1U
438 x 43.5 x 660

MP32-AR1

Ampere^® Altra^® Max Processor
Ampere^® Altra^® Processor

Single processor, TDP 250W

1 x LGA 4926

System on Chip

16 x DIMM slots
Support DDR4 RDIMM/LRDIMM
8-Channel memory per processor
Up to 3200 MT/s

^[Note] Only supports configurations with 1, 2, 4, 6, 8, 12, or 16 DIMMs.

Rear:
2 x 1Gb/s LAN (1 x Intel^® I350-AM2)
1 x 10/100/1000 Mbps Management LAN

Integrated in ASPEED^® AST2500
- 1 x VGA port

Front hot-swap:
4 x 2.5" Gen3 NVMe
6 x 2.5" SATA/SAS, from CRAO338 SAS RAID card

Internal M.2:
2 x M.2 (2242/2260/2280/22110), PCIe Gen4 x4

Supported via SAS add-in cards

RAID 0/1/1E/10

Riser Card CRS101D:
- 1 x FHHL x16 (Gen4 x16)

1 x OCP 2.0 mezzanine (Gen3 x16), occupied by CRAO338 SAS RAID card

1 x USB 3.0 port (Type-A)
1 x Power button with LED
1 x ID button with LED
1 x Reset button
2 x LAN activity LEDs
1 x Storage activity LED
1 x System status LED

3 x USB 3.0 ports (Type-A)
1 x VGA port
1 x Debug port
2 x RJ45 ports
1 x MLAN port
1 x ID button with LED

Speed and bandwidth:
PCIe Gen3 x4 or SATA 6Gb/s or SAS 12Gb/s

1 x TPM header with SPI interface
- Optional TPM2.0 kit: CTM010

1+1 650W 80 PLUS Platinum redundant power supplies

AC Input:
- 100-240Vac~/ 10-5A, 50-60Hz

DC Input:
- 190-310Vdc/ 5-3A

DC Output:
- Max 650W
+ 12V/ 52.9A
+ 5Vsb/ 4.0A

ASPEED^® AST2500 Baseboard Management Controller
GIGABYTE Management Console (AMI MegaRAC SP-X) web interface

• Dashboard
• HTML5 KVM
• Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
• Sensor Reading History Data
• FRU Information
• SEL Log in Linear Storage / Circular Storage Policy
• Hardware Inventory
• Fan Profile
• System Firewall
• Power Consumption
• Power Control
• LDAP / AD / RADIUS Support
• Backup & Restore Configuration
• Remote BIOS/BMC/CPLD Update
• Event Log Filter
• User Management
• Media Redirection Settings
• PAM Order Settings
• SSL Settings
• SMTP Settings

CentOS 8.3-2011 (aarch64) or later
CentOS-8.4.2105 (aarch64) or later
CentOS-8.5.2111 (aarch64) or later

Debian 10.9 (Buster)
Debian 11.1

Fedora Server 33-1.2 (aarch64) or later
Fedora Server 35-1.2 (aarch64) or later

OracleLinux R8 U2
OracleLinux R8 U5

Red Hat Enterprise Linux 8.3 (aarch64) or later
Red Hat Enterprise Linux 8.5 (aarch64) or later

SUSE Linux Enterprise Server 15 SP2 (aarch64) or later
SUSE Linux Enterprise Server 15 SP3 (aarch64) or later

Ubuntu 18.04.5 LTS (aarch64) or later
Ubuntu 20.04.1 LTS (aarch64) or later

5 x 40x40x56mm

Operating temperature: 10°C to 35°C
Operating humidity: 8% to 80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20% to 95% (non-condensing)

985 x 588 x 250 mm

1 x R152-P30
1 x CPU heatsink
1 x Rail kit

- Barebone package: 6NR152P30MR-00-1*
- Motherboard: 9MP32AR1NR-00*
- Rail kit: 25HB2-3A0202-K0R
- CPU heatsink: 25ST1-2534Z0-C1R
- Backplane board - CBP10A3: 9CBP10A3NR-00*
- Fan module: 25ST2-44562G-D0R
- Riser card - CRS101D: 9CRS101DNR-00*
- OCP type SAS RAID card: 9CRAO338NR-00*
- Power supply: 25EP0-206506-F3S
