    • CPU
    • AMD Socket AM5, support for:
      AMD Ryzen™ 7000 / Ryzen™ 8000 / Ryzen™ 9000 Series Processors

      * Please refer to "CPU Support List" for more information.

      1. AMD Socket AM5, support for: AMD Ryzen™ 7000 / Ryzen™ 8000 / Ryzen™ 9000 Series Processors
      (Please refer "CPU Support List" for more information.)
    • Socket
    • Socket AM5
      Socket AM5
    • Chipset
    • AMD B650
      1. AMD B650
    • Memory
    • Support for DDR5 8000(OC)/7800(OC)/7600(OC)/7200(OC)/7000(OC)/6800(OC)/6666(OC)/6600(OC)/6400(OC)/6200(OC)/ 6000(OC)/5600(OC)/5200/4800/4400 MT/s memory modules
      4 x DDR5 DIMM sockets supporting up to 256 GB (64 GB single DIMM capacity) of system memory
      Dual channel memory architecture
      Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
      Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and Extreme Memory Profile (XMP) memory module
      (The CPU and memory configuration may affect the supported memory types, data rate (speed), and number of DRAM modules, please refer to "Memory Support List" for more information.)
      1. Support for DDR5 8000(OC)/ 7800(OC)/ 7600(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6666(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5600(OC)/ 5200/ 4800/ 4400 MT/s memory modules
      2. 4 x DDR5 DIMM sockets supporting up to 256 GB (64 GB single DIMM capacity) of system memory
      3. Dual channel memory architecture
      4. Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
      5. Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and Extreme Memory Profile (XMP) memory module
      (The CPU and memory configuration may affect the supported memory types, data rate (speed), and number of DRAM modules, please refer to "Memory Support List" for more information.)
    • Onboard Graphics
    • Integrated Graphics Processor with AMD Radeon™ Graphics support:
      - 1 x DisplayPort, supporting a maximum resolution of 3840x2160@144 Hz

      * Support for DisplayPort 1.4 version and HDR.


      - 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz

      * Support for HDMI 2.1 version and HDCP 2.3.
      ** Support for native HDMI 2.1 TMDS compatible ports.


      (Graphics specifications may vary depending on CPU support.)
      Integrated Graphics Processor:
      1. 1 x DisplayPort, supporting a maximum resolution of 3840x2160@144 Hz
        * Support for DisplayPort 1.4 version and HDR.
      2. 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
        * Support for HDMI 2.1 version and HDCP 2.3.
        ** Support native HDMI 2.1 TMDS compatible ports.
      (Graphics specifications may vary depending on CPU support.)
    • Audio
    • Realtek® Audio CODEC
      High Definition Audio
      2/4/5.1/7.1-channel

      * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings.

      1. Realtek® Audio CODEC
      2. High Definition Audio
      3. 2/4/5.1/7.1-channel
        * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings.
    • LAN
    • Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
      1. Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
    • Expansion Slots
    • 1 x PCI Express x16 slot (PCIEX16), integrated in the CPU:
      - AMD Ryzen™ 7000 Series Processors/ Ryzen™ 9000 Series Processors support PCIe 4.0 x16 mode
      - AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x8 mode
      - AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4 mode
      * The PCIEX16 slot can only support a graphics card or an NVMe SSD. If only one graphics card is to be installed, be sure to install it in the PCIEX16 slot.

      Chipset:
      - 2 x PCI Express x16 slots, supporting PCIe 3.0 and running at x1 (PCIEX1_1/2)
      1 x PCI Express x16 slot (PCIEX16), integrated in the CPU:
      1. AMD Ryzen™ 7000 Series Processors/ Ryzen™ 9000 Series Processors support PCIe 4.0 x16 mode
      2. AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x8 mode
      3. AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4 mode
        * The PCIEX16 slot can only support a graphics card or an NVMe SSD. If only one graphics card is to be installed, be sure to install it in the PCIEX16 slot.
      Chipset:
      1. 2 x PCI Express x16 slots, supporting PCIe 3.0 and running at x1 (PCIEX1_1/2)
    • Wireless Communication module
    • Realtek® Wi-Fi 6E RTL8852CE (PCB rev. 1.0)
      - WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands
      - BLUETOOTH 5.3
      - Support for 11ax 160MHz wireless

      Intel® Wi-Fi 6E AX210 (PCB rev. 1.1)
      - WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands
      - BLUETOOTH 5.3
      - Support for 11ax 160MHz wireless
      (Actual data rate may vary depending on environment and equipment.)
      AMD Wi-Fi 6E RZ616 (MT7922A22M) (For PCB rev. 1.0)
      1. WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands
      2. BLUETOOTH 5.2
      3. Support for 11ax 160MHz wireless standard
      Intel® Wi-Fi 6E AX210 (For PCB rev. 1.1)
      1. WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands
      2. BLUETOOTH 5.3
      3. Support for 11ax 160MHz wireless standard
      (Actual data rate may vary depending on environment and equipment.)
    • Storage Interface
    • 1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 25110/22110/2580/2280 SSDs:
      - AMD Ryzen™ 7000 Series Processors/ Ryzen™ 9000 Series Processors support PCIe 5.0 x4/x2 SSDs
      - AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs
      - AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4/x2 SSDs

      1 x M.2 connector (M2B_CPU), integrated in the CPU, supporting Socket 3, M key, type 25110/22110/2580/2280 SSDs:
      - AMD Ryzen™ 7000 Series Processors/ Ryzen™ 9000 Series Processors support PCIe 4.0 x4/x2 SSDs
      - AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs
      - AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x2 SSDs

      1 x M.2 connector (M2C_SB), integrated in the Chipset, supporting Socket 3, M key, type 25110/22110/2580/2280 PCIe 4.0 x4/x2 SSDs
      4 x SATA 6Gb/s connectors
      RAID 0, RAID 1, and RAID 10 support for NVMe SSD storage devices
      RAID 0, RAID 1, and RAID 10 support for SATA storage devices
      1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 25110/22110/2580/2280 SSDs:
      1. AMD Ryzen™ 7000 Series Processors/ Ryzen™ 9000 Series Processors support PCIe 5.0 x4/x2 SSDs
      2. AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs
      3. AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4/x2 SSDs
      1 x M.2 connector (M2B_CPU), integrated in the CPU, supporting Socket 3, M key, type 25110/22110/2580/2280 SSDs:
      1. AMD Ryzen™ 7000 Series Processors/ Ryzen™ 9000 Series Processors support PCIe 4.0 x4/x2 SSDs
      2. AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs
      3. AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x2 SSDs
      1 x M.2 connector (M2C_SB), integrated in the Chipset, supporting Socket 3, M key, type 25110/22110/2580/2280 PCIe 4.0 x4/x2 SSDs
      4 x SATA 6Gb/s connectors
      RAID 0, RAID 1, and RAID 10 support for NVMe SSD storage devices
      RAID 0, RAID 1, and RAID 10 support for SATA storage devices
    • USB
    • CPU:
      - 1 x USB Type-C® port on the back panel, with USB 3.2 Gen 2 support
      - 2 x USB 3.2 Gen 2 Type-A ports (red) on the back panel
      CPU + USB 2.0 Hub:
      - 4 x USB 2.0/1.1 ports on the back panel
      Chipset:
      - 1 x USB Type-C® port with USB 3.2 Gen 2x2 support, available through the internal USB header
      - 3 x USB 3.2 Gen 1 ports (1 port on the back panel, 2 ports available through the internal USB header)
      - 4 x USB 2.0/1.1 ports available through the internal USB headers
      Chipset+USB 3.2 Gen 1 Hub:
      - 4 x USB 3.2 Gen 1 ports on the back panel
      CPU:
      1. 1 x USB Type-C® port on the back panel, with USB 3.2 Gen 2 support
      2. 2 x USB 3.2 Gen 2 Type-A ports (red) on the back panel
      CPU + USB 2.0 Hub:
      1. 4 x USB 2.0/1.1 ports on the back panel
      Chipset:
      1. 1 x USB Type-C® port with USB 3.2 Gen 2x2 support, available through the internal USB header
      2. 3 x USB 3.2 Gen 1 ports (1 port on the back panel, 2 ports available through the internal USB header)
      3. 4 x USB 2.0/1.1 ports available through the internal USB headers
      Chipset+USB 3.2 Gen 1 Hub:
      1. 4 x USB 3.2 Gen 1 ports on the back panel
    • Internal I/O Connectors
    • 1 x 24-pin ATX main power connector
      1 x 8-pin ATX 12V power connector
      1 x 4-pin ATX 12V power connector
      1 x CPU fan header
      1 x CPU fan/water cooling pump header
      3 x system fan headers
      1 x system fan/water cooling pump header
      3 x addressable RGB Gen2 LED strip headers
      1 x RGB LED strip header
      3 x M.2 Socket 3 connectors
      4 x SATA 6Gb/s connectors
      1 x front panel header
      1 x front panel audio header
      1 x USB Type-C® header, with USB 3.2 Gen 2x2 support
      1 x USB 3.2 Gen 1 header
      2 x USB 2.0/1.1 headers
      1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0/GC-TPM2.0 SPI V2 module only)
      1 x reset button
      1 x reset jumper
      1 x Clear CMOS jumper
      1. 1 x 24-pin ATX main power connector
      2. 1 x 8-pin ATX 12V power connector
      3. 1 x 4-pin ATX 12V power connector
      4. 1 x CPU fan header
      5. 1 x water cooling CPU fan header
      6. 3 x system fan headers
      7. 1 x system fan/water cooling pump header
      8. 2 x addressable LED strip headers
      9. 2 x RGB LED strip headers
      10. 1 x CPU cooler LED strip/RGB LED strip header
      11. 3 x M.2 Socket 3 connectors
      12. 4 x SATA 6Gb/s connectors
      13. 1 x front panel header
      14. 1 x front panel audio header
      15. 1 x USB Type-C® header, with USB 3.2 Gen 2x2 support
      16. 1 x USB 3.2 Gen 1 header
      17. 2 x USB 2.0/1.1 headers
      18. 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 / GC-TPM2.0 SPI V2 module only)
      19. 1 x reset button
      20. 1 x reset jumper
      21. 1 x Clear CMOS jumper
    • Back Panel Connectors
    • 1 x Q-Flash Plus button
      2 x antenna connectors (2T2R)
      1 x DisplayPort
      1 x HDMI port
      1 x USB Type-C® port, with USB 3.2 Gen 2 support
      2 x USB 3.2 Gen 2 Type-A ports (red)
      5 x USB 3.2 Gen 1 ports
      4 x USB 2.0/1.1 ports
      1 x RJ-45 port
      3 x audio jacks
      1. 1 x Q-Flash Plus button
      2. 2 x SMA antenna connectors (2T2R)
      3. 1 x DisplayPort
      4. 1 x HDMI port
      5. 1 x USB Type-C® port, with USB 3.2 Gen 2 support
      6. 2 x USB 3.2 Gen 2 Type-A ports (red)
      7. 5 x USB 3.2 Gen 1 ports
      8. 4 x USB 2.0/1.1 ports
      9. 1 x RJ-45 port
      10. 3 x audio jacks
    • Operating System
    • Support for Windows 11 64-bit
      Support for Windows 10 64-bit
      1. Support for Windows 11 64-bit
      2. Support for Windows 10 64-bit
    • Form Factor
    • ATX Form Factor; 30.5cm x 24.4cm
      1. ATX Form Factor; 30.5cm x 24.4cm
