R282-Z9G

Legacy | Firmware updates supported

Rev. A00/B00

Rack Server - AMD EPYC^™ 7003/7002 - 2U DP 20-Bay Gen4 NVMe with GRAID solution

Networking

Hardware-level root of trust
Equipped with GRAID SupremeRAID NVMe/NVMe-oF RAID Card
Dual AMD EPYC^™ 7003/7002 Series Processors
8-Channel DDR4 RDIMM/LRDIMM, 32 x DIMMs
2 x 1Gb/s LAN ports via Intel^® I350-AM2
20 x 2.5" Gen4 NVMe hot-swap bays
2 x 2.5" SATA/SAS hot-swap bays on the rear side
1 x M.2 slot with PCIe Gen4 x4 interface
1 x FHHL PCIe Gen4 x16 slot
1+1 1600W 80 PLUS Platinum redundant power supplies

Save

OverviewSpecificationsSupportRelated Resources

Specifications

Dimensions (WxHxD, mm)

2U
438 x 87 x 730

Motherboard

MZ92-FS1 Rev. 3.0

CPU

AMD EPYC^™ 7003 series processors
AMD EPYC^™ 7002 series processors

Dual processor, cTDP up to 280W

^[Note]If only 1 CPU is installed, some PCIe or memory functions might be unavailable.

Socket

2 x LGA 4094
Socket SP3

Chipset

System on Chip

Memory

32 x DIMM slots
Support DDR4 RDIMM/LRDIMM
8-Channel memory per processor
Up to 3200/2933 MT/s^[1]

^[1]Follow BIOS setting and memory QVL if running 3200 MT/s with 2DPC.

LAN

Rear:
2 x 1Gb/s LAN (1 x Intel^® I350-AM2)
- Support NCSI function

1 x 10/100/1000 Mbps Management LAN

Video

Integrated in ASPEED^® AST2500
- 1 x VGA port

Storage

Front hot-swap:
20 x 2.5" Gen4 NVMe
- (12 x NVMe from CPU_0, 8 x NVMe from CPU_1)

Rear hot-swap:
2 x 2.5" SATA
- (SATA from CPU_0)

Internal M.2:
1 x M.2 (2242/2260/2280/22110), PCIe Gen4 x4, from CPU_0^[1]

^[1]CPU TDP is limited to 225W when using M.2 drives.

SAS

N/A

RAID

Equipped with GRAID SupremeRAID NVMe/NVMe-oF RAID Card
RAID Card models: SR1010, SR1000
Support RAID 0/1/10/5/6
Maximum 20 physical drives

PCIe Expansion Slots

Riser Card CRS2033:
- 1 x FHHL x16 (Gen4 x16), from CPU_0, occupied for NVMe
- 1 x FHHL x8 (Gen4 x8), from CPU_0, occupied for NVMe
- 1 x FHHL x8 (Gen4 x8), form CPU_0, occupied for NVMe

Riser Card CRS2015:
- 1 x LP x16 (Gen4 x16), from CPU_1, occupied for NVMe

Riser Card CRS2026:
- 1 x FHHL x16 (Gen4 x16), from CPU_1, occupied by GRAID SupremeRAID SR-1000 NVMe/NVMe-oF RAID Card
- 1 x FHHL x16 (Gen4 x16), from CPU_1

1 x OCP NIC 3.0 (Gen4 x16), from CPU_0, occupied for NVMe
- Supports NCSI function

1 x OCP 2.0 mezzanine (Gen3 x8)(Type1, P1, P2), from CPU_1, occupied for NVMe
- Supports NCSI function

Front I/O

2 x USB 3.0 ports (Type-A)
1 x Power button with LED
1 x ID button with LED
1 x NMI button
1 x Reset button
2 x LAN activity LEDs
1 x Storage activity LED
1 x System status LED

Rear I/O

2 x USB 3.0 ports (Type-A)
1 x VGA port
2 x RJ45 ports
1 x MLAN port
1 x ID button with LED

Backplane Board

Speed and bandwidth:
Front - CBP20O8: PCIe Gen4 x4
Rear - CBP2022: SATA 6Gb/s or SAS 12Gb/s

Security Modules

1 x TPM header with SPI interface
- Optional TPM2.0 kit: CTM010

Power Supply^[#1]

1+1 1600W 80 PLUS Platinum redundant power supplies

AC Input:
- 100-120V~/ 12A, 50-60Hz
- 200-240V~/ 10.0A, 50-60Hz

DC Input:
- 240Vdc/ 10A

DC Output:
- Max 1000W/ 100-120V~
+ 12V/ 81.5A
+ 12Vsb/ 2.5A
- Max 1600W/ 200-240V~ or 240Vdc Input
+ 12V/ 133A
+ 12Vsb/ 2.5A

System Management

ASPEED^® AST2500 Baseboard Management Controller
GIGABYTE Management Console web interface

Dashboard
HTML5 KVM
Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
Sensor Reading History Data
FRU Information
SEL Log in Linear Storage / Circular Storage Policy
Hardware Inventory
Fan Profile
System Firewall
Power Consumption
Power Control
LDAP / AD / RADIUS Support
Backup & Restore Configuration
Remote BIOS/BMC/CPLD Update
Event Log Filter
User Management
Media Redirection Settings
PAM Order Settings
SSL Settings
SMTP Settings

OS Compatibility

Windows Server 2019
Red Hat Enterprise Linux 8.3, 8.4, 8.5
CentOSLinux 8.3, 8.4, 8.5
SUSE Linux Enterprise Server 15 SP2, SP3
openSUSE Leap Server 15.2, 15.3
Ubuntu 20.04 LTS

System Fans

4 x 80x80x38mm

Operating Properties

Operating temperature: 10°C to 35°C
Operating humidity: 8% to 80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20% to 95% (non-condensing)

Weight

Net Weight: 20.6 kg
Gross Weight: 25.6 kg

Packaging Dimensions

982 x 588 x 268 mm

Packaging Content

1 x R282-Z9G
2 x CPU heatsinks
1 x Rail kit

Part Numbers

- Barebone with SR-1000 package: 6NR282Z9GMR-00-A*
- Barebone with SR-1010 package: 6NR282Z9GMR-00-B*
- Motherboard: 9MZ92FS1NR-00*
- Rail kit: 25HB2-3A0202-K0R
- CPU heatsink: 25ST1-44320G-A0R
- Front panel board - CFP2001: 9CFP2001NR-00*
- Backplane board - CBP20O8: 9CBP20O8NR-00*
- Backplane board - CBP2022: 9CBP2022NR-00*
- Fan module: 25ST2-883829-D0R
- Power supply: 25EP0-216008-L0S

[#1] Power cords are not included with server packages. Customers are responsible for selecting appropriate power cords from the optional accessories or contacting sales for customization.

[#2] All materials provided herein are for reference only. GIGABYTE reserves the right to modify or revise the content at any time without prior notice.

[#3] Advertised performance is based on maximum theoretical values as specified by the respective chipset vendors or standards organizations. Actual performance may vary depending on system configuration.

[#4] All trademarks and logos are the property of their respective owners.
