
Intel® LAN Driver and Utility
Version : 26.2
678.06 MB
Jun 10, 2021
OS: Windows Server 2016 64bit,Windows Server 2019
Intel® LAN Driver and Utility
Version : 27.0
714.97 MB
Apr 21, 2022
OS: Windows Server 2022
SATA RAID
SATA RAID
Version
Taille
Date
Intel® SATA Preinstall driver
(For AHCI / RAID Mode)
Note: Windows setup to read from USB devices
(For AHCI / RAID Mode)
Note: Windows setup to read from USB devices
Version : 7.5.0.1991
4.17 MB
Sep 08, 2021
OS: Windows Server 2016 64bit,Windows Server 2019
Intel® Rapid Storage Technology enterprise (Intel® RSTe)
Version : 7.5.0.1991
23.93 MB
Sep 08, 2021
OS: Windows Server 2016 64bit,Windows Server 2019
Intel® SATA Preinstall driver
(For AHCI / RAID Mode)
Note: Windows setup to read from USB devices
(For AHCI / RAID Mode)
Note: Windows setup to read from USB devices
Version : 7.7.0.1273
7.07 MB
Apr 25, 2022
OS: Windows Server 2022
Intel® Rapid Storage Technology enterprise (Intel® RSTe)
Version : 7.7.0.1273
23.58 MB
Apr 25, 2022
OS: Windows Server 2022
BIOS
Description
Version
Taille
Date
Updated for AMI security
SA50216: CVE-2023-39539
SA50216: CVE-2023-39538
SA50216: CVE-2023-39539
SA50216: CVE-2023-39538
Version : F33
23.46 MB
Apr 01, 2024
Windows and UEFI mode flash BIOS SOP
Please download BIOS update tool from AMI Website
Please download BIOS update tool from AMI Website
-
0.31 MB
Jan 29, 2021
Warning:
Because BIOS flashing is potentially risky, if you do not encounter problems using the current version of BIOS, it is recommended that you not flash the BIOS. To flash the BIOS, do it with caution. Inadequate BIOS flashing may result in system malfunction.
What is a BETA?
BETA describes a new version that is reliable yet may not include all the features of the final product. During this phase we are previewing new features and gathering customer input to insure our product provides the best experience possible.
Update CPU ID/Micro codes in new BIOS means?
[1] To support new series of CPUs, or [2] To support the same CPU but with new stepping. CPU support of motherboard is consist of BIOS and hardware design, detail CPU support information please see CPU support list.
Because BIOS flashing is potentially risky, if you do not encounter problems using the current version of BIOS, it is recommended that you not flash the BIOS. To flash the BIOS, do it with caution. Inadequate BIOS flashing may result in system malfunction.
What is a BETA?
BETA describes a new version that is reliable yet may not include all the features of the final product. During this phase we are previewing new features and gathering customer input to insure our product provides the best experience possible.
Update CPU ID/Micro codes in new BIOS means?
[1] To support new series of CPUs, or [2] To support the same CPU but with new stepping. CPU support of motherboard is consist of BIOS and hardware design, detail CPU support information please see CPU support list.
- All
- All
- Windows Server 2022
- Windows Server 2019
- Windows Server 2016 R2 64bit
- Windows Server 2016 64bit
- Windows Server 2012 R2 64bit
- Windows Server 2012 64bit
- Windows 10 64bit
- VMware
- Ubuntu
- Linux CentOS
- Linux
Utilitaire
Description
Version
Taille
Date
GSM CLI
Version : 2.1.72
147.86 MB
Mar 05, 2024
OS: Windows Server 2012 64bit,Windows Server 2012 R2 64bit,Linux CentOS,Windows 10 64bit,Ubuntu,Windows Server 2016 R2 64bit,Windows Server 2019,Windows Server 2022
GSM Server
Version : 2.12
926.33 MB
Jan 18, 2023
OS: Linux,Windows Server 2016 64bit,Windows Server 2019
GSM Agent
Version : 2.5
720.29 MB
Dec 27, 2021
OS: Linux,Windows Server 2016 64bit,Windows Server 2019
Firmware
Description
Version
Taille
Date
BMC firmware with embedded GIGABYTE Management Console
(AST2600)
(AST2600)
Version : 13.05.09
113.83 MB
Jan 26, 2024
Anglais
Mode d'emploi
Description
Version
Taille
Date
User Guide - GIGABYTE Management Console (AMI AST2600)
Version : 1.0
17.39 MB
Aug 29, 2023
Anglais
Description
Version
Taille
Date
RESOURCES
Video
News
Others
Back to G492-HA0
