R282-P92 (rev. 100)
Ampere® Altra® Max ARM GPU Server - 2U DP 12-Bay
| Application:
Networking
Application:
- Supports up to 2 x double slot GPU cards
- Dual Ampere® Altra® Max Processors
- 8-Channel RDIMM/LRDIMM DDR4, 32 x DIMMs
- Dual ROM Architecture supported
- 2 x 1Gb/s LAN ports (Intel® I350-AM2)
- 1 x Dedicated management port
- 6 x 3.5"/2.5" Gen4 NVMe hot-swappable SSD bays in front side
- 6 x 3.5"/2.5" SATA hot-swappable HDD/SSD bays in front side
- 1 x Ultra-Fast M.2 with PCIe Gen4 x4 interface
- 4 x full-height PCIe Gen4 x16 expansion slots
- 4 x low profile PCIe Gen4 x8 expansion slots
- 2 x OCP 3.0 Gen4 x16 mezzanine slots
- 2000W 80 PLUS Platinum redundant power supply
Request a Quote
* ข้อมูลเบื้องต้นมีไว้สำหรับอ้างอิงเท่านั้น GIGABYTE ขอสงวนสิทธิ์ในการปรับเปลี่ยนหรือแก้ไขเนื้อหาได้ตลอดเวลาโดยไม่ต้องแจ้งให้ทราบล่วงหน้า
* ประสิทธิภาพสูงสุดที่ใช้ในการประชาสัมพันธ์เป็นเพียงข้อมูลตามทฤษฎีจากผู้ผลิตชิปเซ็ตที่เกี่ยวข้อง หรือองค์กรที่กำหนดคุณสมบัติอินเตอร์เฟส ประสิทธิภาพที่แท้จริงอาจแตกต่างกันโดยการตั้งค่าของระบบที่ไม่เหมือนกัน
* เครื่องหมายการค้าและโลโก้คุณสมบัติต่างๆ เป็นของผู้ถือสิทธิ์นั้นๆ
* เนื่องจากความต้องการหน่วยความจำมาตรฐานของสถาปัตยกรรมคอมพิวเตอร์ต่อหน่วยที่ไม่เหมือนกัน ดังนั้นขนาดหน่วยความจำที่จำเป็นอาจน้อยกว่าจำนวนที่ระบุไว้ก็ได้
* ประสิทธิภาพสูงสุดที่ใช้ในการประชาสัมพันธ์เป็นเพียงข้อมูลตามทฤษฎีจากผู้ผลิตชิปเซ็ตที่เกี่ยวข้อง หรือองค์กรที่กำหนดคุณสมบัติอินเตอร์เฟส ประสิทธิภาพที่แท้จริงอาจแตกต่างกันโดยการตั้งค่าของระบบที่ไม่เหมือนกัน
* เครื่องหมายการค้าและโลโก้คุณสมบัติต่างๆ เป็นของผู้ถือสิทธิ์นั้นๆ
* เนื่องจากความต้องการหน่วยความจำมาตรฐานของสถาปัตยกรรมคอมพิวเตอร์ต่อหน่วยที่ไม่เหมือนกัน ดังนั้นขนาดหน่วยความจำที่จำเป็นอาจน้อยกว่าจำนวนที่ระบุไว้ก็ได้
SPECIFICATIONS
Dimensions (WxHxD, mm)
2U
438 x 87 x 730 mm
Motherboard
MP92-FS0
CPU
Ampere® Altra® Max Processor
Dual processors, 7nm technology
Up to 128-core per processor, TDP 250W
NOTE:
If only 1 CPU is installed, some PCIe or memory functions might be unavailable
Dual processors, 7nm technology
Up to 128-core per processor, TDP 250W
NOTE:
If only 1 CPU is installed, some PCIe or memory functions might be unavailable
Socket
Dual sockets
LGA4926
LGA4926
Chipset
System on Chip
Memory
32 x DIMM slots
DDR4 memory supported only
8-Channel memory architecture
RDIMM modules up to 256GB supported
LRDIMM modules up to 256GB supported
Up to 4TB of memory capacity supported per processor
Memory speed: Up to 3200 MHz
NOTE: Only supports configurations with 1, 2, 4, 6, 8, 12, or 16 DIMMs
DDR4 memory supported only
8-Channel memory architecture
RDIMM modules up to 256GB supported
LRDIMM modules up to 256GB supported
Up to 4TB of memory capacity supported per processor
Memory speed: Up to 3200 MHz
NOTE: Only supports configurations with 1, 2, 4, 6, 8, 12, or 16 DIMMs
LAN
2 x 1Gb/s LAN ports (1 x Intel® I350-AM2)
NCSI function supported
1 x 10/100/1000 Mbps management LAN
NCSI function supported
1 x 10/100/1000 Mbps management LAN
Video
Integrated in Aspeed® AST2600
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp, DDR4 SDRAM
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp, DDR4 SDRAM
Audio
N/A
Storage
Front side:
Total 12 x 3.5"/2.5" hot-swappable HDD/SSD bays
- 6 x 3.5"/2.5" Gen4 NVMe hot-swappable SSD bays
- 6 x 3.5"/2.5" SATA hot-swappable HDD/SSD bays
Total 12 x 3.5"/2.5" hot-swappable HDD/SSD bays
- 6 x 3.5"/2.5" Gen4 NVMe hot-swappable SSD bays
- 6 x 3.5"/2.5" SATA hot-swappable HDD/SSD bays
SAS
N/A
RAID
N/A
Peripheral Drives
N/A
Expansion Slots
Riser Card CRS101J:
- 1 x PCIe x16 slot (Gen4 x16), Full height half-length
Riser Card CRS101K:
- 1 x PCIe x16 slot (Gen4 x16), Full height half-length
Riser Card CRS202G:
- *1 x PCIe x16 slot (Gen4 x16), Full height full-length
NOTE: 1 PCIe slot is disabled
Riser Card CRS202H:
- *1 x PCIe x16 slot (Gen4 x16), Full height full-length
NOTE: 1 PCIe slot is disabled
Riser Card CRS202E:
- 2 x PCIe x8 slot (Gen4 x8), Low profile half-length
Riser Card CRS202E:
- 2 x PCIe x8 slot (Gen4 x8), Low profile half-length
2 x OCP 3.0 Gen4 x16 mezzanine slots
1 x M.2 slot:
- M-key
- PCIe Gen4 x4
- Supports 2242/2260/2280/22110 cards
- 1 x PCIe x16 slot (Gen4 x16), Full height half-length
Riser Card CRS101K:
- 1 x PCIe x16 slot (Gen4 x16), Full height half-length
Riser Card CRS202G:
- *1 x PCIe x16 slot (Gen4 x16), Full height full-length
NOTE: 1 PCIe slot is disabled
Riser Card CRS202H:
- *1 x PCIe x16 slot (Gen4 x16), Full height full-length
NOTE: 1 PCIe slot is disabled
Riser Card CRS202E:
- 2 x PCIe x8 slot (Gen4 x8), Low profile half-length
Riser Card CRS202E:
- 2 x PCIe x8 slot (Gen4 x8), Low profile half-length
2 x OCP 3.0 Gen4 x16 mezzanine slots
1 x M.2 slot:
- M-key
- PCIe Gen4 x4
- Supports 2242/2260/2280/22110 cards
Internal I/O
1 x M.2 slot
1 x TPM header
1 x Front panel header
1 x HDD/SSD back plane board header
1 x PMBus connector
1 x IPMB connector
1 x Clear CMOS jumper
1 x TPM header
1 x Front panel header
1 x HDD/SSD back plane board header
1 x PMBus connector
1 x IPMB connector
1 x Clear CMOS jumper
Front I/O
2 x USB 3.2 Gen1
1 x Power button with LED
1 x ID button with LED
1 x Reset button
2 x LAN activity LEDs
1 x HDD activity LED
1 x System status LED
1 x Power button with LED
1 x ID button with LED
1 x Reset button
2 x LAN activity LEDs
1 x HDD activity LED
1 x System status LED
Rear I/O
2 x USB 3.2 Gen1
1 x mini-DP
2 x RJ45
1 x MLAN
1 x mini-DP
2 x RJ45
1 x MLAN
Backplane I/O
Front side_CBP20C5: 12 x ports
Speed and bandwidth: PCIe Gen4 x4 or SATA
Speed and bandwidth: PCIe Gen4 x4 or SATA
TPM
1 x TPM header with SPI interface
Optional TPM2.0 kit: CTM010
Optional TPM2.0 kit: CTM010
Power Supply
2 x 2000W redundant PSU
80 PLUS Platinum
AC Input:
- 100-120V~/ 12A, 50-60Hz
- 180-240V~/ 10A, 50-60Hz
DC Input:
- 240Vdc/ 10A
DC output:
- Max 1000W/ 100-120V~
+ 12.2V/ 81.5A
+ 12Vsb/ 2.5A
- Max 1600W/ 180-199V~
+ 12.2V/ 131A
+ 12Vsb/ 2.5A
- Max 1800W/ 200-220V~
+ 12.2V/ 147.5A
+ 12Vsb/ 2.5A
- Max 2000W/ 221-240V~
+ 12V/ 163.5A
+ 12Vsb/ 2.5A
80 PLUS Platinum
AC Input:
- 100-120V~/ 12A, 50-60Hz
- 180-240V~/ 10A, 50-60Hz
DC Input:
- 240Vdc/ 10A
DC output:
- Max 1000W/ 100-120V~
+ 12.2V/ 81.5A
+ 12Vsb/ 2.5A
- Max 1600W/ 180-199V~
+ 12.2V/ 131A
+ 12Vsb/ 2.5A
- Max 1800W/ 200-220V~
+ 12.2V/ 147.5A
+ 12Vsb/ 2.5A
- Max 2000W/ 221-240V~
+ 12V/ 163.5A
+ 12Vsb/ 2.5A
System Management
Aspeed® AST2600 management controller
GIGABYTE Management Console (AMI MegaRAC SP-X) web interface
GIGABYTE Management Console (AMI MegaRAC SP-X) web interface
- Dashboard
- HTML5 KVM
- Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
- Sensor Reading History Data
- FRU Information
- SEL Log in Linear Storage / Circular Storage Policy
- Hardware Inventory
- Fan Profile
- System Firewall
- Power Consumption
- Power Control
- LDAP / AD / RADIUS Support
- Backup & Restore Configuration
- Remote BIOS/BMC/CPLD Update
- Event Log Filter
- User Management
- Media Redirection Settings
- PAM Order Settings
- SSL Settings
- SMTP Settings
OS Compatibility
Red Hat Enterprise Linux 8.3 (aarch64) or later
Red Hat Enterprise Linux 8.5 (aarch64) or later
SUSE Linux Enterprise Server 15 SP2 (aarch64) or later
SUSE Linux Enterprise Server 15 SP3 (aarch64) or later
Ubuntu 18.04.5 LTS (aarch64) or later
Ubuntu 20.04.1 LTS (aarch64) or later
Ubuntu 22.04 LTS (aarch64) or later
Fedora Server 33-1.2 (aarch64) or later
Fedora Server 35-1.2 (aarch64) or later
OracleLinux R8 U2
OracleLinux R8 U5
Debian 10.9 (Buster)
Debian 11.1
Red Hat Enterprise Linux 8.5 (aarch64) or later
SUSE Linux Enterprise Server 15 SP2 (aarch64) or later
SUSE Linux Enterprise Server 15 SP3 (aarch64) or later
Ubuntu 18.04.5 LTS (aarch64) or later
Ubuntu 20.04.1 LTS (aarch64) or later
Ubuntu 22.04 LTS (aarch64) or later
Fedora Server 33-1.2 (aarch64) or later
Fedora Server 35-1.2 (aarch64) or later
OracleLinux R8 U2
OracleLinux R8 U5
Debian 10.9 (Buster)
Debian 11.1
System Fans
4 x 80x80x38mm (16,300rpm)
Operating Properties
Operating temperature: 10°C to 35°C
Operating humidity: 8%-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)
Packaging Dimensions
1077 x 679 x 300 (mm)
Packaging Content
1 x R282-P92 system
2 x CPU heatsink
1 x Rail kit
2 x CPU heatsink
1 x Rail kit
Part Numbers
- Barebone package: 6NR282P92DR-00
- Motherboard: 9MP92FS0NR-00
- Rail kit: 25HB2-3A0206-K0R
- CPU heatsink: 25ST1-45320B-A3R
- Back plane board_12-port: 9CBP20C5NR-00
- Fan module: 25ST2-883829-D0R
- Riser Card_CRS101J: 9CRS101JNR-00
- Riser Card_CRS101K: 9CRS101KNR-00
- Riser Card_CRS202G: 9CRS202GNR-00
- Riser Card_CRS202H: 9CRS202HNR-00
- Riser Card_CRS202E: 9CRS202ENR-00
- G-SC Module: 9CDCR111UR-00
- Front panel board_CFP2001: 9CFP2001NR-00
- Power supply module: 25EP0-22000A-L0S
- Mini-DP to D-Sub cable: 25CRN-200801-K1R (optional)
- Motherboard: 9MP92FS0NR-00
- Rail kit: 25HB2-3A0206-K0R
- CPU heatsink: 25ST1-45320B-A3R
- Back plane board_12-port: 9CBP20C5NR-00
- Fan module: 25ST2-883829-D0R
- Riser Card_CRS101J: 9CRS101JNR-00
- Riser Card_CRS101K: 9CRS101KNR-00
- Riser Card_CRS202G: 9CRS202GNR-00
- Riser Card_CRS202H: 9CRS202HNR-00
- Riser Card_CRS202E: 9CRS202ENR-00
- G-SC Module: 9CDCR111UR-00
- Front panel board_CFP2001: 9CFP2001NR-00
- Power supply module: 25EP0-22000A-L0S
- Mini-DP to D-Sub cable: 25CRN-200801-K1R (optional)
* ข้อมูลเบื้องต้นมีใว้สำหรับอ้างอิงเท่านั้น GIGABYTE ขอสงวนสิทธิ์ในการปรับเปลี่ยนหรือแก้ไขเนื้อหาได้ตลอดเวลาโดยไม่ต้องแจ้งให้ทราบล่วงหน้า
* ประสิทธิภาพสูงสุดที่ใช้ในการประชาสัมพันธ์เป็นเพียงข้อมูลตามทฤษฎีจากผู้ผลิตชิพเซตที่เกี่ยวข้อง หรือองค์กรที่กำหนดคุณสมบัติอินเตอร์เฟส ประสิทธิภาพที่แท้จริงอาจแตกต่างกันโดยการตั้งค่าของระบบที่ไม่เหมือนกัน
* เครื่องหมายการค้าและโลโก้คุณสมบัติต่างๆ เป็นของผู้ถือสิทธิ์นั้นๆ
* เนื่องจากความต้องการหน่วยความจำมาตรฐานของสถาปัตยกรรมคอมพิวเตอร์ต่อหน่วยที่ไม่เหมือนกัน ดังนั้นขนาดหน่วยความจำที่จำเป็นอาจน้อยกว่าจำนวนที่ระบุไว้ก็ได้
* ประสิทธิภาพสูงสุดที่ใช้ในการประชาสัมพันธ์เป็นเพียงข้อมูลตามทฤษฎีจากผู้ผลิตชิพเซตที่เกี่ยวข้อง หรือองค์กรที่กำหนดคุณสมบัติอินเตอร์เฟส ประสิทธิภาพที่แท้จริงอาจแตกต่างกันโดยการตั้งค่าของระบบที่ไม่เหมือนกัน
* เครื่องหมายการค้าและโลโก้คุณสมบัติต่างๆ เป็นของผู้ถือสิทธิ์นั้นๆ
* เนื่องจากความต้องการหน่วยความจำมาตรฐานของสถาปัตยกรรมคอมพิวเตอร์ต่อหน่วยที่ไม่เหมือนกัน ดังนั้นขนาดหน่วยความจำที่จำเป็นอาจน้อยกว่าจำนวนที่ระบุไว้ก็ได้
SUPPORT
BIOS
คำอธิบาย
เวอร์ชั่น
ขนาด
วันที่
Warning:
เนื่องจากความเสี่ยงที่อาจส่งผลให้ BIOS เกิดความเสียหาย, เราจึงไม่แนะนำให้คุณแฟลช BIOS หาก BIOS เวอร์ชั่นเดิมยังสามารถทำงานได้เป็นปกติ อย่างไรนั้นหากคุณต้องการแฟลช BIOS จริงๆ ควรกระทำด้วยความระมัดระวังเพราะหากเกิดความผิดพลาดขึ้นจะทำให้ BIOS ทำงานล้มเหลว.
อะไรคือ BETA?
BETA เป็นคุณสมบัติใหม่ของการปรับปรุงผลิตภัณฑ์ ไม่ใช่การเปลี่ยนแปลงคุณสมบัติทั้งหมด เป็นเพียงหนึ่งในคุณสมบัติที่อยู่ในช่วงของการพัฒนาในการรวบรวมฟีเจอร์ใหม่ๆ เข้ามาใช้งาน เพื่อให้ลูกค้าได้สัมผัสกับประสบการณ์ที่ดีที่สุด..
เนื่องจากความเสี่ยงที่อาจส่งผลให้ BIOS เกิดความเสียหาย, เราจึงไม่แนะนำให้คุณแฟลช BIOS หาก BIOS เวอร์ชั่นเดิมยังสามารถทำงานได้เป็นปกติ อย่างไรนั้นหากคุณต้องการแฟลช BIOS จริงๆ ควรกระทำด้วยความระมัดระวังเพราะหากเกิดความผิดพลาดขึ้นจะทำให้ BIOS ทำงานล้มเหลว.
อะไรคือ BETA?
BETA เป็นคุณสมบัติใหม่ของการปรับปรุงผลิตภัณฑ์ ไม่ใช่การเปลี่ยนแปลงคุณสมบัติทั้งหมด เป็นเพียงหนึ่งในคุณสมบัติที่อยู่ในช่วงของการพัฒนาในการรวบรวมฟีเจอร์ใหม่ๆ เข้ามาใช้งาน เพื่อให้ลูกค้าได้สัมผัสกับประสบการณ์ที่ดีที่สุด..
- All
- All
- Windows Server 2022
- Windows Server 2019
- Windows Server 2016 R2 64bit
- Windows Server 2016 64bit
- Windows Server 2012 R2 64bit
- Windows Server 2012 64bit
- Windows 10 64bit
- Ubuntu
- Linux CentOS
- Linux
ยูทิลิตี้
คำอธิบาย
เวอร์ชั่น
ขนาด
วันที่
GSM Server
Version : 2.12
926.33 MB
2566/01/18
ระบบปฏิบัติการ: Linux,Windows Server 2016 64bit,Windows Server 2019
GSM CLI
Version : 2.1.60
111.39 MB
2566/01/18
ระบบปฏิบัติการ: Windows Server 2012 64bit,Windows Server 2012 R2 64bit,Linux CentOS,Windows 10 64bit,Ubuntu,Windows Server 2016 R2 64bit,Windows Server 2019,Windows Server 2022
GSM Agent
Ubuntu Server for ARM 22.04.1 LTS
(Including installation guide)
Ubuntu Server for ARM 22.04.1 LTS
(Including installation guide)
Version : 2.5
226.76 MB
2565/10/14
ระบบปฏิบัติการ: Ubuntu
BMC Restore Default Setting utility
Version : 1.0
0.15 MB
2563/03/17
ระบบปฏิบัติการ: Ubuntu
Firmware
คำอธิบาย
เวอร์ชั่น
ขนาด
วันที่
BMC Firmware with embedded GIGABYTE Management Console
(AST2600 AMI)
(AST2600 AMI)
Version : 13.04.12
110.92 MB
2565/12/12
ภาษาอังกฤษ
รายการการสนับสนุน
คำอธิบาย
เวอร์ชั่น
ขนาด
วันที่
QVL Support List
Version : 1.0
0.2 MB
2565/09/22
QVL for R182-P91, R282-P91, R282-P92 (2022/Q3)
Back to R282-P92
