G292-Z43 (rev. 100)

2U
448 x 87.5 x 800

MZ42-G20

AMD EPYC™ 7002 series processor family
Dual processors, 7nm technology
Up to 64-core, 128 threads per processor
cTDP up to 240W

NOTE: If only 1 CPU is installed, some PCIe or memory functions might be unavailable

Socket SP3

System on Chip

16 x DIMM slots
DDR4 memory supported only
8-Channel memory architecture per processor
RDIMM modules up to 128GB supported
LRDIMM modules up to 128GB supported
Memory speed: Up to 3200 MHz

2 x 10Gb/s BASE-T LAN ports (Intel^® X550-AT2 controller)
1 x 10/100/1000 management LAN

Integrated in Aspeed^® AST2500
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp, DDR4 SDRAM

8 x 2.5" hot-swappable HDD/SSD bays
- 4 x green HDD trays compatible with Gen4 U.2 or SATA/SAS devices
- 4 x blue HDD trays compatible with SATA/SAS devices only

SAS card is required for SAS devices support

Recommended 12Gb/s SAS cards:
CRA4448
CRA4548

Supported

Supported via add-on SAS Card

Depends on RAID HBA

N/A

16 x PCIe x16 slots (Gen4 x16 bus) for single slot GPUs ( Broadcom solution)
2 x PCIe x16 (Gen4 x16 bus) Half-length low-profile slots

- Maximum limitation of GPU card: 285mm (L) x 111.5mm (W) x 39.5mm (H)
- System is validated for population with a uniform GPU model
- Support is not provided for mixed GPU populations
- For the latest GPU cards QVL, please contact your GIGABYTE representative

1 x TPM header

1 x Power button with LED
1 x ID button with LED
2 x LAN activity LEDs
1 x HDD activity LED
1 x System status LED
1 x Reset button

2 x USB 3.0
1 x VGA
2 x RJ45
1 x MLAN
1 x Power button with LED
1 x ID button with LED
1 x Reset button
1 x NMI button
1 x System status LED

8 x SAS/SATA or 4 x Gen4 U.2 ports and 4 x SAS/SATA
Backplane P/N: 9CBPG084NR-00
Bandwidth: SATA 6Gb/s, SAS 12Gb/s and PCIe Gen4 x4

1 x TPM header with SPI interface
Optional TPM2.0 kit: CTM010

2+0 2200W 80 PLUS Platinum power supply

AC Input:
- 100-127V~/ 14A, 47-63Hz
- 200-240V~/ 12.6A, 47-63Hz

DC Output:
- Max 1200W/ 100-127V~
+12.12V/ 95.6A
+12Vsb/ 3.5A
- Max 2200W/ 200-240V
+12.12V/ 178.1A
+12Vsb/ 3.5A

NOTE: The system power supply requires C19 type power cord

Aspeed^® AST2500 management controller
GIGABYTE Management Console (AMI MegaRAC SP-X) web interface

• Dashboard
• JAVA Based Serial Over LAN
• HTML5 KVM
• Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
• Sensor Reading History Data
• FRU Information
• SEL Log in Linear Storage / Circular Storage Policy
• Hardware Inventory
• Fan Profile
• System Firewall
• Power Consumption
• Power Control
• LDAP / AD / RADIUS Support
• Backup & Restore Configuration
• Remote BIOS/BMC/CPLD Update
• Event Log Filter
• User Management
• Media Redirection Settings
• PAM Order Settings
• SSL Settings
• SMTP Settings

Windows Server 2016 ( X2APIC/256T not supported)
Windows Server 2019

Red Hat Enterprise Linux 7.6 ( x64) or later
Red Hat Enterprise Linux 8.0 ( x64) or later

SUSE Linux Enterprise Server 12 SP4 ( x64) or later
SUSE Linux Enterprise Server 15 SP1 ( x64) or later

Ubuntu 16.04.6 LTS (x64) or later
Ubuntu 18.04.3 LTS (x64) or later
Ubuntu 20.04 LTS (x64) or later

VMware ESXi 6.5 EP15 or later
VMware ESXi 6.7 Update3 or later
VMware ESXi 7.0 or later

Citrix Hypervisor 8.1.0 or later

Net Weight: 30 kg
Gross Weight: 36 kg

8 x 80x80x38mm (16,300rpm)

Operating temperature: 10°C to 35°C
Operating humidity: 8%-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)

NOTE: Please contact Technical Support for more information about optimized GPU operating temperature

1 x G292-Z43
2 x CPU heatsinks
1 x Rail kit

- Barebone with rail kit: 6NG292Z43MR-00
- Motherboard: 9MZ42G20NR-00
- Tool-less rail kit: 25HB2-A86102-K0R
- CPU heatsink: 25ST1-44320N-A3R/ 25ST1-44320P-A3R
- Back plane board: 9CBPG084NR-00
- Fan module: 25ST2-883827-D0R
- Power supply: 25EP0-222001-D0S
- C19 type power cord 125V/15A (US): 25CP1-018000-Q0R (optional)
- C19 type power cord 250V/16A (EU): 25CP3-01830H-Q0R (optional)
