W332-Z00
(rev. 100)
Entry Workstation - AMD Ryzen™ 7000 Series
- AMD Ryzen™ 7000 Series Processors
- Dual Channel ECC / Non-ECC DDR5 Unbuffered DIMM, 4 DIMMs
- Realtek® DASH Remote Management
- Realtek® 2.5Gb/s LAN and 1Gb/s DASH LAN
- 1 x M.2 slot with PCIe Gen5 x4 interface
- 1 x M.2 slot with PCIe Gen4 x4 interface
- 2 x 3.5"/2.5" SATA bays
- 1 x PCIe Gen5 x16 slot
- 2 x PCIe Gen4 x4 and x1 slots
- Rear HDMI and DP support
- Single 500W 80 PLUS Bronze power supply
Get a Quote
* The entire materials provided herein are for reference only. GIGABYTE reserves the right to modify or revise the content at anytime without prior notice.
* Advertised performance is based on maximum theoretical interface values from respective Chipset vendors or organization who defined the interface specification. Actual performance may vary by system configuration.
* All trademarks and logos are the properties of their respective holders.
* Due to standard PC architecture, a certain amount of memory is reserved for system usage and therefore the actual memory size is less than the stated amount.
* Advertised performance is based on maximum theoretical interface values from respective Chipset vendors or organization who defined the interface specification. Actual performance may vary by system configuration.
* All trademarks and logos are the properties of their respective holders.
* Due to standard PC architecture, a certain amount of memory is reserved for system usage and therefore the actual memory size is less than the stated amount.
SPECIFICATIONS
Dimensions (WxHxD, mm)
Mini-Tower
198 x 370 x 375 mm
198 x 370 x 375 mm
Motherboard
MC13-NB0
CPU
AMD Ryzen™ 7000 Series Processors
Note:
- Recommend to install CPU TDP under 105W.
- The BIOS includes standard mode and performance mode. Users can refer to the manual for more details.
Note:
- Recommend to install CPU TDP under 105W.
- The BIOS includes standard mode and performance mode. Users can refer to the manual for more details.
Socket
1 x AM5
Chipset
AMD B650E
Memory
4 x DDR5 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory
Dual channel memory architecture
Support ECC Unbuffered DIMM 1Rx8/2Rx8 memory modules
Support Non-ECC Unbuffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Memory speed: Up to 5200 MT/s (1DPC), 3600 MT/s (2DPC)
Dual channel memory architecture
Support ECC Unbuffered DIMM 1Rx8/2Rx8 memory modules
Support Non-ECC Unbuffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Memory speed: Up to 5200 MT/s (1DPC), 3600 MT/s (2DPC)
LAN
2 x LAN ports
- Realtek® 2.5Gb/s LAN (RTL8125)
- Realtek® 1Gb/s DASH LAN (RTL8111EP)
- Realtek® 2.5Gb/s LAN (RTL8125)
- Realtek® 1Gb/s DASH LAN (RTL8111EP)
Video
1 x DP port: Maximum resolution of 4096x2160@60Hz; Supports DP 1.2.
1 x HDMI port: Maximum resolution of 4096x2160@60Hz; Supports HDMI 2.1, HDCP 2.3, HDR.
1 x HDMI port: Maximum resolution of 4096x2160@60Hz; Supports HDMI 2.1, HDCP 2.3, HDR.
Audio
Realtek® ALC897 audio codec
High Definition audio; 2/4/5.1/7.1-channel
3 ports Audio Jack (Line in/Line out/Mic)
High Definition audio; 2/4/5.1/7.1-channel
3 ports Audio Jack (Line in/Line out/Mic)
Storage
2 x 3.5"/2.5" SATA fixed bays
RAID
RAID 0/1/10
Peripheral Drives
Optional ODD devices
Expansion Slots
1 x PCIe x16 (Gen5 x16) slot, from CPU
1 x PCIe x16 (Gen4 x4) slot, from FCH
1 x PCIe x1 (Gen4 x1) slot, from FCH
1 x M.2 slot:
- M-key
- PCIe Gen5 x4, from CPU
- Supports 2242/2280 cards
1 x M.2 slot:
- M-key
- PCIe Gen4 x4, from CPU
- Supports 2242/2280 cards
1 x M.2 slot for Wi-Fi:
- E-key, from FCH
- Supports 2230 cards
1 x PCIe x16 (Gen4 x4) slot, from FCH
1 x PCIe x1 (Gen4 x1) slot, from FCH
1 x M.2 slot:
- M-key
- PCIe Gen5 x4, from CPU
- Supports 2242/2280 cards
1 x M.2 slot:
- M-key
- PCIe Gen4 x4, from CPU
- Supports 2242/2280 cards
1 x M.2 slot for Wi-Fi:
- E-key, from FCH
- Supports 2230 cards
Internal I/O
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
4 x SATA 6Gb/s ports
1 x CPU fan header
3 x System fan headers
1 x Serial header (COM)
1 x TPM header
1 x Front panel header
1 x Front Audio header
1 x Front USB3.2 Gen1 header
1 x 8-pin ATX 12V power connector
4 x SATA 6Gb/s ports
1 x CPU fan header
3 x System fan headers
1 x Serial header (COM)
1 x TPM header
1 x Front panel header
1 x Front Audio header
1 x Front USB3.2 Gen1 header
Front I/O
2 x USB3.2 Gen1 ports
1 x Line out port
1 x Mic in port
1 x Power Button
1 x Storage activity LED
1 x Reset Button
1 x Line out port
1 x Mic in port
1 x Power Button
1 x Storage activity LED
1 x Reset Button
Rear I/O
1 x Display port
1 x HDMI port
2 x Antenna ports (reserved for option)
3 x USB 3.2 Gen2 type A
1 x USB 3.2 Gen2 type C
1 x 2.5Gb/s RJ45 LAN port
1 x 1Gb/s RJ45 DASH LAN port
3 x Audio Jacks (Line in / Line out / Mic in)
1 x HDMI port
2 x Antenna ports (reserved for option)
3 x USB 3.2 Gen2 type A
1 x USB 3.2 Gen2 type C
1 x 2.5Gb/s RJ45 LAN port
1 x 1Gb/s RJ45 DASH LAN port
3 x Audio Jacks (Line in / Line out / Mic in)
TPM
Onboard with SPI interface
Power Supply
Single 500W 80 PLUS Bronze power supply
AC Input:
- 100-240V~/ 7-3A, 50-60Hz
DC Output:
- Max 500W/ 100-240V~
+12V/ 41.66A
+5V/ 20A
+3.3V/ 20A
+5Vsb/ 2.5A
AC Input:
- 100-240V~/ 7-3A, 50-60Hz
DC Output:
- Max 500W/ 100-240V~
+12V/ 41.66A
+5V/ 20A
+3.3V/ 20A
+5Vsb/ 2.5A
System Management
Realtek® DASH Remote Management
- Power state settings (on, off, restart, hibernate, or sleep)
- View hardware, firmware or BIOS versions
- Retrieve system health status
- USB device redirection
- Boot device selection
- View event logs
- Apply updates and security patches
- Text Console Redirection
- Software KVM
- Power state settings (on, off, restart, hibernate, or sleep)
- View hardware, firmware or BIOS versions
- Retrieve system health status
- USB device redirection
- Boot device selection
- View event logs
- Apply updates and security patches
- Text Console Redirection
- Software KVM
OS Compatibility
Windows 11 (64bit)
Windows 10 (64bit)
Windows 10 (64bit)
System Fans
2 x 92x92x25mm (4,500rpm)
Operating Properties
Operating temperature: 0°C to 30°C
Operating humidity: 8%-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)
Operating humidity: 8%-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)
Packaging Dimensions
512 x 324 x 503 mm
Packaging Content
1 x W332-Z00
1 x Quick Start Guide
Note: The CPU fansink is not included by default. Fansinks included in the AMD CPU package are recommended. Other verified fansinks are listed in the QVL.
1 x Quick Start Guide
Note: The CPU fansink is not included by default. Fansinks included in the AMD CPU package are recommended. Other verified fansinks are listed in the QVL.
Part Numbers
- Barebone package: 6BW332Z00MR-00-1*
- Chassis kit: 25EC2-W33100-C1R
- Motherboard: 9MC13NB0NR-00
- I/O shield: 12AIO-W33200-00R
- System Fan: 25Y00-92250-A20R
- SATA cable: 25CF4-350500-S9R
- Power supply: 25EP0-20500C-F3S
- Chassis kit: 25EC2-W33100-C1R
- Motherboard: 9MC13NB0NR-00
- I/O shield: 12AIO-W33200-00R
- System Fan: 25Y00-92250-A20R
- SATA cable: 25CF4-350500-S9R
- Power supply: 25EP0-20500C-F3S
* The entire materials provided herein are for reference only. GIGABYTE reserves the right to modify or revise the content at anytime without prior notice.
* Advertised performance is based on maximum theoretical interface values from respective Chipset vendors or organization who defined the interface specification. Actual performance may vary by system configuration.
* All trademarks and logos are the properties of their respective holders.
* Due to standard PC architecture, a certain amount of memory is reserved for system usage and therefore the actual memory size is less than the stated amount.
* Advertised performance is based on maximum theoretical interface values from respective Chipset vendors or organization who defined the interface specification. Actual performance may vary by system configuration.
* All trademarks and logos are the properties of their respective holders.
* Due to standard PC architecture, a certain amount of memory is reserved for system usage and therefore the actual memory size is less than the stated amount.
SUPPORT
Driver
BIOS
QVL
- All
- All
- Windows 11 64bit
- Windows 10 64bit
Audio
Audio
Version
Size
Date
Realtek Audio Driver
Version : 9605.1
70.88 MB
Apr 16, 2024
OS: Windows 10 64bit,Windows 11 64bit
Chipset
Chipset
Version
Size
Date
AMD Chipset Driver
Version : 4.07.13.2243
683.85 MB
Mar 28, 2023
OS: Windows 10 64bit,Windows 11 64bit
LAN
LAN
Version
Size
Date
SATA RAID/AHCI
SATA RAID/AHCI
Version
Size
Date
AMD RAID Driver
Version : 932.130
92.39 MB
May 10, 2023
OS: Windows 10 64bit,Windows 11 64bit
BIOS
Warning:
Because BIOS flashing is potentially risky, if you do not encounter problems using the current version of BIOS, it is recommended that you not flash the BIOS. To flash the BIOS, do it with caution. Inadequate BIOS flashing may result in system malfunction.
What is a BETA?
BETA describes a new version that is reliable yet may not include all the features of the final product. During this phase we are previewing new features and gathering customer input to insure our product provides the best experience possible.
Because BIOS flashing is potentially risky, if you do not encounter problems using the current version of BIOS, it is recommended that you not flash the BIOS. To flash the BIOS, do it with caution. Inadequate BIOS flashing may result in system malfunction.
What is a BETA?
BETA describes a new version that is reliable yet may not include all the features of the final product. During this phase we are previewing new features and gathering customer input to insure our product provides the best experience possible.
Description
Version
Size
Date
