SPECIFICATIONS

Ports
2 x internal Mini-SAS HD SFF8643 connectors for up to 8 x SAS 12Gb/s ports
Up to 240 x physical devices supported via expander
Supports SAS / Enterprise SATA hard drives
Controller
Broadcom® SAS3108
RAID
Hardware RAID 0/1/5/6/10/50/60
2GB DDR3 cache memory
Compatible with Broadcom® CacheVault Flash Cache Protection Module PN: 25FCZ-CVM020-L1R
Interface
PCIe x8 slot (3.0 x8 bus)
Dimension
168 x 68.9 mm
Format
Half-length low profile card
Available with full-height or low-profile bracket
Ordering Information
9CRA4648NR-00
12 units per carton
Packaging dimensions: 305 x 285 x 250 mm
Remark
    California Proposition 65:
    WARNING: This product contains a chemical, including lead,
    know to the state of California to cause birth defects or other reproductive harm.
    http://www.p65warnings.ca.gov/
* The entire materials provided herein are for reference only. GIGABYTE reserves the right to modify or revise the content at anytime without prior notice.
* Advertised performance is based on maximum theoretical interface values from respective Chipset vendors or organization who defined the interface specification. Actual performance may vary by system configuration.
* All trademarks and logos are the properties of their respective holders.
* Due to standard PC architecture, a certain amount of memory is reserved for system usage and therefore the actual memory size is less than the stated amount.

SUPPORT

  • Choose your OS
  • Choose your OS
  • Windows Server 2016 64bit
  • Windows Server 2012 64bit
  • Windows Server 2008 R2 64bit
  • Windows 8.1 64bit
  • Windows 10 64bit
  • VMware 6.0 U2
  • VMware 6.0 U1
  • Linux
  • FreeBSD
Chipset
Chipset
Version
Size
Date
LSI SAS3108 Driver
Version : 6.14-6.714.05.00
6.94 MB
2017/08/15
OS: Windows Server 2012 64bit,Windows Server 2008 R2 64bit,Windows 8.1 64bit,Windows 10 64bit,Windows Server 2016 64bit
  • Choose your OS
  • Choose your OS
  • Windows Server 2016 64bit
  • Windows Server 2012 R2 64bit
  • Windows Server 2008 R2 64bit
  • Windows 8.1 64bit
  • Windows 10 64bit
  • Linux
