產品規格
Dimensions (WxHxD, mm)
2OU
537 x 93 x 807.7
LAN
Front:
- Upper tray:
- 1 x 10/100/1000 Mbps Management LAN
- Lower tray:
- 1 x 10/100/1000 Mbps Management LAN
Storage
Front access:
- Upper tray:
- 16 x 3.5"/2.5" SATA/SAS-3
- Lower tray:
- 16 x 3.5"/2.5" SATA/SAS-3
SAS Expander
Upper tray:
1 x Broadcom SAS4x32 expander, single-path
Lower tray:
1 x Broadcom SAS4x32 expander, single-path
Front I/O
4 x Mini-SAS HD ports
2 x MLAN ports
1 x UART audio jack
1 x Power button with LED
1 x ID button with LED
1 x BMC reset button
1 x System status LED
1 x MLAN access LED
System Management
ASPEED® AST2520 Remote Management Controller
System Fans
4 x 92x92x38mm (9,700rpm)
Packaging Dimensions
1165 x 764 x 282 mm
Packaging Content
1 x TO24-JD3-AA01
Part Numbers
- Barebone package: 6NTO24JD3MR000AA01*
No. of Bus Bars
1 x 48V Bus Bar
