1. Supports new generation of AMD Phenom™II X6 processors
  2. AMD SB850 provides 6 native SATA3 storage interfaces with superfast 6Gbps link speed and RAID 0, 1, 5, 10 support
  3. Supports newest NEC SuperSpeed USB 3.0 with superfast transfer rates of up to 5 Gbps
  4. 3X USB power delivery for greater compatibility and extra power for USB devices
  5. Exclusive Auto Unlock technology provides hardware-based solution for unleash CPU performance
  6. Ultra Durable 3 Classic Technology with copper cooled quality for lower working temperature
  7. Revolution energy saving design with Easy Energy Saver technology
  8. Supports AMD AM3 Phenom II/ Athlon II processors
  9. Dual Channel DDR3 1866+ for remarkable system performance
  10. Integrated ATI Radeon HD 4250 graphics (DirectX10.1)
  11. Innovative Turbo 3D technology to unleash extra levels of 2D/3D graphics performance
  12. 2 PCI-E 2.0 x16 interface with ATI Hybrid CrossFireX support for ultimate graphics performance
  13. Blu-ray playback supported by high quality ALC892 HD audio
  14. Supports Dolby Home Theater audio to enjoy a rich surround sound experience
  15. Integrated HDMI/ DVI interface for Full HD 1080 Blu-ray playback with HDCP
  16. Compatible with Window 7 to deliver the best operation experience
  17. Meet European Union ErP(Energy-related-Products) requirement
  • Suport On/Off Charge
    Tehnologia GIGABYTE On/Off Charge permite încărcarea iPhone, iPad şi iPod Touch fie că PC-ul este pornit, în standby sau chiar oprit. Fiind derivată a tehnologiei apreciate GIGABYTE 3x USB Power, On/Off Charge permite echipamentelor să primeasca mai mult curent din porturile USB ale plăcilor de bază GIGABYTE faţă de cât permit porturile USB standard, astfel încât încărcarea din PC sa fie la fel de rapidă ca cea cu încărcător dedicat...mai mult
    *Din cauza anumitor limitări ale telefoanelor mobile, utilizatorii pot fi nevoiti să conecteze telefonul mobil la PC înainte ca PC-ul să intre în modul S4/S5 pentru a se permite încărcarea rapidă de la un port USB fără ON/OFF Charge. Rezultatele încărcării pot varia în funcţie de model.
    *Suportul pentru 3X USB power design poate varia în funcţie de model.
     On/Off Charge Driver download
  • Introduction


    The 880GA-UD3H motherboard is designed to offer a stable, high-speed platform for delivering amazingly fast data transfer via revolutionary GIGABYTE Ultra Durable 3 Classic technology with featuring 2 oz copper PCB, and further the latest GIGABYTE 333 onboard acceleration technologies (USB 3.0 / SATA3 6Gbs / 3X USB power). Based on AMD 880G chipset, the 880GA-UD3H supports the latest 45nm AMD AM3 Phenom II/ Athlon II processors, integrated DDR3 memory controller, HyperTransport™ 3.0 technology links and PCI Express 2.0 graphics interfaces for ATI Hybrid CrossFireX support. With the innovative GIGABYTE Easy Energy Saver technology, the 880GA-UD3H is able to provide user friendly computing, reach the maximum system performance easily while still able to save the power and environment in real life at the same time.
  • Supports next generation of 45nm AMD AM3 CPU
    This motherboard designs with Split Power Plane, 4+1 phase VRM to support AMD the latest 45nm AM3 Phenom™II series processors, delivering the great performance enchantment to system and ultimate scalability hardware expending.
  • SATA 6 Gbps Support
    Yet another onboard feature of GIGABYTE AMD 800A series motherboards are integrated the latest AMD SB850 chip for high-speed SATA Revision 3.0 compatibility, delivering 6 ports native superfast 6Gbps link speeds for twice the data transfer rates of SATA Revision 2.0 (3 Gbps) and RAID 0, 1, 5, 10 support. When used in RAID 0 (Stripe) mode, GIGABYTE AMD 800A series motherboards offer even faster data transfer rates of up to 4x the speed of current SATA interfaces.
  • USB 3.0 Support
    The GIGABYTE motherboards support the latest generation SuperSpeed USB 3.0 technology made possible through an onboard USB 3.0 host controller. With superfast transfer rates of up to 5 Gbps, users are able to experience an almost a 10x improvement over USB 2.0. Additionally, backwards compatibility with USB 2.0 assures users of long term use of their legacy USB 2.0 devices. The onboard SuperSpeed USB 3.0 technology also provides new power management features that include increased maximum bus power and device current draw to better accommodate power-hungry devices.

    * USB 3.0 10x performance is a maximum theoretical value. Actual performance may vary by system configuration.
  • 3x USB Power Boost
    Plăcile de bază GIGABYTE permit o creștere a puterii de 3x pe porturile USB, oferind o mai mare compatibilitate și mai multă putere pentru echipamentele USB. Design-ul unic de alimentare USB de la GIGABYTE este de asemenea capabil să regularizeze eficient ieșirea pe toată gama de tensiuni, ce îmbunătățește și mai mult compatibilitatea cu echipamentele USB. În plus, siguranțele dedicate cu rezistență scăzută asigură căderi mai mici de tensiune și permit o livrare de energie mai stabilă și mai puternică.


    (notă) Doar porturile USB frontale suportă 3X USB Power.
  • Auto Unlock Support
    Experience a phenomenal performance upgrade with GIGABYTE’s innovative Auto Unlock technology that unleashes your system’s hidden performance. Featuring a unique design that enables the processor’s hidden cores by BIOS, GIGABYTE Auto Unlock technology effectively provides a CPU upgrade while running multi-threaded applications or multi-tasking.
    * The ability of unlocking the hidden CPU cores might vary by different processors.
  • Ultra Durable 3 – Classic

    GIGABYTE Ultra Durable 3 Classic motherboards once again lead the motherboard industry for the highest quality and most innovative motherboard design. Featuring the industry’s first consumer desktop motherboard design to introduce 2 ounces of copper for both the Power and Ground layers, delivering a dramatically lower system temperature, improved energy efficiency and enhanced stability for overclocking. GIGABYTE Ultra Durable 3 Classic motherboards are equipped with the GIGABYTE Ultra Durable signature features including Japanese Solid Capacitors boasting an operational life time of more than 50,000 hours, and GIGABYTE patented DualBIOS™ technology (providing dual hardware BIOS protection). GIGABYTE Ultra Durable 3 Classic motherboards promise to provide the stability, reliability and longevity essential to meet the power needs of high-end processors and other components running today's most demanding applications and games.
  • AMD 880G 3D Graphics Performance Upgrade- up to 3DMark 2006 3000 marks!!
    The 3DMark 2006 is a benchmark software which is from Futuremark Corporation and generally used on analyzing a PC performance of DirectX® 3D visualization, especially a valuable guideline for gaming users as reference.
    3DMark06 2868 marks on 880G system configuration
    AMD PhenomII X4 965 (OC), GPU OC 1124MHz, 4GB DDR3-1600(OC), Win7-32bit, 3DMark06 (1280x1024)

    * 3000+ marks in 3DMark06 was achieved by overclocking.
    * Please be aware that GIGABYTE's product warranty does not cover damages caused by overclocking.
  • ATI Hybrid Graphics Technology support
    ATI Hybrid Graphics is a technology umbrella brand encompassing several technologies, such as ATI Hybrid CrossFireX™, ATI SurroundView™, ATI PowerPlay™, etc. that allow both an AMD integrated graphics processor and a discrete graphics processor to work co-operatively on an AMD based system to provide enhanced gaming performance, productivity and platform efficiency to the mainstream PC.
    * Please use ATI Hybrid CrossFireX certified DX11 VGA card (i.e., ATI Radeon HD 5450, etc.), detail information please refer to AMD website.
  • Dual Channel DDR3 2000+ MHz
    Delivering native support for DDR3 memory up to 2000MHz, GIGABYTE Ultra Durable 3 series motherboards allow users to easily reach higher memory frequencies at lower voltages; achieving higher memory performance with lower power consumption to run even the most memory intensive applications such as high-definition video and 3D games with ease.
  • EasyTune6
    GIGABYTE a reproiectat de la zero utilitarul EasyTune6 pentru a face și mai ușoară administrarea și monitorizarea resurselor hardware cât și pentru ajustarea setărilor sistemului pentru obținerea de performanțe maxime. Fie că sunteți un overclocker entuziast sau un începător în computere, EasyTune6 vă ofera uneltele necesare pentru ajustarea rapidă și fără efort a sistemului.
  • GIGABYTE innovative technology- Easy Energy Saver
    GIGABYTE innovative technology- Easy Energy Saver Featuring an advanced proprietary software design, GIGABYTE Easy Energy Saver is able to dynamically adjust CPU power depending on workload, delivering just the right amount of power needed for the task. Coupled with AMD’s highly efficient processors, the Easy Energy Saver is able to provide exceptional levels of power savings and enhanced power efficiency without sacrificing computing performance.
  • HDMI 1.3* certification, support Full HD 1080P
    HDMI is able to provide up to 5Gb/s video transmitting bandwidth and multi-channel high quality audio all through a single cable. Able to transmit superior, uncompressed digital video and audio, HDMI ensures the crispest rendering of digital content up to 1080p without the quality losses associated with analog interfaces and their digital-to-analog conversion. GA-MA78LMT-US2H has obtained the latest HDMI 1.3* certification, able to support Full HD 1080p multi-media and HDCP (High-bandwidth Digital Content Protection) which allowing Blu-ray/ HD DVD and other protected contents playback.
    * HDMI 1.3 certified in video spec only.
  • Suport Dolby Home Theater
    Oferă sunet surround de calitate pentru muzică, filme și jocuri, folosind de la 2 la 8 difuzoare sau orice tip de căști.
  • Norton™ Internet Security
    Fast, comprehensive, and up-to-the-minute protection against online threats. It safeguards your computer, identity, and home network without slowing you down. It sets a new standard for speed and makes online shopping, banking, and browsing safer and more convenient than ever.
  • Qualified for Windows® 7
    The motherboard qualified for WHQL (Windows Hardware Quality Labs) certification of Windows 7 from Microsoft®, setting the standard for future Windows 7 certified motherboards...more
  • Suport EuP Lot 6
    EuP (cunoscut și ca Energy Using Products Directive) este parte a noilor reglementări pentru mediu ale Uniunii Europene. EuP se bazează pe îngrijorarea față de problemele de mediu cu privire la echipamentele electonice care au câștigat popularitate și despre cum să se îmbunătățească eficiența energetică pentru o viață mai bună și mai verde. GIGABYTE prezintă plăci de bază standard ce ajută efectiv la îmbunătățirea performanțelor sistemului și la economisirea de energie.

* Termenii HDMI, HDMI High-Definition Multimedia Interface, Imaginea comercială HDMI și Siglele HDMI sunt mărci comerciale sau mărci comerciale înregistrate ale HDMI Licensing Administrator, Inc.
* Materialele oferite aici sunt doar pentru referinţă. GIGABYTE îşi rezervă dreptul de a modifica sau revizui continutul oricând fără notificare prealabilă.
* Perfomanţa prezentată este bazată pe valorile teoretice maxime ale interfeţei de la vendorii respectivi de Chipset-uri sau de la organizaţiile ce au definit specificaţiile interfeţei. Perfomanţele reale pot varia în funcţie de sistem.
* Toate mărcile inregistrate şi logo-urile sunt proprietatea deţinătorilor respectivi.
* Datorită arhitecturii standard PC, o anumită cantitate de memorie este rezervată pentru sistem şi de aceea mărimea actuală a memoriei este mai mică decât cea indicată.
