uATX-Q370A
Micro-ATX with 9th/8th Generation Intel® Core™ Processors, Dual channel DDR4 memory, PCIe, 4 x COM, 10 x USB, 6 x SATA 6Gb/s
  • Micro ATX form factor
  • Supports 9th/8th Generation Intel® Core™ Processors
  • Intel® Q370 Express Chipset
  • Dual Channel Non-ECC Unbuffered DDR4, 4 x DIMMs
  • 2 x GbE LAN ports
  • 6 x SATA 6Gb/s ports
  • Ultra-Fast M.2 with PCIe Gen3 x4 interface
  • HDMI 1.4, DVI-D, VGA ports for multiple displays
  • Up to 4 x PCIe Gen3 expansion slots
  • 1 x USB3.1 Gen2 port with 10Gb/s speed
  • 4 x RS232 COM ports
  • Onboard TPM 2.0 security chip

  • (For more product information, please contact us at sales@gigaipc.com)
    uATX-H370A
    Micro-ATX with 9th/8th Generation Intel® Core™ Processors, Dual channel DDR4 memory, PCIe, 4 x COM, 10 x USB, 6 x SATA 6Gb/s
  • Micro ATX form factor
  • Supports 9th/8th Generation Intel® Core™ Processors
  • Intel® H370 Express Chipset
  • Dual Channel Non-ECC Unbuffered DDR4, 4 x DIMMs
  • 2 x GbE LAN ports
  • 6 x SATA 6Gb/s ports
  • Ultra-Fast M.2 with PCIe Gen3 x4 interface
  • HDMI 1.4, DVI-D, VGA ports for multiple displays
  • Up to 4 x PCIe Gen3 expansion slots
  • 1 x USB 3.1 Gen2 port with 10Gb/s speed
  • 4 x RS232 COM ports
  • Onboard TPM 2.0 security chip

  • (For more product information, please contact us at sales@gigaipc.com)
    uATX-H310A
    Micro-ATX with 9th/8th Generation Intel® Core™ Processors, Dual channel DDR4 memory, PCIe, 4 x COM, 8 x USB, 4 x SATA 6Gb/s
  • Micro ATX form factor
  • Supports 9th/8th Gen Intel® Core™ Processors
  • Intel® H310 Express Chipset
  • Dual Channel Non-ECC Unbuffered DDR4, 2 x DIMMs
  • 2 x GbE LAN ports
  • 4 x SATA 6Gb/s ports
  • HDMI 1.4, DVI-D, VGA ports for multiple displays
  • Up to 4 x PCIe expansion slots
  • 4 x RS232 COM ports
  • Onboard TPM 2.0 security chip

  • (For more product information, please contact us at sales@gigaipc.com)
    QBiX-WP-APLA3940H-A1
    • System Size : 188W x 155D x 72H (mm)
    • Intel® Atom® x5-E3940 Processor
    • Dual Channel DDR3L, 2 x SO-DIMMs
    • IP67 water proof certification
    • M12 and IP67 water proof connectors
    QBiX-WP-WHLA8265H-A1
    • System Size : 188W x 155D x 72H (mm)
    • Intel® Core™ i5-8265U Processor
    • Dual Channel DDR4, 2 x SO-DIMMs
    • IP67 water proof certification
    • M12 and IP67 water proof connectors
    SDM-4000L
    • SDM-L, 175W x 100D (mm)
    • Intel® Celeron® N4000 Processor
    • Dual Channel DDR4, 2 x SO-DIMMs
    • 1 x GbE LAN ports
    • HDMI, Display Port for multiple display
    • M.2 with SATA III 6Gb/s
    • 4 x USB 3.0 port
    • 1 x EMMC 32GB
    SDM-7300L
    • SDM-L, 175W x 100D (mm)
    • Intel® Core™ i5-7300U Processor
    • Dual Channel DDR4, 2 x SO-DIMMs
    • 1 x GbE LAN ports
    • HDMI, Display Port for multiple display
    • Ultra-Fast M.2 with PCIe Gen3 x4 interface
    • 4 x USB 3.0 port
    mITX-H310A
    Mini-ITX with Intel® H310 Chipset that supports 9th/8th Generation Intel® Core™ Processors, Dual channel DDR4 memory, PCIe, 4 x COM, 8 x USB, 2 x SATA 6Gb/s
  • Mini-ITX Form Factor
  • Supports 9th/8th Generation Intel® Core™ Processors
  • Intel® H310 Express Chipset
  • Dual Channel DDR4, 2 x SO-DIMMs
  • 2 x GbE LAN ports
  • 2 x SATA 6Gb/s ports
  • HDMI, Display Port, VGA, eDP ports for multiple display
  • 2 x RS-232/422/485 and 5V/12V/RI COM ports
  • 2 x RS-232 COM ports

  • (For more product information, please contact us at sales@gigaipc.com)
    SDM-7100L
    • SDM-L, 175W x 100D (mm)
    • Intel® Core™ i3-7100U Processor
    • Dual Channel DDR4, 2 x SO-DIMMs
    • 1 x GbE LAN ports
    • HDMI, Display Port for multiple display
    • Ultra-Fast M.2 with PCIe Gen3 x4 interface
    • 4 x USB 3.0 port
    GA-H310MSTX-HD3(1.0)

    • Support for 9th and 8th Generation Intel® Core™ Processors
    • Dual Channel DDR4 SO-DIMM, 2 DIMMs
    • Features USB 3.0 with USB Type-C™ Support
    • 2 x RS232 COM Port Support
    • M.2 Socket 1 Interface for WIFI+BT Module Support
    • M.2 Socket 3 Interface for SATA Mode SSD Support
    • Rear Panel DisplayPort, HDMI 1.4, D-Sub Ports for Multi-Display Connection
    • Amplified Speaker Header Able to Drive Up to 3W System Integrated Speaker
    • Intel® GbE LAN for WOL and PXE Support
    • GIGABYTE UEFI DualBIOS™ Technology
    • Mini-STX 147x140mm Form Factor with 19V DC-In Power Design
    • Support Intel® Small Business Basics
    • Compatible with GIGABYTE Mini STX Chassis
    GA-IMB310N(1.0)
    • Supports 9th and 8th Generation Intel® Core™ Processors up to 65W
    • Dual Channel DDR4 SO-DIMM, 2 DIMMs
    • 2 x RS232/422/485, 2 x RS232, Digital I/O 4-in/4-out
    • M.2 Socket 1 for PCIe WIFI co-lay with CNVI Hybird E key WIFI
    • M.2 Socket 2260/80 Storage support PCIe/SATA Mode
    • Mini-PCIe Slot Full size Support mSATA/PCIe mode
    • VGA Header for legacy Monitor
    • LVDS Header for System Integrated Flat Panel Display Support
    • Rear Panel DisplayPort, HDMI 2.0 Ports & D-sub Header for Multi-Display Connection
    • Amplified Speaker Header Able to Drive Up to 3W System Integrated Speaker
    • Dual Intel® GbE LAN for WOL and PXE Support
    • 4 USB 3.0 and 2 USB 2.0 Ports, USB 3.0 support OTG function
    • OP 0~60 degree
    • Mini-ITX 170x170mm Form Factor with ATX Power


    • * Datasheet Download
    mITX-Q370A
    Mini-ITX with Intel® Q370 Chipset that supports 9th/8th Generation Intel® Core™ Processors, Dual channel DDR4 memory, PCIe, 2 x COM, 10 x USB, 3 x SATA 6Gb/s
  • Mini-ITX form factor
  • Intel® vPro™ ready
  • Supports 9th/8th Gen Intel® Core Processors
  • Intel® Q370 Express Chipset
  • Dual Channel Non-ECC Unbuffered DDR4, 2 x SODIMMs
  • 2 x GbE LAN ports ( Intel® I211-AT and I219LM)
  • 3 x SATA III 6Gb/s ports
  • HDMI 1.4, DisplayPort, eDP, D-Sub ports for multiple displays
  • 2 x COM ports
  • 1 x USB3.1 Gen2 10Gb/s port in rear IO
  • 1 x PCIe x16 expansion slot
  • Compatible with 12V-24V power adapter

  • (For more product information, please contact us at sales@gigaipc.com)
