NVIDIA HGX Rubin NVL8

GIGAPOD AI DLC POD Scale Solution

Built on the NVIDIA HGX^™ Rubin NVL8 platform
72 x GIGABYTE G2L4 2U DLC GPU servers
576 x NVIDIA Rubin GPUs
144 x Intel^® Xeon^® 6700/6500-Series Processors
2.3 TB HBM4 GPU memory per server
Up to 305 kW rack power consumption
Reserved space for InfiniBand / Ethernet switches
Integrated G-REX cluster-level DLC power and cooling management kit
Compatible with GIGABYTE POD Manager software for cluster management / orchestration
Supports flexible storage with GIGABYTE storage servers and validated partner solutions

Save

Quote

Configuration

	PAD3 Series
Cooling Type	Direct Liquid Cooling
Racks per Scalable Unit (Compute + Management)	9+3		8+3	6+4
Rack Height	48U
Server Model	G2L4-SD4-LA08
Servers per Rack	8 x 2U DLC GPU servers		9 x 2U DLC GPU servers	12 x 2U DLC GPU servers
CPU	Intel^® Xeon^® 6 Processors - Intel^® Xeon^® 6700-Series Processors - Intel^® Xeon^® 6500-Series Processors Total 144 processors
GPU	NVIDIA HGX^™ Rubin NVL8 - Total 576 x NVIDIA Rubin SXM
Switch	Flexible validated InfiniBand / Ethernet switch configurations
Power Shelves per Rack	4 x 3RU power shelves
Power Socket	110 kW, 100 A, 3-phase
Rack Power Consumption	Up to 215 kW	Up to 210 kW	Up to 235 kW	Up to 305 kW
CDU	In-Rack	In-Row
CDU Specifications	In-Row Liquid-to-Liquid CDU: Cooling Capacity: 1800 kW (4°C approach temperature) Primary Loop Connections: 5" clamp interface (inlet/outlet) Input Power: 2 x IEC 60309 100A (4P5W, 6h plug), AC 380 V ±10% / 3P / 60 Hz 1+1 redundant pumps and redundant A/B power feeds ^[Note]The Facility Water System (FWS) loop must meet the water quality values specified in ASHRAE Liquid Cooling Guidelines for Datacom Equipment Centers, 2nd ed., Ch. 5, as reproduced in the ASHRAE TC 9.9 white paper Water-Cooled Servers: Common Designs, Components, and Processes (2019), Table 1.
Management	Integrated G-REX DLC power and cooling management kit: - N120-LS0 management node - Real-time cluster-level monitoring and control - Supports Modbus, Redfish, and REST APIs for seamless integration with CDUs and RDHx Optional GIGABYTE POD Management (GPM) software suite: - Essential single-node BMC for real-time hardware health and remote system oversight - Unified cluster-scale management and deep telemetry for high-density deployments - Total POD-level orchestration for infrastructure provisioning and environmental monitoring
Storage Solutions	Flexible validated partner solutions with GIGABYTE storage servers


Cooling Type
Racks per Scalable Unit (Compute + Management)
Rack Height
Server Model
Servers per Rack
CPU
GPU
Switch
Power Shelves per Rack
Power Socket
Rack Power Consumption
CDU
CDU Specifications
Management
Storage Solutions

PAD3 Series
Direct Liquid Cooling
9+3
48U
G2L4-SD4-LA08
8 x 2U DLC GPU servers
Intel^® Xeon^® 6 Processors - Intel^® Xeon^® 6700-Series Processors - Intel^® Xeon^® 6500-Series Processors Total 144 processors
NVIDIA HGX^™ Rubin NVL8 - Total 576 x NVIDIA Rubin SXM
Flexible validated InfiniBand / Ethernet switch configurations
4 x 3RU power shelves
110 kW, 100 A, 3-phase
Up to 215 kW
In-Rack
In-Row Liquid-to-Liquid CDU: Cooling Capacity: 1800 kW (4°C approach temperature) Primary Loop Connections: 5" clamp interface (inlet/outlet) Input Power: 2 x IEC 60309 100A (4P5W, 6h plug), AC 380 V ±10% / 3P / 60 Hz 1+1 redundant pumps and redundant A/B power feeds ^[Note]The Facility Water System (FWS) loop must meet the water quality values specified in ASHRAE Liquid Cooling Guidelines for Datacom Equipment Centers, 2nd ed., Ch. 5, as reproduced in the ASHRAE TC 9.9 white paper Water-Cooled Servers: Common Designs, Components, and Processes (2019), Table 1.
Integrated G-REX DLC power and cooling management kit: - N120-LS0 management node - Real-time cluster-level monitoring and control - Supports Modbus, Redfish, and REST APIs for seamless integration with CDUs and RDHx Optional GIGABYTE POD Management (GPM) software suite: - Essential single-node BMC for real-time hardware health and remote system oversight - Unified cluster-scale management and deep telemetry for high-density deployments - Total POD-level orchestration for infrastructure provisioning and environmental monitoring
Flexible validated partner solutions with GIGABYTE storage servers

PAD3 Series
Direct Liquid Cooling
9+3
48U
G2L4-SD4-LA08
8 x 2U DLC GPU servers
Intel^® Xeon^® 6 Processors - Intel^® Xeon^® 6700-Series Processors - Intel^® Xeon^® 6500-Series Processors Total 144 processors
NVIDIA HGX^™ Rubin NVL8 - Total 576 x NVIDIA Rubin SXM
Flexible validated InfiniBand / Ethernet switch configurations
4 x 3RU power shelves
110 kW, 100 A, 3-phase
Up to 210 kW
In-Row
In-Row Liquid-to-Liquid CDU: Cooling Capacity: 1800 kW (4°C approach temperature) Primary Loop Connections: 5" clamp interface (inlet/outlet) Input Power: 2 x IEC 60309 100A (4P5W, 6h plug), AC 380 V ±10% / 3P / 60 Hz 1+1 redundant pumps and redundant A/B power feeds ^[Note]The Facility Water System (FWS) loop must meet the water quality values specified in ASHRAE Liquid Cooling Guidelines for Datacom Equipment Centers, 2nd ed., Ch. 5, as reproduced in the ASHRAE TC 9.9 white paper Water-Cooled Servers: Common Designs, Components, and Processes (2019), Table 1.
Integrated G-REX DLC power and cooling management kit: - N120-LS0 management node - Real-time cluster-level monitoring and control - Supports Modbus, Redfish, and REST APIs for seamless integration with CDUs and RDHx Optional GIGABYTE POD Management (GPM) software suite: - Essential single-node BMC for real-time hardware health and remote system oversight - Unified cluster-scale management and deep telemetry for high-density deployments - Total POD-level orchestration for infrastructure provisioning and environmental monitoring
Flexible validated partner solutions with GIGABYTE storage servers

PAD3 Series
Direct Liquid Cooling
8+3
48U
G2L4-SD4-LA08
9 x 2U DLC GPU servers
Intel^® Xeon^® 6 Processors - Intel^® Xeon^® 6700-Series Processors - Intel^® Xeon^® 6500-Series Processors Total 144 processors
NVIDIA HGX^™ Rubin NVL8 - Total 576 x NVIDIA Rubin SXM
Flexible validated InfiniBand / Ethernet switch configurations
4 x 3RU power shelves
110 kW, 100 A, 3-phase
Up to 235 kW
In-Row
In-Row Liquid-to-Liquid CDU: Cooling Capacity: 1800 kW (4°C approach temperature) Primary Loop Connections: 5" clamp interface (inlet/outlet) Input Power: 2 x IEC 60309 100A (4P5W, 6h plug), AC 380 V ±10% / 3P / 60 Hz 1+1 redundant pumps and redundant A/B power feeds ^[Note]The Facility Water System (FWS) loop must meet the water quality values specified in ASHRAE Liquid Cooling Guidelines for Datacom Equipment Centers, 2nd ed., Ch. 5, as reproduced in the ASHRAE TC 9.9 white paper Water-Cooled Servers: Common Designs, Components, and Processes (2019), Table 1.
Integrated G-REX DLC power and cooling management kit: - N120-LS0 management node - Real-time cluster-level monitoring and control - Supports Modbus, Redfish, and REST APIs for seamless integration with CDUs and RDHx Optional GIGABYTE POD Management (GPM) software suite: - Essential single-node BMC for real-time hardware health and remote system oversight - Unified cluster-scale management and deep telemetry for high-density deployments - Total POD-level orchestration for infrastructure provisioning and environmental monitoring
Flexible validated partner solutions with GIGABYTE storage servers

PAD3 Series
Direct Liquid Cooling
6+4
48U
G2L4-SD4-LA08
12 x 2U DLC GPU servers
Intel^® Xeon^® 6 Processors - Intel^® Xeon^® 6700-Series Processors - Intel^® Xeon^® 6500-Series Processors Total 144 processors
NVIDIA HGX^™ Rubin NVL8 - Total 576 x NVIDIA Rubin SXM
Flexible validated InfiniBand / Ethernet switch configurations
4 x 3RU power shelves
110 kW, 100 A, 3-phase
Up to 305 kW
In-Row
In-Row Liquid-to-Liquid CDU: Cooling Capacity: 1800 kW (4°C approach temperature) Primary Loop Connections: 5" clamp interface (inlet/outlet) Input Power: 2 x IEC 60309 100A (4P5W, 6h plug), AC 380 V ±10% / 3P / 60 Hz 1+1 redundant pumps and redundant A/B power feeds ^[Note]The Facility Water System (FWS) loop must meet the water quality values specified in ASHRAE Liquid Cooling Guidelines for Datacom Equipment Centers, 2nd ed., Ch. 5, as reproduced in the ASHRAE TC 9.9 white paper Water-Cooled Servers: Common Designs, Components, and Processes (2019), Table 1.
Integrated G-REX DLC power and cooling management kit: - N120-LS0 management node - Real-time cluster-level monitoring and control - Supports Modbus, Redfish, and REST APIs for seamless integration with CDUs and RDHx Optional GIGABYTE POD Management (GPM) software suite: - Essential single-node BMC for real-time hardware health and remote system oversight - Unified cluster-scale management and deep telemetry for high-density deployments - Total POD-level orchestration for infrastructure provisioning and environmental monitoring
Flexible validated partner solutions with GIGABYTE storage servers
