G2L4-SD4-LA08

To be released

HPC/AI Server - Intel® Xeon® 6700/6500-Series Processors - 2U DP NVIDIA HGX™ Rubin NVL8 DLC
  • Liquid-cooled NVIDIA HGX™ Rubin NVL8
  • CPU+GPU direct liquid cooling solution with leak detection
  • 8 x 800 Gb/s OSFP InfiniBand or Ethernet GPU networking ports via 8 x single-port NVIDIA ConnectX®-9 VPI
  • 3.6 TB/s GPU-to-GPU bandwidth with NVIDIA NVLink™ and NVIDIA NVLink™ Switch
  • Dual Intel® Xeon® 6700/6500-Series Processors
  • 8-Channel liquid-cooled DDR5 RDIMM/MRDIMM per CPU with 32 x DIMMs
  • 1 x 1 Gb/s LAN ports via Intel® I210-AT
  • 2 x M.2 slots with PCIe Gen6 x4
  • 8 x liquid-cooled E1.S Gen5 NVMe hot-swap bays
  • 1 x liquid-cooled FHHL PCIe x16 slots with Gen6 x16 lanes for NVIDIA BlueField®-4 DPU
  • 54 V DC Bus Bar power solution
Save
This model has been saved to favorite!
View Saved List
Quote

NVIDIA HGX Rubin NVL8

Agentic AI doesn't just compute, it reasons, coordinates, and remembers across every step of a long-running task, passing context between models and agents in real time. That demands a system built for exactly that job. The NVIDIA HGX Rubin NVL8 platform answers the call, with eight NVIDIA Rubin GPUs working as one, linked by sixth-generation NVIDIA NVLink™ so agents can share information instantly instead of waiting for it. A multi-agent engine and dedicated reinforcement learning engine keep reasoning workflows fast and memory optimized, even as workloads scale from training through post-training and inference. The result is a system built from the ground up for the way intelligent agents actually think and act at enterprise scale.
Content Image
GPU8x NVIDIA Rubin GPUs
Total GPU Memory | Bandwidth2.3 TB | 160 TB/s
CPU2x Intel® Xeon® 6 processors
NVIDIA NVLink Switch System4x
NVIDIA NVLink Bandwidth28.8 TB/s total bandwidth
Networking

8x OSFP ports serving 8x single-port NVIDIA ConnectX®-9 VPI

- up to 800 Gb/s NVIDIA InfiniBand and Ethernet

2x 400G QSP112 NVIDIA BlueField®-4 DPUs

- up to 800 Gb/s NVIDIA InfiniBand and Ethernet

Boosting Individual Applications with On-Point Features

Intel® Xeon® 6 is a new generation of processors that has tailored its CPU lineup to target all uses cases such as Cloud Computing, AI, Analytics, and Edge & IOT. Whether it's high compute density that is dependent on core count and power efficiency or AI/HPC applications that heavily rely on strong single-core performance, this new platform covers them all with its Performance cores (P-cores) and Efficient-cores (E-cores). Along with flexible I/O options, integrated accelerators, and support for CXL 2.0 devices, Intel Xeon 6 fulfills customer needs across the broadest range of data center workloads, segments, and deployment models.
Content Image

Core Technology Aligned with Aspirations

Accelerators
built-in*
Incredible performance and efficiency improvements with the easy adoption of on-chip accelerators
8 or 12
Channels
Increased memory frequency and throughput with DDR5 RDIMM support
PCIe 5.0
lanes
Up to 136 lanes for 1S designs, supporting all the latest drives and accelerators
CXL 2.0
support**
Flexible support between PCIe and CXL, utilizing DDR5 and CXL memory as one unified region
Up to 288
E-cores per CPU
Core dense and optimized efficiency for cloud-native and hyperscale workloads
Intel Xeon 6 Processors with E-cores
Up to 128
P-cores per CPU
Greater core performance with improved TCO, accelerating AI and compute intensive workloads
Intel Xeon 6 Processors with P-cores
MRDIMM
support
Unprecedented frequency on the advanced MRDIMM, boosting memory-intensive application to a whole new level
Intel Xeon 6 Processors with P-cores
* Different on-chip accelerators are supported depending on CPU SKUs, and they require a one-time activation. Please visit Intel's official website or contact technical support for details.

** CXL peripheral support varies by product. Please refer to the QVL list for validated configurations.
