PC Case Comparison

Show Differences
Quick Navigate

Case Form Factor
Case Form Factor
Full Tower
Mid Tower
Mid Tower
Mid Tower
M/B Type
M/B Type
Mini ITX / Micro ATX / ATX / E-ATX
Mini ITX / Micro ATX / ATX / E-ATX
mini-ITX/m-ATX/ATX
mini-ITX/m-ATX/ATX
Color
Color
Black
Black
Black
Black
Materials
Materials
Aluminum, Steel, Plastic, Glass
Steel, Plastic, Glass
Steel, Plastic, Glass
Steel, Plastic, Glass
Dimensions
Dimensions
H=714 W=301 D=671 mm (Within ± 1% error)
H=548 W=250 D=482 mm (Within ± 1% error)
H= 469 W= 211 D= 458mm (Within ± 1% error)
H=480 W=210 D=435 mm (Within ± 1% error)
Expansion Slots
Expansion Slots
8 + 2 (Requires PCI-E Riser Cable)
8 + 3 (Requires PCIE Riser Cable)
7 or 2 (Requires PCIE Riser Cable)
7
5.25" Drive Bays
5.25" Drive Bays
None
None
None
None
3.5“/2.5” Drive Bays
3.5“/2.5” Drive Bays
4
2
2
2
2.5" Drive Bays
2.5" Drive Bays
6
2
3(Behind the MB tray)
2
I/O Panel
I/O Panel
USB 3.1 Gen-2 Type-C x1
USB 3.0 x4
HDMI x1
RGB SW Button
Fan Speed Button
Audio In & Out (supports AC97 /HD Audio)
USB 3.1 Gen2 Type-C x1 / USB 3.0 x2 / Audio In & Out
(supports AC97 /HD Audio)
HDMI x1
USB 3.1 Gen2 Type-C x1
USB 3.0 x2
Audio In & Out (Supports AC97 / HD Audio)
USB 3.0 *2
RGB LED Switch
Reset Button
Audio In & Out (Supports AC97 / HD Audio)
Pre-installed Fans
Pre-installed Fans
Front : 120mm x3 (PWM)
Rear : 120mm x2 (ARGB&PWM)
Front : 120mm x3 (ARGB & PWM)
Rear : 120mm x1 (ARGB & PWM)
Fan Support
Fan Support
Front : 120mm x3 / 140mm x3
Top : 120mm x3 / 140mm x3
Rear : 120mm x2 / 140mm x1
Front : 120mm x3 / 140mm x3
Top : 120mm x3 / 140mm x2
Rear : 120mm x1 / 140mm x1
"Front : 120mm x3 / 140mm x2
Top : 120mm x2 / 140mm x2
Rear : 120mm x1
(Pre-installed: Rear 120mm x 1, Front 120mm x 1)
Rear : 120mm x1 (Pre-installed)
Top : 120mm x2 / 140mm x2
Front : 120mm x3 / 140mm x2
Radiator Support
Radiator Support
Front : Max 360mm
Top : Max 420mm
Rear : Max 140mm
Front : Max 420mm
Top : Max 360mm
Rear : 140mm
Front : 360mm / 280mm / 240mm
Rear : 120mm
Rear : 120mmx1
Top : 120mm x2 / 240mm x1
Front : 120mm x2 / 140mm x2 / 240mm x1 / 280mm x1
Power Supply Type
Power Supply Type
Standard ATX (Not included)
Standard ATX (Not included)
Standard ATX (Not included)
Standard ATX (not included)
Maximum Compatibility
Maximum Compatibility
CPU Height : 198mm
GPU Length : 490mm
PSU Length : 200mm
CPU Height : 190mm
GPU Length : 420mm
PSU Length : 220mm
CPU Height : 170mm
GPU Length : 400mm
PSU Length : 180mm
CPU Height : 165mm
GPU Length : 330mm
PSU Length : 170mm
Vertical GPU Mount
Vertical GPU Mount
Yes
*54mm total clearance, standard 2-slot GPU (<38mm thickness) recommended for optimum cooling
Yes (Default: 73mm total clearance / VGA holder bracket: 160mm total clearance)
Yes
Dust Filters
Dust Filters
Bottom
Top, Front, Bottom
Top, Front, Bottom
Top, Bottom
RGB Lighting
RGB Lighting
Yes (Support RGB Fusion 2.0)
Yes (Support RGB Fusion 2.0)
Yes (Support RGB Fusion 2.0)
Yes
Weight
Weight
N.W. 19.2 Kg
N.W. 13.4 Kg
N.W. 8 Kg
N.W. 7.24 Kg
Package Dimensions
Package Dimensions
H=773 W=406 D=820 mm
H=594 W=336 D=584 mm
H=542 W=309 D=541 mm
H=514 W=277 D=523 mm
Accessories
Accessories
1. Manual
2. Accessories kit
1. Manual
2. Accessories kit
1. Manual
2. Accessory Kit
1. Manual
2. Accessory Kit
