W771-Z00
(rev. 100)
AMD® Ryzen™ Threadripper™ PRO Tower GPU Workstation
| Application:
AI
,
AI Training
,
AI Inference
,
Visual Computing
&
HPC
Application:
- AMD Ryzen™ Threadripper™ PRO 5000WX and 3000WX Processors
- 8-Channel DDR4 UDIMM/RDIMM/3DS RDIMM/LRDIMM 8 x DIMMs
- Dual Intel® 10GbE and 1GbE LAN Ports
- 1x Dedicated Management Port
- 7x PCIe 4.0 Slots for Multi-GPU
- Up to 8x 3.5” SATA HDD Bays and 2x M.2 (NVMe and SATA mode)
- Default 6x system Fan, and optional external 2x GPU Fan
- 2x 2000W CRPS RPSU 80+ Platinum
Request a Quote
1/6
* The entire materials provided herein are for reference only. GIGABYTE reserves the right to modify or revise the content at anytime without prior notice.
* Advertised performance is based on maximum theoretical interface values from respective Chipset vendors or organization who defined the interface specification. Actual performance may vary by system configuration.
* All trademarks and logos are the properties of their respective holders.
* Due to standard PC architecture, a certain amount of memory is reserved for system usage and therefore the actual memory size is less than the stated amount.
* Advertised performance is based on maximum theoretical interface values from respective Chipset vendors or organization who defined the interface specification. Actual performance may vary by system configuration.
* All trademarks and logos are the properties of their respective holders.
* Due to standard PC architecture, a certain amount of memory is reserved for system usage and therefore the actual memory size is less than the stated amount.
SPECIFICATIONS
Dimensions (WxHxD, mm)
Pedestal
175 x 438 x 680 mm
175 x 438 x 680 mm
Motherboard
MC62-G40
CPU
AMD® Ryzen™ Threadripper™ PRO 5000WX Processor
AMD® Ryzen™ Threadripper™ PRO 3000WX Processor
Processor up to 64-core, 128 threads
TDP up to 280W
AMD® Ryzen™ Threadripper™ PRO 3000WX Processor
Processor up to 64-core, 128 threads
TDP up to 280W
Socket
sWRX8 Socket
Chipset
AMD® WRX80
Memory
8 x DIMM slots
DDR4 memory module supported only
8 channel memory architecture
Support for 3200/2933/2666/2400/2133 MHz; ECC & non-ECC; buffered & unbuffered; UDIMM, RDIMM, 3DS R-DIMM, LRDIMM
Total up to 2TB of system memory (256GB single LRDIMM capacity)
DDR4 memory module supported only
8 channel memory architecture
Support for 3200/2933/2666/2400/2133 MHz; ECC & non-ECC; buffered & unbuffered; UDIMM, RDIMM, 3DS R-DIMM, LRDIMM
Total up to 2TB of system memory (256GB single LRDIMM capacity)
LAN
2 x 10GbE LAN (Intel® X550-AT2)
1 x GbE LAN (Intel® i210)
1 x 10/100/1000 management LAN
1 x GbE LAN (Intel® i210)
1 x 10/100/1000 management LAN
Video
Integrated in Aspeed® AST2600
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp
Audio
Realtek® ALC4080 HD audio codec
Supports 7.1 channel configurations
3 ports Audio Jack (Audio in/Audio out/Mic)
Supports 7.1 channel configurations
3 ports Audio Jack (Audio in/Audio out/Mic)
Storage
4 x 3.5" / 2.5" SATAIII hot-swappable HDD/SSD bays
Additional 4 x 3.5" / 2.5" SATAIII hot-swappable HDD/SSD bays (Option)
2 x M.2 slot for storage (M-Key; NGFF-2242/2280; PCIe Gen4 x4 or SATA III 6Gb/s)
SAS card is required for SAS devices support
Additional 4 x 3.5" / 2.5" SATAIII hot-swappable HDD/SSD bays (Option)
2 x M.2 slot for storage (M-Key; NGFF-2242/2280; PCIe Gen4 x4 or SATA III 6Gb/s)
SAS card is required for SAS devices support
RAID
RAID 0, RAID 1, RAID 5 and RAID 10
Peripheral Drives
2 x 5.25" space reserved for ODD device
Expansion Slots
Slot_7: 1 x PCIe x16 (Gen4 x16) slot
Slot_6: 1 x PCIe x16 (Gen4 x16) slot
Slot_5: 1 x PCIe x16 (Gen4 x16) slot
Slot_4: 1 x PCIe x16 (Gen4 x16) slot
Slot_3: 1 x PCIe x16 (Gen4 x16) slot
Slot_2: 1 x PCIe x16 (Gen4 x8) slot
Slot_1: 1 x PCIe x16 (Gen4 x16) slot
2 x M.2 slot for storage:
- M-key
- PCIe Gen4 x4 or 4x SATA 6Gb/s
- Supports NGFF-2242/2280 card
1 x M.2 slot for Wi-Fi:
- E-key
- Supports NGFF-2230 card
Slot_6: 1 x PCIe x16 (Gen4 x16) slot
Slot_5: 1 x PCIe x16 (Gen4 x16) slot
Slot_4: 1 x PCIe x16 (Gen4 x16) slot
Slot_3: 1 x PCIe x16 (Gen4 x16) slot
Slot_2: 1 x PCIe x16 (Gen4 x8) slot
Slot_1: 1 x PCIe x16 (Gen4 x16) slot
2 x M.2 slot for storage:
- M-key
- PCIe Gen4 x4 or 4x SATA 6Gb/s
- Supports NGFF-2242/2280 card
1 x M.2 slot for Wi-Fi:
- E-key
- Supports NGFF-2230 card
Internal I/O
1 x 24-pin ATX main power connector
2 x 8-pin ATX 12V power connectors
1 x CPU Fan header
1 x PCH Fan header
8 x System Fan headers
2 x USB 3.0 headers for 4 ports
1 x PMBus connector
4 x SATA III 6Gb/s ports
2 x M.2 slot for storage
1 x M.2 slot for Wi-Fi
3 x slimSAS connectors
1 x Front panel header
1 x Back plane board header
1 x PMBus header
1 x IPMB header
1 x TPM header
1 x COM header 6 x System fan headers
1 x USB 3.0 header
2 x COM headers
1 x TPM header
1 x Front panel header
1 x HDD back plane board header
1 x PMBus connector
1 x IPMB connector
1 x Clear CMOS jumper
1 x BIOS recovery jumper
2 x 8-pin ATX 12V power connectors
1 x CPU Fan header
1 x PCH Fan header
8 x System Fan headers
2 x USB 3.0 headers for 4 ports
1 x PMBus connector
4 x SATA III 6Gb/s ports
2 x M.2 slot for storage
1 x M.2 slot for Wi-Fi
3 x slimSAS connectors
1 x Front panel header
1 x Back plane board header
1 x PMBus header
1 x IPMB header
1 x TPM header
1 x COM header 6 x System fan headers
1 x USB 3.0 header
2 x COM headers
1 x TPM header
1 x Front panel header
1 x HDD back plane board header
1 x PMBus connector
1 x IPMB connector
1 x Clear CMOS jumper
1 x BIOS recovery jumper
Front I/O
1 x Front Panel Lock
2 x USB 3.0
1 x Power button
1 x Reset button
1 x Power LED
1 x Hard drives status LED
1 x System status LED
1 x UID LED
2 x LAN activity/link LEDs
4 x Hard drive bays
2 x USB 3.0
1 x Power button
1 x Reset button
1 x Power LED
1 x Hard drives status LED
1 x System status LED
1 x UID LED
2 x LAN activity/link LEDs
4 x Hard drive bays
Rear I/O
1 x VGA
1 x ID Button
2 x USB 3.2 gen2 (Type-A + Type-C®)
1 x RJ45 (GbE LAN)
1 x MLAN
4 x USB 3.2 gen2 Type-A
2 x RJ45 (red) (10GbE LAN)
1 x 3 in 1 Audio jacks 1 x Power switch with LED
1 x ID Button
2 x USB 3.2 gen2 (Type-A + Type-C®)
1 x RJ45 (GbE LAN)
1 x MLAN
4 x USB 3.2 gen2 Type-A
2 x RJ45 (red) (10GbE LAN)
1 x 3 in 1 Audio jacks 1 x Power switch with LED
TPM
1 x TPM header with SPI interface
Optional TPM2.0 kit: CTM010
Optional TPM2.0 kit: CTM010
Power Supply
2 x 2000W redundant PSUs
80 PLUS Platinum
AC Input:
- 100-127V~/ 13A, 50-60Hz
- 200-240V~/ 12A, 50-60Hz
DC Output:
- Max 2000W/ 240-300V
+12.2V/ 166.7A
+12Vsb/ 3A
- Max 1560w / 180-220V
+12.2V/ 130A
+12Vsb/ 3A
- Max 996W/ 90-140V
+12.2V/ 83A
+12Vsb/ 2.1A
System Management
ASPEED® AST2600 Management Controller
GIGABYTE Management Console (AMI MegaRAC SP-X) web interface
GIGABYTE Management Console (AMI MegaRAC SP-X) web interface
- Dashboard
- HTML5 KVM
- Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
- Sensor Reading History Data
- FRU Information
- SEL Log in Linear Storage / Circular Storage Policy
- Hardware Inventory
- Fan Profile
- System Firewall
- Power Consumption
- Power Control
- LDAP / AD / RADIUS Support
- Backup & Restore Configuration
- Remote BIOS/BMC/CPLD Update
- Event Log Filter
- User Management
- Media Redirection Settings
- PAM Order Settings
- SSL Settings
- SMTP Settings
OS Compatibility
Windows 10 (64bit)
Windows 11 (64bit)
Red Hat Enterprise Linux 8.2 (64bit)
Red Hat Enterprise Linux 8.3 (64bit)
Ubuntu 20.04 LTS (64bit)
Windows 11 (64bit)
Red Hat Enterprise Linux 8.2 (64bit)
Red Hat Enterprise Linux 8.3 (64bit)
Ubuntu 20.04 LTS (64bit)
Weight
Net Weight: 22 kg
Gross Weight: 24 kg
Gross Weight: 24 kg
System Fans
4 x 80x80x38mm (11,000 rpm)
2 x 80x80x38mm (8,200 rpm)
Recommend Action: purchase additional GPU Fan module (option) to reach maximum computing performance if system is installed multiple GPU cards with up to 300w power consumption.
2 x 80x80x38mm (8,200 rpm)
Recommend Action: purchase additional GPU Fan module (option) to reach maximum computing performance if system is installed multiple GPU cards with up to 300w power consumption.
Operating Properties
Operating temperature: 10°C to 35°C
Operating humidity: 8-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)
Operating humidity: 8-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)
Packaging Dimensions
1078 x 588 x 388 mm
Packaging Content
1 x W771-Z00
1 x CPU Fan-sink
1 x Quick installation guide
1 x CPU Fan-sink
1 x Quick installation guide
Part Numbers
Barebone package: 6NW771Z00MR-00-1*
- Motherboard: 9MC62G40MR-00*
- I/O shield: 12AIO-MC62G4-00R
- Power supply: 25EP0-22000G-A0S
- GPU Fan module: 25HB1-MC6200-C0R (option)
- Additional HDD cage: 25HB1-MC6201-C0R (option)
- Rail kit for W771-Z00 (option, (A)+(B))
(A) 25HB2-A66123-C0R (Slide Rail), Q'ty: 1 set
(B) 25HB4-MC6200-C0R (Handle + Rack ear + Rail screws), Q'ty: 1 set
- CPU Fan-Sink: (option, (A)+(B))
(A) 25ST2-88382C-D0R (Fan)
(B) S25ST1-243103-A0R (Sink)
- Motherboard: 9MC62G40MR-00*
- I/O shield: 12AIO-MC62G4-00R
- Power supply: 25EP0-22000G-A0S
- GPU Fan module: 25HB1-MC6200-C0R (option)
- Additional HDD cage: 25HB1-MC6201-C0R (option)
- Rail kit for W771-Z00 (option, (A)+(B))
(A) 25HB2-A66123-C0R (Slide Rail), Q'ty: 1 set
(B) 25HB4-MC6200-C0R (Handle + Rack ear + Rail screws), Q'ty: 1 set
- CPU Fan-Sink: (option, (A)+(B))
(A) 25ST2-88382C-D0R (Fan)
(B) S25ST1-243103-A0R (Sink)
* The entire materials provided herein are for reference only. GIGABYTE reserves the right to modify or revise the content at anytime without prior notice.
* Advertised performance is based on maximum theoretical interface values from respective Chipset vendors or organization who defined the interface specification. Actual performance may vary by system configuration.
* All trademarks and logos are the properties of their respective holders.
* Due to standard PC architecture, a certain amount of memory is reserved for system usage and therefore the actual memory size is less than the stated amount.
* Advertised performance is based on maximum theoretical interface values from respective Chipset vendors or organization who defined the interface specification. Actual performance may vary by system configuration.
* All trademarks and logos are the properties of their respective holders.
* Due to standard PC architecture, a certain amount of memory is reserved for system usage and therefore the actual memory size is less than the stated amount.
SUPPORT
Driver
BIOS
Utility
Firmware
- All
- All
- Windows 11 64bit
- Windows 10 64bit
Audio
Audio
Version
Size
Date
Chipset
Chipset
Version
Size
Date
SATA RAID/AHCI
VGA
VGA
Version
Size
Date
ASPEED Graphic Driver
Version : 1.12
3.45 MB
Mar 31, 2022
OS: Windows 10 64bit,Windows 11 64bit
BIOS
Description
Version
Size
Date
Windows and UEFI mode flash BIOS SOP
Please download BIOS update tool from AMI Website
Please download BIOS update tool from AMI Website
-
0.31 MB
Jan 29, 2021
Warning:
Because BIOS flashing is potentially risky, if you do not encounter problems using the current version of BIOS, it is recommended that you not flash the BIOS. To flash the BIOS, do it with caution. Inadequate BIOS flashing may result in system malfunction.
What is a BETA?
BETA describes a new version that is reliable yet may not include all the features of the final product. During this phase we are previewing new features and gathering customer input to insure our product provides the best experience possible.
Because BIOS flashing is potentially risky, if you do not encounter problems using the current version of BIOS, it is recommended that you not flash the BIOS. To flash the BIOS, do it with caution. Inadequate BIOS flashing may result in system malfunction.
What is a BETA?
BETA describes a new version that is reliable yet may not include all the features of the final product. During this phase we are previewing new features and gathering customer input to insure our product provides the best experience possible.
- All
- All
- Windows Server 2022
- Windows Server 2019
- Windows Server 2016 R2 64bit
- Windows Server 2016 64bit
- Windows Server 2012 R2 64bit
- Windows Server 2012 64bit
- Windows 10 64bit
- VMware
- Ubuntu
- Linux CentOS
- Linux
Utility
Description
Version
Size
Date
GSM CLI
Version : 2.1.67
111.17 MB
Oct 31, 2023
OS: Windows Server 2012 64bit,Windows Server 2012 R2 64bit,Linux CentOS,Windows 10 64bit,Ubuntu,Windows Server 2016 R2 64bit,Windows Server 2019,Windows Server 2022
GSM Server
Version : 2.12
926.33 MB
Jan 18, 2023
OS: Linux,Windows Server 2016 64bit,Windows Server 2019
GSM Agent
Version : 2.5
720.29 MB
Dec 27, 2021
OS: Linux,Windows Server 2016 64bit,Windows Server 2019
Firmware
Description
Version
Size
Date
BMC Firmware with embedded GIGABYTE Management Console
(AST2600 AMI)
(AST2600 AMI)
Version : 13.05.07
112.97 MB
Sep 27, 2023
English
Manual
Description
Version
Size
Date
User Guide - GIGABYTE Management Console (AMI AST2600)
Version : 1.0
17.39 MB
Aug 29, 2023
English
User Guide - BIOS setup manual (AMD Naples platform)
Version : 1.0
18.14 MB
Sep 05, 2017
English
Support List
Description
Version
Size
Date
QVL Support List
Version : 1.5
0.3 MB
Jun 14, 2023
QVL for W771-Z00 ; new add Threadripper PRO 5000WX series
RESOURCES
Articles
Solutions
Video
News
Media Review
Others
Back to W771-Z00
